Interface Solutions Aid Pharmaceutical Industry

Among the many highly regulated and incredibly complex industries, the medical industry is highly dependent on tools and resources that are precise and measure with high accuracy.

The medical industry is a broad, encompassing hospitals, medical professionals, payers, medical devices and pharmaceuticals. In each sector, Interface has a long history of providing precision measurement solutions for R&D, prototyping, testing, manufacturing, packaging and monitoring use.

In every use case, safety of patients and quality of products is predicated on extreme accurateness. Throughout a pharmaceutical product’s life cycle, specialized measurement equipment and sensor technologies are used by scientists, engineers, researchers, lab technicians, regulators, quality groups and manufacturers. These instruments are utilized in design and maintenance to provide unmistakable evidence of process quality and safety.

Medical and healthcare companies, including those specifically in pharmaceuticals, turn to Interface because our high accuracy force measurement solutions are designed for reliable performance test and measurement projects. The science used in the pharmaceutical industry depends on quality measurement of force and weight. Interface load cells are designed for these types of precise requirements. There is also tremendous demand for Interface’s ability to customize solutions that meet the exact measurement requirements of these sensitive applications. Visit our new Interface Pharmaceutical Industry Solutions.

Interface supports a range of pharmaceutical applications including:

• Weighing and distributing
• Specimen testing equipment
• Tablet hardness testing
• Tablet forming machine optimization
• Capsule filling machines
• Quality control and safety
• Mixing
• Packaging and filling
• Bioreactors and fermenters

Interface force measurement solutions are used for a variety of pharma-related products and machines that help biotechnology and pharmaceutical product engineers to design, test, and manufacture their products.  When it comes to equipment used in the manufacturing of medicine, Interface products are used to optimize production and reduce waste. Our miniature load cells are often integrated into machines and equipment to provide precision measurements during operations.

Types of Interface Load Cells Used by Pharmaceutical Companies

• WMC Rod End Load Cell
• SuperSC S-Type Miniature Load Cell
• ConvexBT Load Button Load Cell
• SML Low Height Load Cell
• LBMP Overload Protected Compression Load Button Load Cell
• LW General Purpose Load Washer Load Cell
• LWCF Clamping Force Load Cell
• LWPF1 Press Force Load Washer Load Cell
• MB Miniature Beam Load Cell
• MCC Miniature Compression Load Cell
• SM S-Type Load Cell
• SMA Miniature S-Type Load Cell

Pharmaceutical Tablet Forming Machine Optimization

A pharmaceutical tablet producer wanted to monitor the forces applied by the tablet forming machine to understand the relationship between raw material, die set, forming force, and the motor’s cycle speed. The goal was to improve productivity and efficiency of the tablet forming process, while reducing losses such as cracked tablets or voids, by adding a dimension of feedback that could be used to assign specific press adjustment criterion for given inputs. An Interface WMC Sealed Stainless Steel Mini Load Cell (10K lbf Capacity) was mounted in the section of the downward press bar. The machine was modified to accomplish this. The load cell was then connected to a 9320 Portable Load Cell Indicator to collect the needed data. After analyzing the data, the tablet producer was able to quantify adjustment levels by monitoring which forces produced the most optimal results for a given cycle speed, die set, and raw material. Productivity and efficiency were greatly improved by the enhancement of the data feedback.

Tablet Hardness Testing for Pharmaceuticals

A pharmaceutical producer wanted to test and monitor the hardness of the pills being created in their tablet forming machine. Interface’s SML Low Height S-Type Load Cell was mounted to the hardness device inside the tablet forming machine. The SML Low Height S-Type Load Cell was then connected to the 9870 High-Speed High Performance TEDS Ready Indicator to record the force measurements. The tablet producer was able to verify and test the specific hardness needed for their tablets being produced by their tablet forming machine.

Pharmaceutical Tablet Machine Hardness Calibration

A customer wanted to regularly recalibrate tablet hardness testers. The customer needed a miniature load cell the size of a sugar cube that replaces the tablets and fits horizontally in the tablet test-box. Therefore, a special cable exit was important for the compression only calibration application. In the past, the machines had to be rebuilt for calibrations, or a complex mechanism had to be integrated to enable vertical calibration. However, Interface’s MCC Miniature Compression Load Cell measures forces on its side with a special cable exit on the flat side that attaches to the calibration indicator, such as the Interface handheld indicator and datalogger Model 9330. The MCC load-cell calibration set compared the applied forces with the hardness tester to make sure that the tablet hardness tester uses the correct force for future tablet hardness tests. The BlueDAQ software helped to log and compare the data of the MCC reference load cell. The customer successfully verified and calibrated the tablet hardness tester machine horizontally to conduct accurate hardness testing on tablets in the future. Interface’s MCC Miniature Compression Load Cell was perfect due to its small size, and convenient to measure the forces on its side.

Like medical devices, pharmaceutical machines and products must undergo a variety of mission-critical tests before they are safe for distribution to uses. Interface products are selected by the pharmaceutical industry is due to our product’s accuracy and reliability, in addition to our deep experience in supplying solutions to those in the medical business.
