Measurement Technologies for Boats, Yachts and Watercraft

/0 Comments/in /by

Interface has been a long-term supplier of force and torque measurement solutions for the maritime industry. This explains how our products play a big role in a wide variety of waterborne vessels, maintenance and safety equipment, and offshore products found at docks and in the open water. We have captured some of these specific use cases of how our sensor technologies and instrumentation are used in the building and maintenance of boats, yachts, and watercraft of all sizes.

Our load cells and sensors work well in vehicles that are used in water. For example, we offer technologies that can wirelessly transmit data underwater and in harsh weather conditions, making them perfect for a variety machines used in water. These specialized load cells operate in underwater submersions at different capacities, and reliably relay information to those at the surface level for accurate sensor readings. Interface load cells of various designs can regulate harsh maritime situations in use cases such as underwater tension lines, underwater oil drilling, as well as storm and tsunami monitoring. Read more about offshore and near shore solutions here.

The applications we are highlighting below provide real-world examples of force measurement products used in boat, yacht and watercraft related products. The uses of force measurement range from testing fishing wire to yacht rigging inspection. Here’s a closer look:

Wireless Telemetry System (WTS) for Yacht Rigging Inspection

For a customer who wants to have a complete yacht rigging inspection to make sure the mast, still lines, and all movable hoisting lines are functional, Interface offers our robust WTS products line. These various wireless sensor technologies and components are designed for use to meet the proper specifications for sailing, test the tension of the forestay, shroud, and backstay cables, and to test the tension of the movable lines when sailing.

With Interface’s WTSSHK-B Wireless Crosby™ Bow Load Shackle paired with the WTS-BS-1 Wireless Handheld Display for Unlimited Transmitters, the customer can switch and view between multiple shackles being tested. The WTS-BS-4 USB Industrial Base Station can also be attached to the customer’s computer to display real-time measurements from the shackles and log data. With this solution, the user is able to conduct both a running and standing rigging inspections of their ship or vessel, and determine if all lines were functional and met safety standards. Read the entire WTS solutions used on this yacht here.

Commercial Fishing Wire Rope Testing

When a commercial fishing owner wanted to measure the force tension of the wire fishing rope connected to the fishing cage or net when their vessel goes to catch and ensure the wire rope is strong enough and safe enough to hold the maximum capacity of fish caught in the cage or net, they can turn to Interface.

Using a WTSTL Wireless Tension Link Load Cell attached between the end of the cable, and the end that hooks onto the fishing net, the tension link will be able to measure the forces of the full net of fish, or a heavy load at maximum capacities. The data information can be transmitted to both the WTS-BS-1-HS Handheld Display for Single Transmitters, or to the customers computer laptop through the WTS-BS-4 USB Industrial Base Station. Utilizing this solution, the customer was able to determine if the fishing cable on their vessel was strong enough to hold the fish cage or net at maximum capacity when out catching.

Mooring Line Tension Testing

Due to changing environmental conditions, mooring cable lines undergo wear and tear. A customer wanted to ensure all mooring lines for ships and large commercial vessels are securely docked at the same loading tension, so that they do not risk the mooring lines to break or cause damage.

We provided a WTSTL Lightweight Wireless Tension Link, which can be attached to each mooring cable in use. Results are sent to the customers through the WTS-BS-4 USB Industrial Base Station when connected to the customer’s supplied PC computer/Laptop. Data can also be transmitted to the WTS-BS-1-HA Handheld Display for Multiple Transmitters, giving the customer the option to view multiple mooring cable line tensions. The customer was able to verify the tensions to multiple mooring cable lines. Thus, resulting in the security of their ship being safely docked.

If you’re interested in learning more about our maritime solutions, call 480-948-5555 to contact an application engineer about your project requirements.

