SM S-Type Load Cell

S-Type

QuickShip48 Product
  • Low-deflection / better test results
  • Proprietary Interface temperature compensated strain gages
  • High performance
  • 0.0008%/°F temp. effect on output
  • Lowest creep (0.025%)
  • Tension and compression
  • 5 ft integral cable included

Order QuickShip48™ Now

Request a Quote

Request a CAD File

Clicking "Order Now" below will take you to our new Quickship 48 site so you can place your order.

Order Now

Request a Quote

Request a CAD File

Product Downloads

  • Data Sheet
  • Installation Manual
  • SM 10-250lbf STP File
  • SM 50-1KN STP File
  • SM 500-1Klbf STP File
  • SM 2K-5KN STP File
  • SM 10-250 lbf Drawing
  • SM 500 lbf Drawing
  • SM 1K lbf Drawing

Specifications

Dimensions

Model SM is a low cost highly accurate unsealed load cell for test machine and other general purpose applications. This product is available in capacities ranging from 10 to 1000 lbf (50 N to 5 kN).

See datasheet for available models, additional capacities, connectors, options, and accessories.
