Force Measurement is Fundamental in Material Testing

/0 Comments/in /by

Material tests are run to determine the quality, durability, and resistance of materials for parts and products. Selecting the right material is critical to performance of a product, system, or part, especially as it relates to the environmental factors. It is also core for adhering to regulatory standards and compliance requirements.

Whether it is construction and concrete materials, metals, fabrics, biomaterial, plastics, packaging, or some other matter, material testing is fundamental throughout the entire development lifecycle.

Among the various ways to test materials, force measurement is one of the most important. Common uses of force measurement in material tests include applications to measure hardness, torsion, strength, compression, bending, shear, impact, creep, fatigue, and nondestructive capabilities.

The use of load cells provides an adaptable tool that can be utilized for various types of material tests. Using force measurement sensors help to detect changes in load, which is used to determine the flexibility, strength, or weakness of properties in materials. This is critical for research and quality control.

For example, in metal material testing load cells are frequently used for characterizing and assessing the quality of metallic components and structures. Material test engineers use load cells to accurately measure the tensile strength, compression resistance, and yield properties of metal samples. By subjecting metals to controlled loads and monitoring the metals deformation during tests, Interface load cells provide critical data that informs engineering decisions and quality control processes. Material tests confirm that the metals chosen for products like aircraft structures, automotive components, and sports equipment, meet stringent performance standards. The measurement sensors are also vital for determining the reliability, longevity and safety of metal materials used for any product or part. See other examples of testing in our new Interface T&M Material Testing Overview.

It is the responsibility of a material testing engineer to determine the resilience, safety, and value of materials through mechanical testing, of which material testing is one of the five categories. Ultimately, product designers and original equipment manufacturers (OEMs) rely upon material testing data to ensure their products can withstand the anticipated levels of force during use. They also need to know if the material will stretch or elongate, as well as pinpoint its exact breaking point.

Interface’s robust line of load cells, multi-axis sensors, and data acquisition systems are used for material testing. It is common to have our 1200 LowProfile load cells installed into material testing machines at test labs and onsite. We also supply a variety of miniature load cells and load pins for material testing, depending on the type of equipment and environment used for tests.

High accuracy load cells are essential in material testing due to their precision, versatility, and ability to provide real-time data, which helps researchers and engineers gain a better understanding of a material’s mechanical properties and behavior under different conditions.

If force must be measured, Interface has a solution. This applies to testing materials used for infrastructure, medical devices, aircraft, rockets, vehicles, robotics and consumer goods. As new materials and composites are introduced in revolutionary ways for use in construction, designing light weight products using polymers, and 3D printed components, it is imperative that material tests validate the use case based on high accuracy measurements.

Our force measurement products are being used to gather data from testing materials in applications used for machines, equipment, structures, packaging and more. Here are a few examples of material testing applications.

Inflatable Space Habitat

Inflatable habitats are the newest innovation in the space industry, creating a new interplanetary dwelling for humans to live and work past the Earth’s atmosphere. An innovative space industry company wanted to test the overall design and material of their inflatable habitats by conducting a burst test. Multiple clevises and LP Stainless Steel Load Pins were attached to the in the webbing material that create the inflatable habitat. When pressure was increased within the inflatable habitat, the load pins captured how much force the heavy duty material will hold at specific pressures until it explodes. Interface’s LP Stainless Steel Load Pins successfully measured the amount of force the inflatable habitat could withstand during the burst test.

Material Tensile Testing Load Frame

A customer wanted to conduct a tensile force test on different samples and materials until failure. Materials include plastic, steel, or woven fabric. They wanted to measure tensile strength, yield strength, and yield stress. Interface’s 1200 Standard Precision LowProfile™ Load Cell was installed into the customer’s test frame. The tensile test was conducted, and force results were captured by the load cell and extensometer were synced through the SI-USB4 4 Channel USB Interface Module. These results were then displayed on the customer’s PC with supplied software. With Interface’s force products, the customer was able to determine the tensile strength, yield strength, and yield stress of a variety of different materials.

Material testing is often the first step in any new product development process. With Interface force measurement solutions, our customers can expect industry-leading accuracy, quality and reliability in testing the materials that will go into their next project. Contact us for products used for various test types.

Interface Solutions for Material Testing Engineers

Tensile Testing for 3D Materials

Bending Beam Load Cell Basics

The Aviation Industry Soars Using Interface Solutions

Interface Solutions for Structural Testing

Interface Solutions Aid Pharmaceutical Industry

How Does Tensile Testing Work?

/0 Comments/in /by

Tensile testing, also known as tension testing, is a type of mechanical test used to determine how a material responds to a stretching force. This test helps evaluate the mechanical properties of an object, such as metals, polymers, composites, and various other materials.

Performing a tensile test applies a load to specimen, and gradually increasing the load sometimes until failure or destruction. The tensile data is analyzed by using a stress-strain curve.

Interface stain gage load cells are commonly used in tensile testing due to their high precision and sensitivity. They work by measuring the strain in a material, which is directly related to the applied force. This strain data is then converted into force measurements. Learn more in Tension Load Cells 101.

Tensile testing is fundamental in test and measurement. It is used by researchers, testing labs, and engineers across industries including infrastructure, medical, manufacturing, aerospace, consumer goods, automotive, energy, and construction.

How Tensile Testing Works

Tensile testing is essential in materials science and engineering to understand the material’s behavior under tension and to ensure its suitability for specific applications.

First, a specimen of the material is prepared with a specific shape and dimensions. This sample is carefully controlled to meet testing standards based on the test plan.

