Interface New Product Releases Fall 2023

/0 Comments/in /by

Interface has added new load cells and instrumentation to our expansive measurement solutions catalog. The Fall 2023 new product releases include several standard products, along with options for engineered to order and custom solutions.

The Interface product line is one of the most extensive in the world of test and measurement. We want to make it easier to navigate models based on your requirements. Interface has a series of guides that can help you choosing the right load cells, miniature load cells, torque transducers, couplings, DAQ systems and instrumentation. Visit our online product selection tools.

ICPA STAINLESS STEEL COMPRESSION LOAD CELL

Interface’s new ICPA compression load cells are built to exacting standards with submersible versions available. The standard product is durable, versatile and easy to integrate into existing machines and equipment. There are several options available in standard capacities and dimensions including domed top (supplied with or without a loading cap), integral carry handles, mounting base, integral connectors and internal analog/digital signal amplifiers. The standard product is constructed from stainless steel and IP-rated. It can be customized to specific requirements. Download the ICPA datasheet.

Primary ICPA features and benefits:

  • Ranges: 2 to 1000 MT (4.4K to 2204K lbf)
  • Stainless steel construction
  • Environmentally sealed to IP67
  • Submersible version available upon request
  • Options: Special electrical connections, integral signal conditioning
  • Model options: Domed top and loading cap, mounting base and handles
  • TEDS (Transducer Electronic Data Sheet) option
  • Custom ranges and sizes available

BSC4D-BT PORTABLE 4-CHANNEL BLUETOOTH DATA LOGGER

Interface’s new BSC4D-BT Portable 4-Channel Bluetooth Data Logger is designed for wireless measurement data acquisition with wire strain gage sensors. It is also suitable for connecting strain gage full bridges and half bridges. For quarter bridges (120 Ohm, 350 Ohm, and 1000 Ohm), there is a connection option in three-wire technology. Data is transmitted by radio via the Bluetooth Standard 2.0+EDR with serial port profile (SPP). The range is 20-meters in buildings or up to 100 m when in direct line of sight. Current consumption is less than 150 mA. When not in use, current consumption is under 10 mA. A battery can be charged at 5V supply voltage via an integrated charge regulator. Download the BSC4D-BT datasheet.

Primary BSC4D-BT Portable 4-Channel Bluetooth Data Logger:

  • IP65 housing with integrated battery
  • Long distance Bluetooth interface
  • 4 channels
  • Inputs for mV/V / 0 – 5 V / PT1000
  • Measuring ranges 2 mV / V / 10 mV / V, mV/V quarter and half-full bridge options
  • 4 digital inputs and outputs
  • Data rate up to 450 Hz

BSC1-HD SINGLE CHANNEL PC INTERFACE MODULE WITH ANALOG OUTPUT

The new Interface BSC1-HD Single Channel PC Interface Module with Analog Output is a single channel signal conditioner with both digital and analog input and output. The BSC1-HD also has optional RS232, RS422, and CANopen protocols.  Download the BSC1-HD datasheet.

Primary BSC1-HD Single Channel Module with Analog Output features and benefits:

  • 24-bit
  • mV/V input (+/-10mV/V) and Analog Input (0-10VDC)
  • Analog Output (standard +/-5V)
  • LCD Display (to 200,000 digits display resolution)
  • Compatible with Interface BlueDAQ Software
  • RS232, RS422 or Optional – CANopen
  • Trigger input
  • Options include: 4-20mA Output, 0-10V Output, CANopen and +/-5V Output

Amplifier channel has a fixed gain settings and is not adjustable for specific load cell output signals. Thus, the amplifier output will typically 0.5V per mV/V of load cell output.

SGA AC/DC POWERED SIGNAL CONDITIONER

Interface versatile SGA Signal Conditioner is now offered as a series. There are eight configurations available for this popular instrumentation product. The SGA features user selectable outputs of ±10V, ±5V, 0-10V, 0-5V, 0-20mA and 4-20ma. This product is DC or AC powered with switch selectable filters from 1 to 5kHz and is packaged in a sealed ABS enclosure. This product supports shunt calibration and a wide range of gain settings. To review all the SGA options, go here.