Load Shackles 101

/0 Comments/in , /by

A load shackle is a u-shaped, load-bearing connecting device designed to be used with a removable pin. Load shackles can be used in a number of different rigging and load securement applications to provide sensor technologies in the connection of different types of lifting slings, chains or ropes to an object or to each other.  A load shackle is essentially the installation of a load monitoring pin into the shackle body allowing you to replace existing rigging hardware with a load cell for force measurement and weighing data.

Load shackles are rugged in design and are used to provide accurate and reliable measurement of tensile loads, as well as support applications for harsh and challenging environments. The industries that most regularly take advantage of our load shackles include industrial, aerospace and defense, agriculture, and construction. Applications for lifting, moving and weighing objects can be monitored as well as optimized for performance using load shackles. They are often designed into engineered structures or for use with cranes, winches or other robust lifting mechanisms.

Interface offers a wide variety of load shackle designs for different environments and force measurement needs, ranging from 2.2K to 2205K lbf. Our load shackles come in both cabled and wireless, as well as environmental resistance options including flameproof and IP67. Visit our overview here.

Load shackles come in many standard shapes and sizes, including customization options to meet a specific design or use requirement. Some of our shackles are exclusively designed to meet the needs of applications in hazardous environments like the oil and gas industry, or marine industry where they’ll be submerged in water during testing and for continuous use, or in areas with high heat and flames. Some of our most popular load shackles are listed below:

WTSSHK-B Wireless Crosby™ Bow Load Shackle  – Suitable for use in a wide range of industrial and marine weighing applications, these load shackles are robust, reliable and easy to install. The unique telemetry housing is manufactured from tough high-performance polyamide resin making it strong yet light, resulting in a better-balanced load shackle when compared to others available on the market.

ISHK-B Bow Type Crosby™ Cabled Load Shackle – The Interface range of ISHK-B load shackles are designed for lifting and weighing in rugged or harsh environments, including submersible applications. The shackle pins are forged from high tensile stainless steel to 6.5 MT (14.3K lbf) and high tensile carbon steel from 9.5 MT (20.9K lbf), and are machined to an exacting specification. The basic shackle uses the Crosby G2130 (1 to 25 MT / 2.2K to 55.1K lbf), G2140 (40 to 120 MT / 88.2K to 265K lbf) and GN Rope H10 (150 to 1K MT / 331K to 2205K lbf).

Flame Proof Bow Type Crosby™ Cabled Load Shackle – The Interface range of flameproof load shackles is designed for lifting and weighing in rugged or harsh environments, and also meet the requirements for operation in Zone 1 and 2 hazardous areas. The shackle pins are forged from high tensile stainless steel and are machined to an exacting specification. The basic shackle uses the Crosby G2130 (1 to 25MT or 2.2K to 55.1K lbf) and G2140 (40 to 400MT or 88.2K to 882K lbf) series.

Load Shackle Application:

Load shackles are commonly used in the construction industry to measure heavy machinery. For cranes outfitted with a lifting attachment such as a claw, a tension sensing load shackle is used on the pulley mechanism to measure the weight lifted by the crane. The tension sensor can provide real-time data to the construction crew to help monitor the lifting process and provide the operator with the information necessary to refrain from lifting weights that are too heavy for the crane to handle. If the claw arm lifts more than the crane is able to withstand, the attachment could break off, or worse, the crane could topple over.

In a recent example, Interface’s customer used a WTSSHK-B Wireless Load Shackle connected to load-bearing strings and a WTS-BS-1-HA Wireless Handheld Indicator to gather data. The customer was able to successfully lift and read the weight (wirelessly) on a handheld display while the material was being relocated.

Learn more in this product video

To learn more about our wide variety of load shackles and their many applications, please contact our application specialists today.  You can see all of Interface’s Load Pins, Load Shackles and Tension Links here.

This post is part of our Interface 101 series where we provide a basic overview of the wide variety of product lines we offer here at Interface. In this series, we explain our force measurement product line and its benefits and then provide a few examples of our product’s in real-world situations. Here are some of our other popular 101 posts.