Interface supplies a variety of load cells for these tests. The load cell is typically mounted in a tensile testing machine. The tensile test machine has two separate jaws, one of which will move away from the other at a controlled rate during the test. As it moves away, it is pulling on the material, stretching it until it the test is complete, or it breaks. This is also referred to as testing to failure or destruction. The controlled rate is called the strain rate, and materials will behave differently under different strain rates.

The specimen is then securely mounted in a testing machine, which is usually called a tensile testing machine or universal testing machine. The load cell is positioned in such a way that it bears the load applied to the specimen during the test.

Load cells are commonly used in tensile testing to measure and record the force or load applied to a specimen during the test. These sensor devices are crucial for accurately determining the mechanical properties of materials under tension.

The testing machine applies a pulling force (tensile force) to the specimen along its longitudinal axis. The force is gradually increased at a constant rate, causing the specimen to elongate.

As the tensile testing machine applies a pulling force to the specimen, the load cell measures the force in real-time. This force measurement is typically displayed on a digital instrumentation device or recorded by a data acquisition system.

The recorded data, including the applied force and the corresponding elongation or deformation of the specimen is usually plotted on a stress-strain curve for analysis. The stress-strain curve provides valuable information about the material’s mechanical properties, including its ultimate tensile strength, yield strength, Young’s modulus, and elongation at break.

Engineering Checklist for Tensile Test Plans

  • Identify the Purpose of the Tensile Test
  • Select the Material and Test Standard
  • Define the Mechanical Properties
  • Determine the Specific Mechanical Properties for Evaluation
    • Common properties include tensile strength, yield strength, modulus of elasticity (Young’s modulus), elongation, reduction in area, stress-strain curve characteristics
  • Establish Test Conditions
    • Include temperature, strain rate and testing environment
  • Define Sample and Specimen Requirements
  • Determine Measurement Accuracy Requirements
  • Prepare Instrumentation and Equipment
  • Plan for Data Recording and Reporting
  • Review Compliance Requirements and Safety Standards
  • Document Test Plan
  • Publish Verification and Validation Processes
  • Report Results

Defining measurement requirements for tensile tests by specifications is a crucial step in ensuring that the tests accurately and reliably assess the mechanical properties of materials.

Tensile Testing Terms to Know

Stress: Stress is the force applied per unit cross-sectional area of the specimen and is usually denoted in units of pressure. Stress is calculated by dividing the measured force by the cross-sectional area of the specimen. The load cell’s force measurement ensures that the stress values are accurate and precise. Simply, stress is the amount of force applied over a cross-cross-section.

Strain: Strain represents the relative deformation of the material and is the change in length (elongation) divided by the original length of the specimen. Strain is the amount of elongation in a sample as it is stretched or squashed.

Elastic Region: In the stress-strain curve, the initial linear region where stress is directly proportional to strain is known as the elastic region. Here, the material returns to its original shape when the load is removed.  As soon as a material is placed under any load at all, it deforms. Visually, the deformation may not be noticeable, but right away, the material is deforming. There are two types of deformation: elastic (not permanent) and plastic (permanent).

Yield Point: The yield point is the stress at which the material begins to exhibit permanent deformation without an increase in load. It marks the transition from elastic to plastic deformation.

Ultimate Tensile Strength (UTS): UTS is the maximum stress the material can withstand before breaking. It is the highest point on the stress-strain curve. If the material is loaded to its UTS, it will never return to its original shape, but it can be useful in engineering calculations, as it shows the maximum, one-time stress a material can withstand.  Load cells can detect the exact moment of specimen failure, such as fracture or breakage. This information is crucial for determining the ultimate tensile strength and other mechanical properties of the material.

Elongation at Break: Elongation at break is the amount the specimen stretches before it breaks, expressed as a percentage of the original length.

Load cells can also be used for real-time monitoring and control during the test. Test operators can set specific load or strain rate parameters to control the testing machine’s operation and ensure the test is conducted within specified conditions.

Load cells play a safety role by providing feedback to the testing machine’s control system. If the load exceeds a certain threshold or if the load cell detects an anomaly, the testing machine can be programmed to stop or take corrective actions to prevent damage to the equipment or ensure operator safety.

To discuss Interface products and experience in tensile testing, be sure to reach out to our global representatives in the field or contact us. We are always here to help!

The Aviation Industry Soars Using Interface Solutions

/0 Comments/in /by

Interface is proud to offer a diverse range of force, torque, and weight measurement solutions to the aviation industry.

A sector within the aerospace industry, Interface aviation solutions are products we supply for use in the design, engineering and operation of aircraft.

The quality of our products, including the reliable form factor design, proprietary strain gages, and rugged materials, are built to withstand the rigorous performance standards and environments that aircraft safety demands. It is why Interface is a provider of choice for test and measurement solutions in the aviation industry. Check out our new Aircraft Solutions overview here.

The aircraft and aviation industries are vast and complex with many different sectors. Our products are currently used in commercial, general and military aviation, aviation infrastructure, equipment and systems. In addition to the mechanical component testing, Interface often supplies load cells, torque transducers and instrumentation for use in aviation training, education, research and development.

While aviation systems embody an extensive collection of interconnected components and technologies, this complexity does not lessen the requirements for rigorous sensor-based test and measurement programs for every part. Interface products help to collect critical data on the performance of aircraft components and systems. These aviation systems include aircraft, air traffic control, navigation and communication systems, infrastructure, ground support equipment, airport transport vehicles, aircraft testing labs, and tools.

We work with aeronautical and mechanical engineers who are involved in designing, developing, and maintaining aircraft, propulsion systems, avionics, and air traffic management technologies. Interface load cells and transducers provide accurate and reliable measurements of forces, weights and torques of aviation components and systems.