NEW! 8 SGA Configuration Models Now Available

  1. SGA: Amplifier with no power cord
  2. SGA-WPC: Amplifier with power cord
  3. SGA-RSC: Amplifier with Remote Shunt Calibration option and no power cord
  4. SGA-RSC-WPC: Amplifier with Remote Shunt Calibration option and includes a power cord
  5. SGA-DCI: SGA-D with Isolated Power Supply option and no power cord (DC Power Only). Also allows for 9-36 VDC Supply
  6. SGA-BCM: Amplifier with Bridge Completion option and no power cord
  7. SGA-BCM-WPC: Amplifier with Bridge Completion option and includes power cord
  8. SGA-DRMK: DIN Rail Mounting Kit option for model SGA.

Primary and Optional SGA features and benefits:

  • User selectable analog output ±10V, ±5V, 0-10V, 0-5V, 0-20 mA, 4-20 mA
  • 110 VAC, 220 VAC OR 18-24 VDC power
  • Switch selectable filtering 1 Hz to 5 kHz
  • Single channel powers up to 4 transducers
  • Selectable full scale input range 0.06 to 30 mV/V
  • Switch selectable offset ±70% FS
  • Sealed ABS enclosure
  • Model SGA-RSC can remotely activate a shunt calibration by closing a relay on the related RSC module
  • Model SGA-DCI offers with isolated 12/24V power supply
  • Model SGA-BCM has a bridge completion module for both quarter and half bridges
  • Option: AC Power Cord (PWRCRD-SGA-110)
  • Option: DIN Rail for mounting available by request

4850 BATTERY POWERED BLUETOOTH WEIGHT INDICATOR

The new Interface 4850 Bluetooth Digital Indicator is a wireless capable digital indicator housed in a stainless steel NEMA 4X enclosure. It comes with a large 0.8” LCD display for easy readout of up to 50,000 display divisions and can drive up to 8-350Ω load cells. All setup parameters may be entered via the front panel keys. A full duplex RS-232 port or optional Bluetooth module can transmit data on demand or continuously to match the input requirements of a wide variety of peripheral devices including printers, remote displays and computers. This is a high quality instrumentation solution with Bluetooth capabilities. Review the 4850 weight indicator specifications here.

Primary 4850 Digital Indicator features and benefits:

  • Full front panel configuration
  • Drives up to eight 350 ω load cells
  • Full front panel calibration, multipoint cal – linearization
  • Units- lb, kg, g, and oz
  • Stainless steel swivel stands and enclosure
  • Easy to read LCD display with up to 50,000 graduations
  • Power requirements – 4-14 vdc
  • Battery is 6-volt 3 ah internal rechargeable lead acid
  • Options for analog output: 16-Bit, 0-5 VDC, 4-20 mA and built-in relays (6V or 12V)

Beyond our standard load cells, transducers, and instrumentation, we also offer options for engineered to order, OEM sensors, and complete custom systems. If you need any assistance in selecting the right products for your test and measurement applications, please contact us.  If you have questions about these new products, capacities, capabilities, or specifications, we are here to help.

ADDITIONAL PRODUCT RESOURCES

Demystifying Specifications Webinar

/0 Comments/in /by

Interface’s technical force measurement webinar Demystifying Specifications details descriptions, terms, values and parameters found in product datasheets for load cells, torque transducers, instrumentation and specialty products. Learn from our experts what specifications need critical review, recommendations based on product categories, and the insider point of view on what is most important in terms of specifications for different use cases and tests.

Read more

Interface Manufacturing and Production Solutions

/0 Comments/in , /by

Force measurement is integral to advanced manufacturing systems, especially when it comes to how this technology is used in production lines. Force sensors are utilized in both testing and monitoring of a wide variety of machines to ensure accuracy and repeatability throughout the production line. These sensors are also used by production line engineers in the design and development of systems used to ensure accuracy in measurements of force, weight, compression, and torque as products and components move throughout the line, including distribution.

Watch how Interface provided an industrial automation solution for small pallets used in the distribution of manufactured products. In the video, we highlight a request for a pallet weighing solution to use in their warehouse to monitor their products and goods 24/7. They need to use sensor technologies to verify if any products are missing based on the weight, and able to determine pricing for their goods based on the weight.

