Calibration and Repair Services
Interface provides calibration and repair services on load cells and other force measurement devices from nearly any manufacturer.
Load Cells
100,000+ Calibrations Performed Annually
Why Choose Interface for Calibration and Repair Services?
Interface provides calibration and repair services on load cells and other force measurement devices from nearly any manufacturer. We perform more than 100,000 calibrations annually on devices shipped to Interface for recalibration, as part of the post-repair process, or on devices newly manufactured by Interface. Repairs include a complete evaluation of the device prior to repair and calibration upon completion.
Calibration Experts
- ISO 17025 Accredited
- 50+ Years of Calibration Experience
- Calibration of All Manufacturers Load Cells
- 100,000+ Calibrations Performed Annually
- Custom Calibrations to Meet your Needs
- IPerform Service Software for RMA, Tracking and Permanent Archive of Test Data
- NMI Certified Gold and Platinum Standard Reference Load Cells
- Interface Gold Standard Calibration Software Used for Data Collection & Analysis
- Full-Service Machine Shop for any Mechanical Requirements
Force
- NIST/NMI Traceable Calibration
- 2 gf – 1 Million lbf Calibration Capability
- (9) Hydraulic & (5) Deadweight Test Stands to Support Your Calibration Requirements
Torque
- 0.022 – 100K in-lbf Capacities
- NIST Traceable to 2.2K in-lbf
- NMI Traceable 2.2K – 100K in-lbf
Customer Service
- Highly Trained & Dedicated Professionals
- Quick and Timely Response
- Expedited 2-3 Business Day Service Available
- A2LA Accredited Lab Certificate Interface
Repair Services
- Comprehensive repair services on load cells, force and torque transducers
- Basic repair services for industry standard force and torque transducers
- Dependable turnaround including calibration
- Connector replacement* for any manufacturers load cell
- Complimentary transducer evaluations
Calibration Services
Calibration is important based on many different factors, including continued performance, safety, and compliance with ISO or industry specific standards. Interface’s standard recommended calibration interval is 12 months. The frequency of calibrations should be determined by the customer based on the following factors that may affect measurement accuracy:
- Measurement quality and allowable tolerance range
- Level of stress to which the equipment is subjected
- Stability of past calibrations
- Required measuring accuracy
- Quality assurance requirements
Once these factors are established and the stability of past calibrations are reviewed, the customer may then establish the calibration frequency:
- Per ASTM E74 Standard
- Normal Use – Calibration every 12 months.
- Severe Use – Calibration on a quarterly to monthly basis.
- Special Service – As recommended after consultation with an Interface Technical Service team member.
Recalibration Services offered for Tension, Compression, System Calibrations, ISO 376, ASTM E74.
Force
Force
| Services Offered | Standard | ANSI Z-540.1 MIL-STD-4562A |
ASTM E74 | ISO 376 |
|---|---|---|---|---|
| Tension & Compression | ✔ | ✔ | ✔ | ✔ |
| Dual Bridge | ✔ | ✔ | ✔ | ✔ |
| System Calibrations | ✔ | ✔ | ✔ | ✔ |
| Extra/Custom Points Available | ✔ | ✔ | ✔ | ✔ |
| Interface NMI Traceable Cal Cert | ✔ | ✔ | ✔ | ✔ |
| A2LA / ISO 17025 Accredited | ✔ | ✔ | ✔ | |
| Lower Load Limits | ✔ | |||
| Calibration Coefficients | ✔ | ✔ | ||
| Calibration Curve Fit Graph | ✔ | ✔ | ||
| ISO 376 Class 0.5 <500 lbf | ✔ | |||
| ISO 376 Class 1 >500 lbf | ✔ |
Torque
Repair Services
Interface offers repair services for damaged or suspect load cells with highly trained and experienced repair technicians. Each load cell is fully inspected and tested in order to diagnose the problem(s). Following our evaluation, we will provide you with a list of issues and our recommendation(s), proposing the most cost effective solution for you.
- Complete complimentary evaluation prior to repair and calibration
- Connector replacement on any manufacturers’ load cell subject to connector availability, excludes welded connectors
- To learn more or request calibration or repair services, please complete the form below. In order to complete this form you will need the following:
- The model name and/or number of each device.
- The serial number of the item(s) you want services.
Once submitted, you will receive an RMA (Return Material Authorization) number, which is required to accompany all devices sent in to the service department and help track the progress of your request. Requests for expedited services are available for an additional fee of $140.00 per device, please call to confirm service length if repairs are required.
Industry Standard Links
For additional standards and technical information regarding Calibration and load cells, please visit.