How does the aviation industry use Interface measurement solutions?

  • Aircraft engine manufacturers use our load cells and torque transducers to measure the operating performance within their design limits and for diagnostics and troubleshooting. Read: Aircraft Engine Hoist
  • Aviation system developers integrate our sensors into equipment and parts to provide continuous force monitoring and to trigger alarms for maintenance.
  • Rotorcraft part makers need to assess the loads and torques on blades and other components to the aircraft is safe to fly and to identify any weaknesses based on accurate measurements. Read:Propeller Testing
  • Landing gear experts use our load cells to confirm that the gear can withstand the forces encountered during takeoff, landing, and taxiing. Read: Landing Gear Joint Testing
  • Aircraft structures must be strong enough to withstand the forces encountered in flight. Testing is standard for cycle counts, environmental tests and assessment of materials. Interface products are used for assessing structural like wings and fuselages in wind tunnel tests. Read: Interface Solutions for Structural Testing and Aircraft Wing Fatigue App Note
  • Flight control systems are using measurement sensors to test and monitor the components used for various controls. Read: Aircraft Yoke Torque Measurement
  • In-flight systems and simulators utilize precision measurement devices to provide vital data that monitors aviation and aircraft health. This is important for real-time assessments and for training purposes. It is essential for the long-term growth of the industry to provide the best tools and equipment to learn the values of accurate measurement and how it impacts performance and safety.

Beyond the essential manufacturers of aircraft parts, aviation systems, and equipment, Interface supplies many of the leading aviation testing labs with load cells, load pins, torque transducers, wireless devices and instrumentation. The quality of our products is built to withstand the rigorous performance standards and environments that aircraft safety demands.

Our products are used for static testing, material testing, torque testing, fatigue testing, stress and tension tests, dynamic testing, environmental and wind tunnel testing, structural tests and compression testing. We also supply the aviation industry with measurement solutions for rigging, lifting, weighing and monitoring of equipment in use. Check out our Aircraft Lifting Equipment App Note.

Learn more about our range of solutions in this Airplane Jacking System solution.

The aviation industry is a dynamic and ever-changing industry, and the sectors within it are constantly evolving. New innovations in the aviation require extensive testing and accurate measurement. The aviation industry is a complex and demanding industry, and the development of new technologies requires a rigorous testing process.

The fact that Interface offers an extensive array of force measure devices in different models, capacities, configurations and capabilities helps aviation system suppliers and manufacturers. Our load cells and sensor technologies are used to measure a wide range of factors, such as tensions, weights, forces, and torques. This information can be used to ensure the safety and reliability of aircraft and their components.

With a surplus of options that can meet the specifications of each use case and testing application, Interface is an experience and preferred provider to the aviation industry.

ADDITIONAL RESOURCES

Interface Supports Wind Tunnel Testing

LIFTING: Airplane Jacking System

LIFTING: Aircraft Engine Hoist

Taking Flight with Interface Solutions for Aircraft Testing

Aircraft Wing Fatigue App Note

Aircraft Screwdriver Fastening Control App Note

Airplane Static Testing Case Study

Force Measurement Testing Improves Products and Consumer Safety

/0 Comments/in /by

Across every industry, force measurement solutions are utilized to improve product performance, safety and quality. Sensor technologies are used every day to test various consumer products’ weight, torsion, tension, compression, fatigue, impact, and materials.

Force measurement testing is used throughout the product development lifecycle, from concept and R&D, through engineering and testing, to manufacturing and distribution, leading to eventual utilization. Interface load cells are commonly integrated into actual consumer products for activation and to measure performance during use.

Interface force measurement solutions are also used in the testing of equipment, machines, and tools used in the production of all types of products and goods. Our products are used in industrial automation robotic arms as well as within lifting equipment deployed to move materials around a facility.

The key to all force measurement testing is accuracy and reliability of data, as well as selecting the right type of force sensor for the specific product being testing.

Types of Product Testing Applications Using Interface Measurement Solutions

  • Weighing Applications: Interface miniature load cells are often for product testing to measure the exact weight of consumer products, such as food, beverages, and electronics. This information is critical R&D, as well on the production line and to meet the exact product specifications. Our load cells help to ensure that the products are not underweight or overweight, and comply with regulations. Read more about Load Cells for Smarter and More Efficient Weighing
  • Material Applications: Interface LowProfile load cells are often found in product testing labs to assess the strength of materials used in consumer products such as plastics, metals, and mixtures of composites. The measurements gathered during the product testing safeguards consumers and confirms the product’s durability. Read Interface Solutions for Material Testing Engineers
  • Force Applications: Interface load cells, torque transducers, and instrumentation are used in complete test systems that examine the usability of products such as exercise equipment, appliances and electronics. The data acquired in shear, tensile and force testing is important to understand if the product meets design specifications, is easy to use and does not require excessive force to work.
  • Safety Applications: One of the most important product use cases for Interface measurement solutions is to test the safety of products such as furniture, toys and automobile features. It is a requirement for every maker of products that are not hazardous and will not cause injury to consumers. Read Interface Solutions for Safety and Regulation Testing and Monitoring

To give you a better idea of how our load cells and instrumentation are utilized in distinct types of product tests, we have included a few application notes below outlining real-world examples of force testing projects.

