Data Acquisition Systems 101
Engineers and testing professionals use data acquisition systems to enable smart decisions. The data retrieved through DAQ systems empower users to identify points of failure, optimize performance, and create efficiencies in products and processes.
When it comes to measuring force, the accuracy and reliability of the sensor is a critical component to receiving quality data. The data acquired from measurement devices, including load cells, torque transducers, and other types of force sensors, is valuable for product development, research, and robust testing to ensure performance and durability of all types of innovations. Ultimately, utilizing precision-based data provides enhanced control and response for all types of applications and use cases. Interface provides a wide range of data acquisition instrumentation that is easily paired with our force measurement products.
By definition, a data acquisition system is a collection of components used to acquire data via analog signals and converting them to digital form for storage, research, and analysis. Data acquisition systems, also called DAQ systems, typically are made up of sensors, signal conditioners, converters, plus computer hardware and software for logging and analysis. Interface experts are available to help pair the transducers with the right instrumentation.
The data acquired through the measurement device is only useful if it is logged for analysis and traceability. This is where instrumentation, in particular DAQ systems come into play, in not only transferring data, but also obtaining the right type of data in a format and data transfer method that works with existing user systems.
Data acquisition that utilizes analog output has long been the standard in the industry. As new requirements for use cases and applications grow, test and measurement professionals and engineers find these systems advantageous because of the lower cost, easy integration, and scalability. They also like the advantage of daisy-chaining multiple sensors together on a single cable run to maximize the amount of data through single tests. More data improves the quality of analysis and monitoring.
Advancements in sensor technologies coincide with growing demands for digitalization and to gather more testing data. This is seen using multi-axis sensors, along with requirements for multi-channel acquisition that can integrate into existing systems already designed with specific digital connections and protocols.
In addition to improving speed of data output, acquisition systems offer an abundance of value-added benefits. This is primarily due to the digital signal, as they are less susceptible to noise and are more secure. The systems also typically have built in error detection. Digital signals are best for transmitting signals across longer distances or when you need to allow for simultaneous multi-directional transmissions. Many people like the ease of integration, both into existing networks as well as with other testing devices.
Data acquisition systems and accessories come in many shapes and sizes, wired and wireless and there are also a handful of different software options in different systems. All these various products such as digital instruments, input and output modules, cables, monitors, and accessories. Interface offers a range of DAQ products, including full systems including the sensors.
Interface Complete Data Acquisition Systems
BlueDAQ Data QA Pack
Force sensors can easily connect via the BlueDAQ Family Data AQ Pack for fast and accurate data acquisition. This solution provides a convenient way to view the test results from transducers including single axis, dual axis, 3-axis, and 6-axis multi-axis sensors. Check out our BX8-HD44 BlueDAQ Series Data Acquisition System for Multi-Axis Sensors with Lab Enclosure.
T-USB-VS Rotary Torque Transducer Data AQ Pack
Connecting dynamic torque transducers to the T-USB Rotary Torque Transducer Data Acquisition Pack will provide you with convenient way to view the test results for your torque transducers that have internal USB functionality.
WTS Wireless Data AQ Pack
Utilizing the popular WTS Wireless Data Acquisition Pack provides convenient wireless communication with speeds up to 200 samples per second. Learn more in our Interface Wireless Telemetry System Review. See the complete line Interface WTS here.
DIG-USB PC Interface Module Data AQ Pack
Interface’s DIG-USB Data Acquisition Pack enables a straightforward way to view the test results our load cells or torque transducers. Check out the popular DIG-USB Output Module and the DIG-USB-F Fast USB Output Module.
9325 Portable Display Data AQ Pack
Interface’s 9325 Data Acquisition Pack makes your system portable. The 9325 allows simple display of strain bridge based measurements such as load cells, torque transducers, and other mV/V output transducers with sensitivity up to +/-1 V/V.
INF-USB-VS3 PC Interface Module Data AQ Pack
Our INF-USB-VS3 Data Acquisition Pack connects Interface mV/V load cells or torque transducers to provide real-time data analysis. Here is more information about the INF-USB3 Universal Serial Bus Single Channel PC Interface Module.
Interface Data Acquisition Systems are modular. We offer the complete system, including enclosures, along with single components to complete a system. Consult with our application engineers to learn what system would be best for your test and measurement programs.
