Interface and Testing Lab Applications
Test and measurement impacts nearly every industry. At Interface, we classify Test and Measurement (T&M) as it’s own solutions market. Though testing is generally a service, the accuracy and quality equipment and tools that are required for performing these T&M services has created an industry in itself.
Throughout the Test and Measurement industry, there are several different classifications and testing lab types. Each of these different testing labs provide unique equipment for different forms of testing depending on the application, system or component. These different types test labs include:
- Structural testing labs perform tensile, compression, bending, fatigue and hardness testing on materials, components, or assemblies.
- Environmental testing labs evaluate the impact of environmental factors on products, components, or materials performing temperature, humidity, salt spray, and vibration testing.
- Electrical testing labs determine the electrical properties of components or products using insulation resistance, electrical continuity, and dielectric strength testing.
- Chemical testing labs determine the composition and purity of materials using chromatography, spectroscopy, and elemental analysis.
- Product safety testing labs ensure that products meet safety and regulatory standards with flammability, toxicity, and durability testing.
- Calibration testing labs ensure that measuring instruments and equipment are accurate and reliable. Common disciplines include force, torque, pressure, temperature and physical calibration. Read more: Interface Calibration 101
- Non-destructive testing labs evaluate the integrity of materials with ultrasonic testing, magnetic particle inspection, and radiography.
Here at Interface, we are deeply ingrained in supplying nearly every type of testing lab out there with precision T&M devices, from the world’s best force measurement sensors to advanced instrumentation. Interface offers one of the most diverse force, torque, and weight related force sensor product lines in the market. It is why labs prefer Interface. In addition to our expanding line of data acquisition systems, software and accessories, T&M engineers and lab pros find Interface as a one-stop-shop for simple and complex testing projects.
Testing Lab Applications Using Interface Products
Material Testing Lab – Press Form Monitoring
Customer Challenge: Press forming is a method to deform different materials. A force measurement solution is required to monitor the forces being applied by the press forming machine to ensure quality control and traceability during the production process.
Interface Solution: For large press forming machines, Interface recommended installing the 1000 High Capacity Fatigue-Rated LowProfile™ Load Cell. When the material was placed under the punch plate to form a shape, the force applied was measured and results were sent to the INF-USB3 Universal Serial Bus Single Channel PC Interface Module, where results can be graphed and logged. Read: Press Forming and Load Monitoring
Medical Testing Lab – Specimen Research Linear Test Stand
Customer Challenge: Medical experts need the best equipment during research of multiple specimens. In this case, a medical researcher needed to monitor the load force of their linear actuator that uses a needle to collect material from the desired specimen.
Interface Solution; Interface’s SuperSC S-Type Miniature Load Cell was easily installed into the linear test stand. A needle with a gripper on the end was installed on the lower end of the SuperSC. As the needle is pushed to collect material of the specimen, the load feedback is captured using the 9330 Battery Powered High Speed Data Logging Indicator. Read: Specimen Research App Note
Safety Test Facility – Bike Helmet Impact Test
Customer Challenge: A company wanted to test the impact of a bike helmet when dropped from different heights, onto a flat surface such as an anvil. This test is necessary to ensure consumer safety, and that their products are made of the highest quality until sold to the public.
Interface Solution: Interface suggested installing our 1101 Compression Only Ultra Precision LowProfile™ Load Cell at the bottom of an anvil. The bike helmet was then dropped from multiple heights, at multiple angles, onto the anvil. The measurements from impact were then recorded and logged using our INF-USB3 Interface Module. Read: CPG Bike Helmet Impact Test
Product Test Lab – Touch Screen Force Testing
Customer Challenge: Touchscreen kiosks used in restaurants, retail and entertainment venues all need various tests to be performed to ensure functionality and sensitivity. One of those tests are force tests that touch screens to withstand high use by all types of consumers.
Interface Solution: Interface’s SMTM Micro S-Type Load Cell was installed on the customer’s force testing machine. The touchscreen was laid flat under the machine, and force tests were conducted in different locations of the touchscreen. With supplied BlueDAQ software, results are captured and reviewed using the 9330 Battery Powered High Speed Data Logging Indicator through an SD card.
These are just a few examples of where Interface products are involved in a wide variety of different testing labs and how T&M engineers are utilizing them. To learn more, check out our new Testing Lab Essentials webinar, which can be found here.