Bicycle Helmet Safety and Impact Product Testing

A high production bicycle manufacturing facility set up a product testing lab to measure the impact of the safety of their helmets when dropped from different heights onto a flat surface such as an anvil. This test is necessary to ensure consumer safety and that the products are made with the highest quality materials to protect the rider. Interface suggests installing the 1101 Compression-Only Ultra Precision LowProfile® Load Cellat the bottom of an anvil. The bike helmet is then dropped from multiple heights and at multiple angles onto the anvil. The measurements from impact are then recorded and logged throughout the product testing using Interface’s INF-USB3 Universal Serial Bus Single Channel PC Interface Module with supplied software. Every design or material change runs through the same rigorous testing protocols using these high accuracy measurement solutions.  Read CPG Bike Helmet Impact Test

Product Weighing of Consumer Water Bottles

A manufacturer of glass bottled water needs to dispense the exact amount of fluid into each bottle and then weigh the water bottle to ensure it is at the labeled weight on the product packaging. The product testing of the manufacturing equipment is used to minimize waste and to meet the weight requirements to ensure consumer satisfaction. Interface suggests using the MBP Miniature Beam Load Cell and attaching it under a plate or platform where the water bottle is placed on while it is being filled with fluids. The force weight is measured by the MBP Miniature Beam Load Cell and connected to the 9870 High Speed High Performance TEDS Ready Indicator where results are captured, displayed, and logged for quality control. Read CPG Water Bottle Dispensing and Weighing

Product Test Lab Conducts High Volume Tensile Force Testing

A product test lab is constantly requested to conduct a series of tensile force tests on different samples and materials until failure. These materials include plastic, steel, or woven fabric, and are utilized in the design and manufacturing of several consumer products. The lab professionals want to measure tensile strength, yield strength, and yield stress for every submitted product material sample. For the tensile test stand, we recommend using Interface’s 1200 Standard Precision LowProfile™ Load Cell be installed into the test frame. As the tensile test is conducted, force results captured by the load cell and extensometer are synchronized through the SI-USB4 4 Channel USB Interface Module. The results are displayed on the customer’s computer with supplied software. Learn more by reading Material Tensile Testing.

Interface’s high precision force sensor technologies used in robotics have revolutionized the manufacturing of consumer products. With automated assembly lines and robotic arms taking charge, these machines work efficiently to mass-produce consumer goods. Quality control of all the products we provide you for testing is one of the main focuses of Interface, as we want to keep your customers happy and safe.

Interface’s experienced team are renowned specialists in force, torque and weight measurement manufacturing and technology. Our depth of knowledge and wide range of capabilities create custom solutions of all types, whether special transducers made to your exact specifications or complete customized sensor, instrumentation, and software systems. We collaborate with you to ensure the product specifications you need are designed to match your precise requirements.

ADDITIONAL RESOURCES

Introducing the Interface Consumer Product Testing Case Study

Interface Solutions for Consumer Products

Force Measurement is Reducing Waste and Automating the Consumer Packaging Industry

Applications for Consumer Products and Packaging

Load Cells for Consumer Product Applications

Why Product Design Houses Choose Interface

Testing Labs Choose Interface High Accuracy Products

Interface Solutions for Material Testing Engineers

How Load Cells Are Transforming the Construction Industry

/0 Comments/in /by

The construction industry is one the most universal, growing, and dangerous industries in the world. Interface force measurement solutions are used for all types of construction applications from bridge and high-rise building projects to foundation load tests and structural monitoring. Our sensors and instrumentation are used in crane and heavy lifting operations, material testing and equipment calibration.

Accuracy and quality of all measurement products used for design, testing, monitoring, and equipment evaluations is imperative in protecting the project’s assets and workers. One of the leading causes of construction accidents is overloading equipment. When equipment is overloaded, it can fail, leading to serious injuries. It is essential to utilize high accuracy load cell technologies to measure the amount of force being applied to construction equipment.

Interface force measurement solutions can help to prevent overloading accidents by using the measurement data to ensure that equipment is not being extended beyond its safety capabilities. Force measurement solutions can also be used to monitor the performance of equipment and identify potential problems before they lead to an accident.

Interface offers a wide variety of sensor solutions for construction equipment and material testing. Our load cells offer precise measurements of applied forces, furnishing essential data regarding the structural response under various load circumstances. This data plays a critical role in evaluating structural integrity, detecting potential vulnerabilities, and optimizing design to guarantee the safety and dependability of infrastructure.

Interface force measurement solutions can help to improve efficiency and productivity in the construction industry in all areas including engineering, testing and maintenance. By monitoring the performance of equipment, construction companies can identify areas where they can improve efficiency.

It is common to find Interface load cells, including load pins, load shackles, miniature and even jumbo load cells in use for various forms of construction projects, equipment and tools. These products, as well as torque transducers, instrumentation and wireless systems are frequently used in the testing and monitoring of the machinery, rigging and lifting devices, gear, and heavy duty vehicles that are used in various stages of building.

Interface provides various sensors for a range of construction use cases around the world, including:

  • Residential and commercial buildings
  • Infrastructure programs
  • Industrial construction
  • Material testing machines
  • Civil engineering projects
  • Mining and tunneling
  • Environmental remediation
  • Heavy equipment manufacturing
  • Vehicle OEMS
  • Cranes and lifting equipment


Construction is an ever-present and ever-growing industry estimated to reach nearly $13T in global spending with broad and diverse use of measurement solutions. From single dwelling construction tools to heavy machines used to move concrete slabs, measurement is fundamental in construction. Included below we have provided a few examples of how our sensors are being used in construction.

Construction Reach Stacker

A reach stacker is a vehicle used in construction site to lift, move, and stack heavy containers. A force monitoring system was needed to ensure the safety of surrounding personnel, and if the reach stacker can lift heavy loads. Interface’s WTSLP Wireless Stainless Steel Load Pins were installed into the corners of the lifting mechanism of the reach stacker, where heavy loaded containers are lifted and moved. The force results were then wirelessly transmitted to both the WTS-BS-1-HS Wireless Handheld Display for Single Transmitters, or directly to the customer’s PC with the WTS-BS-6 Wireless Telemetry Dongle Base Station. Using this solution, the customer was able to monitor their reach stacker with Interface’s Wireless Telemetry System and ensure its ability to lift heavy loads on site.

Bridge Construction Wind Monitoring

Wind monitoring is a necessary operation during bridge constructions. Strong winds can destroy a bridge under construction since it is a work in progress with poor structural design. Monitoring these winds in real time is much more accurate than using predicted weather forecasts. Interface suggested installing the WTS-WSS Wireless Wind Speed Transmitter Module on the highest point of construction, such as a crane. Wind speed results were wirelessly transmitted to the customer’s PC through WTS-BS-4 Wireless Base Station with USB Interface in Industrial Enclosure. It was transmitted to the WTS-BS-1 Wireless Handheld Display for Unlimited Transmitters Data can be displayed, logged, and graphed with supplied Log100 software. Interface’s WTS-WSS Wireless Wind Speed Transmitter Module combined with Interface’s Wireless Telemetry System was perfect to monitor the wind speed in real-time during the bridge’s construction.

Metal Bending Force Material Testing for Construction

A construction material supplier wanted to know how much force it takes to bend different grades of steel metal used for building and infrastructure projects. They use their metal bending machine to create different metal hardware and wanted to record the amounts of force it takes to bend the metal used for their projects. Interface suggested using a wireless method, so cables do not interfere with the machine. The WTS 1200 Standard Precision LowProfile® Wireless Load Cell was attached to the head of the hydraulic operated steel bender. Results were wirelessly transmit to the customers PC through the WTS-BS-4 Wireless Base Station with USB Interface, where data can be displayed, logged, and graphed with supplied Log100 software. Using this solution, the customer was able to record the force results of his metal bending machine with Interface’s Wireless Telemetry System.

Interface is adept at providing solutions suited for use in construction projects, equipment and ongoing monitoring programs.  If you have questions about what products are suited for your specific project, equipment or testing programs, contact us. We are here to help.

ADDITIONAL RESOURCES

Force Measurement Solutions for the Construction Industry

Interface Solutions for Heavy Equipment

Gantry Crane Weighing

Lifting Heavy Objects

Rigging Engineers Choose Interface Measurement Solutions

Innovative Interface Lifting Solutions

Modernizing Infrastructure with Interface Sensor Technologies

Interface Solutions for Structural Testing

Why Civil Engineers Prefer Interface Products

Innovative Interface Load Pin Applications





Why Product Design Houses Choose Interface

/0 Comments/in /by

When people think of force measurement, they often think that it is a tool for testing products. However, load cells, torque transducers and multi-axis sensors also play a fundamental role throughout the entire product design process. In fact, many products today actually design force sensors directly into products.

Product design houses are companies that fulfill outsourced design work for a variety of industries. These specialized design houses are contracted to develop and bring products to life.

A product design house primarily focuses on designing physical products or tangible goods. The services they offer to product makers, engineers, manufacturers, and innovators typically involve the entire product development lifecycle, from conceptualization and design to prototyping and manufacturing.

Due to our experience and expertise across multiple industries, Interface collaborates with product design houses in identifying the right sensors and systems to use during different stages of the design process. Whether it is for accurately measuring forces for impact and fatigue testing, identifying precise weights for packaging, modeling consumer usability, or testing material strength, Interface products are chosen by design houses based on their range of capabilities, accuracy, versatility and quality.

How Product Design Houses Use Interface Products

  • Concept Development and Prototyping: Product design houses often use Interface product design files when refining their initial product ideas or creating new concepts. When the products move into physical modeling, Interface products are used for testing and validation at this early stage.
  • Industrial Design: Industrial designers use Interface load cells and other sensor products for measuring functionality of the product.
  • Design Validation and Testing: Conducting tests and simulations to validate the product’s performance, durability, and safety are the number one reason why design houses utilize Interface measurement solutions. Design houses put sensor technologies into products to provide force data for user feedback, to optimize performance, safeguard consumers and activate components.
  • Mechanical Engineering: The mechanical engineering team of a design house will connect with Interface when they are working on the technical phases of product design. Our products are used to help ensure the final product can be fabricated efficiently, performs consistently, and meets applicable safety standards.
  • Materials and Manufacturing: Experts at design houses that are versed in materials science and manufacturing processes will consult with Interface in finding measurement solutions that can access and validate material testing and production systems. Within the manufacturing realm, these devices are employed in quality control processes to ensure consistent product standards.
  • Packaging: If a product has packaging that must meet durability, temperature, pressure or fatigue requirements, Interface will provide sensors and instrumentation for design testing.
  • Regulatory Compliance and Certification Support: For products subject to regulatory standards, design houses utilize high accuracy measurement solutions in creating specifications, reporting, and compliance requirements before moving to market.

These services can vary from one product design house to another, and some design houses may specialize in specific industries or types of products.

Product design houses leverage Interface load cells across various industries to measure and monitor forces and weights with precision. For example, in medical device development, Interface miniature load cells are used for patient lifts, ensuring secure and accurate weight measurements.

Whether used in material testing, robotics, or agricultural machinery, load cells enable product design houses to create innovative solutions tailored to specific industry requirements, enhancing overall product performance and reliability. Here are a few examples of house product designers use force measurement solutions during the design phase.

Furniture Fatigue Cycle Testing

To meet safety protocols in relation to the manufacturing of various furniture products, fatigue testing, shock testing, and proof testing must be rigorously performed before diffusion into the marketplace, and into the homes of consumers. Force testing of furniture products is critical in determining the posted max loads to protect manufacturers from liability due to damage that might result from the misuse of those products and overloading. Using Interface’s SSMF Fatigue Rated S-Type Load Cell along with Interface’s 9890 Strain Gage, Load Cell, & mV/V Indicator provided a solution that measures the force being applied in fatigue cycle testing of a furniture product, in this case, testing the rocking mechanism in an office chair. Throughout the testing phase, changes were made to the design to improve the safety and life of the furniture, ensuring product quality and protecting the manufacturer from future liability.

Self-Checkout Kiosk Functional Testing

To assess the design of self-checkout kiosks, part of the development cycle is to ensure the weighing feature is functioning properly with the right amount of sensitivity when customers want to weigh products like fruits or vegetables. The designers also needed a system that measures the force it takes for the self-checkout kiosk to activate a response for consumers. Interface suggested installing SSB Load Beam Load Cells under the plate where items are weighed. When connected to the WTS-AM-1E Wireless Strain Bridge Transmitter Module, force results are wirelessly transmitted to the WTS-BS-6 Wireless Telemetry Dongle Base Station on the customer’s PC. Data can be logged and graphed with included Log100 software. Interface’s wireless force system successfully measured the amount of force it took for the self-checkout kiosk to react and ensure it is functioning properly.



Design of a Prosthetic Foot

In the design of this medical device, the product designers need to know how the foot responds as it is loaded during different stances. To measure this, Interface’s 3A120 3-Axis Load Cell was installed between the leg socket and the prosthetic foot. The 3A120 was then connected to the BSC4D Multi-Channel Bridge Amplifier and Computer Interface Module. Using this solution, data was logged for X, Y, and Z axis. The design house was able to review the results and identify premature flat foot and dead spots during foot’s production for consumer use. They utilized this vital information to make improvements to the design.

Interface works with design houses and product design engineers across the continuum of a product’s development through go-to-market. We supply standard measurement sensors like our load cells, along with custom solutions that are uniquely engineered for a particular use case.

ADDITIONAL RESOURCES

Why Product Design Engineers Choose Interface

Interface Solutions for Consumer Products

Introducing the Interface Consumer Product Testing Case Study

Interface Mini Load Cells Growing in Product Use and Testing

Rod End Load Cells 101

/0 Comments/in , /by

Rod end load cells are designed to measure the tension and compression forces applied to a rod or similar structure. This type of load cell consists of a rod with a threaded connector. The load cell’s strain gage measures the deformation caused by the applied force. As the force is applied to the rod, it deforms slightly, causing a change in the electrical resistance of the strain gage.

To provide a complete analysis of the forces being applied to the structure, rod end load cells are often used in pairs, with one load cell measuring tension and the other measuring compression.

Interface Rod End Load Cells utilize proprietary temperature compensated strain gages for high-accuracy measurement. For example, our popular REC Rod End Load Cell is fatigue rated and designed to go up to 100,000,000+ fully reversed cycles which makes them ideal for test article failure tests. Our REC models are resistant to off-axis and impact loading with performance to .04%. They are environmentally sealed and made of stainless steel. They are easy to integrate in actuators.

Rod end load cells are commonly found in test labs and used in industrial environments, mechanical systems, and testing machines. They are adaptable and reliable force measurement devices utilized for applications in various industries.

Common Rod End Load Cell Use Cases

  • Material Testing: Rod end load cells are widely used in material testing applications, such as tensile testing, compression testing, and fatigue testing. They help measure the applied forces accurately and provide data for analyzing material properties, structural integrity, and performance.
  • Machine Force Monitoring: Rod end load cells are used in industrial machinery to monitor and control forces applied to rods, shafts, or other structural components. They help ensure that the machinery operates within safe load limits, preventing overloading and potential failures.
  • Hydraulic and Pneumatic Systems: Rod end load cells are employed in hydraulic and pneumatic systems to measure the tension or compression forces experienced by cylinders, pistons, or actuators. This enables accurate force control and monitoring for proper system use.
  • Robotics and Industrial Automation: Rod end load cells are integrated into robotic systems to measure the forces exerted by robotic arms or grippers. This allows for precise force control, feedback, and safety features in tasks such as assembly, material handling, and force-sensitive operations.
  • Calibration and Test Lab Equipment: Rod end load cells are utilized in calibration and testing equipment, such as force testers and dynamometers. They provide reliable and traceable force measurements, ensuring the accuracy and calibration of the testing instruments.
  • Aerospace and Automotive Industries: Rod end load cells find application in both aerospace and automotive industries for various purposes, including component testing, structural analysis, quality control, and safety testing. There are many use cases to rod end load cells for multiple industries, as found in our application solutions.
  • Research and Development: Rod end load cells are used in research and development activities across different fields, enabling precise force measurements for studying material behavior, product development, and prototype testing.

Drone Fireworks Rod End Load Cell Application

Drone fireworks have become increasingly popular in recent years. During drone firework and light shows, drones are equipped with LED lights, flying in synchronized patterns to create displays in the night sky.  Four rod end styled Interface WMC Sealed Stainless Steel Miniature Load Cells  are installed to the necessary propeller motors measure the attached LED lights. Each are connected to a WTS-AM-1E Wireless Strain Bridge Transmitter Modules. The WMC’s measure the weight of the LED lights to monitor weight shifting or any uneven weight distributions. Data results are wirelessly transmitted through the WTS-BS-4 Wireless Base Station.

Interface offers a wide range of rod end load cells. The following highlights our standard models for this type of load cell. Customization is an option if a rod end load cell is needed to be designed into machines or used as a component within a specific product.

Interface Standard Rod End Load Cells

REC Rod End Load Cell stainless steel mini with capacities from 1K to 50K lbf (5 kN to 220 kN).

WMC Rod End Load Cell industrial grade rod end type has capacities 15K to 200K lbf (65 kN to 900 kN).

WMC Sealed Stainless Steel Miniature Load Cell environmentally sealed in capacities from 5 to 500 lbf (22 to 2200 N). Submersible versions also available.

WMC Sealed High Capacity Stainless Steel Miniature Load Cell ranging from 1K lbf to 10K lbf (5 kN to 45 kN). Submersible versions also available.

WMCP Overload Protected Stainless Steel Miniature Load Cell With Male Threads is an excellent safeguard in rugged applications with capacities 1.1 to 2.2 lbf (500 to 1000 gmf).

WMCFP Overload Protected Sealed Stainless Steel Miniature Load Cell With Female Threads in 1.1 to 2.2 lbf (500 to 1000 gmf) capacities are stainless steel, sealed, and environmentally protected.

WMCF Miniature Sealed Stainless Steel Load Cell is an industrial design with capacities from 5 to 10 lbf with female threads.

MTFS Miniature Tension Force Load Cell is a small sized tension load cell available in capacity ranges from 1 kN to 100 kN (224.8 to 22.5K lbf).

NEW! ITCA Tension And Compression Load Cell is ideal for measuring both tensile and compressive forces 2.2K lbf to 330.6K lbf (1 MT to 150 MT). The standard metric threads at each end of the load cell are designed to accept standard spherical seating rod-end bearings. Customization is available.

Benefits of Interface Rod End Load Cells

#1 High accuracy: Our rod end load cells provide high accuracy in measuring the tension or compression force applied to a rod or similar structure. They are capable of measuring very small changes in force, making them suitable for precise measurement requirements and applications.

#2 Range of measurement and dimensions: Interface rod end load cells are available in a wide range of measurement capacities and compact size making them suitable for use in a variety of industrial and mechanical applications.

#3 Durability: Rod end load cells are designed to withstand harsh environments, high loads, and repetitive use. They are made from ruggedized materials, stainless steel or aluminum, so that can withstand exposure to moisture, dust, and other environmental factors.

#4 Versatility: Rod end load cells can be used in a variety of applications including material testing and manufacturing processes. They can be easily integrated into existing actuation systems and are compatible with a variety of instrumentation and control systems.

Rod end load cells, as highlighted in our recent Testing Lab Essentials Webinar, are used in applications that involve the measurement of tension or compression force on a rod or similar structure, such as in material testing or in the calibration of testing machines.

Testing Labs Choose Interface High Accuracy Products

/0 Comments/in /by

Specialists focused on testing applications work in a variety of testing lab environments. In each lab, technicians rely on the tools to collect and report on data that is used to make products safer, guarantee performance, ensure quality, and to meet the strict industry standards and requirements. Accuracy in testing data is dependent on the precision measurement devices and instrumentation used to capture the results.

We supply lab engineers with high-accuracy sensor technologies used to complete rigid test requirements. Interface is the top provider of test and measurement products used for structural and material testing, static and fatigue testing, torsion effects, tension tests, calibration testing, and environmental testing. Read more in Types of Force Measurement Tests 101.

Our standard high precision load cells, torque transducers, multi-axis sensors, and instrumentation are used on every continent for T&M. Based on our quality and performance, we are the chosen supplier to calibration and testing labs. We see our products used today for continuous improvement programs, advancements in smart manufacturing and new product designs.

If it must be measured, Interface has a solution. Our products are designed for small and large testing facilities, including calibration-grade load cells, load frames and test stands, along with data acquisition systems. The wide variety of our force measurement solutions designed for testing labs means we play a role in every industry that is making a physical product and the test labs that validates the products performance.

Testing Labs and Types of Testing Using Interface Solutions

General Automotive Test Labs:

  • Component and Sub-Component Level Testing
  • Suspension Testing
  • EV Battery Testing

Automotive Driveline Testing:

  • Engine Performance and Durability Tests
  • Motor Efficiency Testing
  • Power Analyzation (Electric)

Aerospace Testing:

  • Full Scale Structural Static Testing
  • Component Fatigue Test
  • High Precision Thrust Testing
  • Simulators
  • Wind Tunnel Testing

Geotechnical and Civil Testing

  • Concrete or Asphalt Core Testing
  • Soils Testing

General Structural and Component Testing

  • General Push and Pull
  • Design Proofing
  • Life Cycle Fatigue Validation

Medical Device Testing:

  • Prototyping
  • PPAP Validation and FDA Certification
  • Device Lifecycle Testing

Consumer Product Testing Labs:

  • Design Validation
  • Material Testing
  • Fatigue and Failure Tests

Interface recently highlighted testing lab applications in our Test Lab Essentials Webinar. Here you can see the lab use cases and products as they are reviewed by our applications experts.

Each of these testing types requires different force testing equipment, and our experts work directly with testing lab professionals to determine the products or systems they need for single and ongoing test requirements.

As testing technologies becomes increasingly complex, off-the-shelf products may not meet the needs of every Interface customer. We lend engineers expertise in test and measurement to support unique and custom requirements to get the right sensor, instrument, and system in place.

Since our first load cells were designed five decades ago, we have built millions upon millions of load cells and torque transducers used in testing labs around the world. Our products are built to withstand the rigor and requirements needed for high quality and reliable data collection in test and measurement. Our test customers depend on us for proving accuracy, consistency, and reliability in performance.

ADDITIONAL RESOURCES

Interface and Testing Lab Applications

Testing Lab Essentials Webinar

Engine Dynamometer App Note

Consumer Product Testing Case Study

Interface Solutions for Safety and Regulation Testing and Monitoring

Metrologists and Calibration Technicians 101

Motor Test Stand

GS-SYS04 Gold Standard® Portable E4 Machine Calibration System

Electric Vehicle Structural Battery Testing

Furniture Fatigue Cycle Testing App Note

Regular Calibration Service Maintains Load Cell Accuracy



Tension Load Cells 101

/0 Comments/in , /by

A tension load cell is a type of force sensor used to measure tensile forces in materials, structures, or machines. It is used to measure the maximum load that a material can support without fracture when being pulled or stretched under the applied load. A strain gage manufactured inside the load cell sensor measures the deformation and converts it into an electrical signal.

The main difference between a tension load cell and a compression load cell is the direction in which they measure the force being pushed or pulled. Though most Interface high performance load cells are designed for both tension and compression, specific load cells are calibrated in tension only to measure forces that pull or stretch a structure. As the load cell stretches, it measures the resulting force.

It is customary practice for most labs to use tension and compression load cells, then determine its specific tension use case based on the requirements of a test project or product design. Tension and compression load cells are easily used for tension only but will measure both. Load cells can be calibrated in either tension or compression, and both tension and compression. The combined is more economical for test labs and most use cases.

Benefits of Tension Load Cells

Load cells that measure tension are preferred over other types of load cells when the force being measured is tensile in nature. They are accurate, reliable, and can be calibrated to suit different applications and environments. Additionally, they are easy to use and require minimal maintenance.

Accurate measurement of tensile forces: Tension-only load cells are specifically designed to measure tensile forces accurately, without being influenced by compressive or bending forces. This makes them ideal for applications where the force being measured is purely tensile, such as in the testing of cables, wires, ropes, or chains used in lifting applications and equipment. Interface Tension Links are preferred for these types of lifting and weighing use cases.

High sensitivity and resolution: Tension-only load cells typically have high sensitivity and resolution, meaning they can detect slight changes in the applied force. This makes them useful in applications where precise measurements are required, such as in the testing of materials with low tensile strength.

Easy installation: Tension-only load cells are typically easy to install and use, requiring minimal setup time and equipment. They are often designed with attachment points or hooks for attaching to the load being measured, which makes them convenient for use in the field or in a testing lab.

Durability and reliability: Tension-only load cells are often constructed from durable materials, such as stainless steel, which makes them resistant to corrosion and wear over time. They are also designed to provide reliable and consistent measurements, ensuring accuracy and consistency in test results.

Tension Load Cell Applications

Tension load cells are standard and their versatility in application use makes them popular in test and measurement. Tension load cells are used for test and measurement industry applications including in manufacturing, automotive, energy, aerospace, and infrastructure. For example, the transportation sector uses load cells to measure the tension in cables, wires, ropes, and chains. They are used in a diverse range of testing equipment to measure the strength and durability of materials. They are designed to provide accurate and reliable measurements of tensile loads and can be calibrated to suit different applications and environments.

Tension load cells are commonly used in applications for material testing to evaluate the tensile strength and elasticity of varied materials, such as metals, plastics, and composites. Tension testing is a valuable tool in materials science and engineering, as it provides valuable information about the tensile properties of a material. Some examples of tension testing include:

  • Determining the strength of a material: Tension testing provides a way to measure the maximum load a material can withstand before it breaks or fails. This information is crucial in determining the strength of a material and its suitability for different applications.
  • Understanding the ductility of a material: Tension testing can also be used to measure the amount of deformation a material can undergo before it breaks. This information is important in determining the ductility of a material and its ability to withstand bending and stretching without breaking.
  • Identifying defects or weaknesses in a material: Tension testing can help identify defects or weaknesses in a material that may cause it to fail under stress. By subjecting a material to increasing levels of tension, engineers can pinpoint the point at which the material fails and investigate the cause of the failure.
  • Comparing the properties of varied materials: Tension testing can also be used to compare the tensile properties of different materials. This information is useful in selecting the best material for a specific application and designing structures that can withstand the required loads.

Tensile Testing For 3D Materials

A customer wants to conduct a tensile force test on different 3D printing materials until failure. These different 3D printing materials being tested included PLA, PETG and ASA to see how they performed. The customer wanted to test the materials quality, strength, ductility, and stiffness. Interface recommended using our 1200 Standard Precision LowProfile™ Load Cell be installed into the customer’s test frame. The tensile test is conducted, and force results captured by the load cell are synced through the INF-USB3 Universal Serial Bus Single Channel PC Interface Module. These results can be displayed on the customer’s computer with supplied software.

Tension load cells are used in structural testing to measure the tension in structures used in construction, aerospace, maritime, and infrastructure. For example, tension load cells are commonly used for bridges, buildings, and towers, to ensure they can withstand the forces in their design and application.

Tension load cells are often used within manufacturing machines and equipment for monitoring and real-time force measurement. For example, in a facility they are used to measure the tension in cables or wires during production, to ensure they meet the required specifications and are safe for use.

Research and development for all types of applications need to assess the tensile properties of new materials or structures, to assess their suitability for different applications, from medical devices to product simulations.

If your next project needs an accurate tension load cell, contact our application experts to see which model best fits your exact requirements.

ADDITIONAL RESOURCES

Interface Solutions for Material Testing Engineers

Tensile Testing for 3D Materials App Note

Testing Lab Essentials Webinar

Bolt Tension Monitoring

Mooring Line Tension Testing App Note

Tension Links 101