Interface works with a large range of manufacturers and equipment makers to improve quality and productivity by supplying high-performance measurement solutions. From using miniature load cells to apply the exact force needed to press a brand identity onto fragile consumable, to using multi-axis sensors for verifying performance data when making intricately machined parts, Interface products are commonplace in manufacturing and production.

In fact, Interface offers manufacturing and production standard off-the-shelf, engineered to order and complete OEM solutions including load cells, instrumentation and weighing devices. Our products provide the quality and durability necessary within industrial environments. In addition, we can customize the majority of our products to fit unique and evolving needs as sensor technologies like robotics and advanced manufacturing devices are integrated into production lines.

Load cells are frequently used in monitoring equipment. Interface can custom design force sensors to be installed directly into product for monitoring certain forces in real-time, including for use in industrial automation robotics. This is particularly popular in manufacturing because you can monitor equipment to understand when it may be out of alignment and needs to come down for repair, rather than risking a disruption in production. This is particularly important in automated production lines because it gives engineers and extra set of eyes on machines and improves efficiency overall by reducing downtime.

One of the unique use cases for load cells used for monitoring is in weighing materials held on pillow blocks bearings. Pillow block bearings, or similarly constructed bearing, are used to carry rolled materials or conveyor belt. Interface’s new PBLC1 Pillow Block Load Bearing Load Cell can be placed underneath the bearing to measure the weight of whatever material is being held up. These types of bearing are often found in machines with similar type of bearing are used on conveyor belts moving products down a production line.

Manufacturing Feed Roller System

A customer has a feed roller system and needs to monitor the forces of both ends of the rollers, in order to maintain a constant straight feed. They would also prefer a wireless system. Interface came to the rescue with our Pillow Block Load Cells and WTS Wireless Telemetry Systems. Interface suggests installing two PBLC Pillow Block Load Cells at both ends of the bottom roller to measure the forces being applied. The forces are measured when connected to WTS-AM-1E Wireless Strain Bridge Transmitter Module. The data is then transmitted wirelessly to the WTS-BS-6 Wireless Telemetry Dongle Base Station and the WTS-BS-1-HA Wireless Handheld Display for multiple transmitters, where data can be displayed, graphed, and logged on the customer’s computer.

Production Line Conveyor Belt Adhesion Test

A customer wants to test the adhesion strength in between the many layers and textiles of a conveyor belt. They want to conduct a separation test from the rubber of the conveyor belt from the other layers. They would also like a wireless solution. Interface’s SMA Miniature S-Type Load Cell is installed in the customer’s tensile test load frame, where it measures the forces applied as the test is conducted and the layers are pulled and separated. When connected to the WTS-AM-1F Wireless Strain Bridge Transmitter Module, the data is wirelessly transmitted to WTS-BS-5 Wireless Analog Output Receiver Module with nV output. The WTS-BS-5 can then connect to the 9330 Battery Powered High Speed Data Logging Indicator to display, graph, and log the data with supplied BlueDAQ software.

Industrial Automation Robotic Arm for Production

A manufacturer of a robot arm needs to measure force and torque when the arm picks up and places objects. The manufacturer needs a wireless system to accomplish this in order to log the measurement results. Interface supplied Model 6A40A 6-Axis Load Cell with Model BX8-HD44 Data Acquisition/Amplifier.

Interface force sensors can be used in a number of ways within the manufacturing industry across a variety of applications for the test and monitoring of machines and production lines.

ADDITIONAL RESOURCES

Force Measurement Solutions for Advanced Manufacturing Robotics

Robotics and Automation are Changing Modern Manufacturing at Interface

Vision Sensor Technology Increases Production Reliability

Industrial Automation Brochure

Weighing Solutions Brochure

Smart Pallet Solution

Interface Solutions for Safety and Regulation Testing and Monitoring

Interface Solutions for Production Line Engineers

/0 Comments/in /by

Due to the influence of IoT, AI and big data, the role of production line engineer has become far more critical as manufacturers demand peak efficiency. These engineers need to stay current in automation technologies used to design, build, and monitor a production line for the benefits of decreasing speed to market, lowering costs, and improving outputs at the highest quality standards.

Among the many software and hardware solutions these individuals must also understand connected sensors are among the most important. Sensors are the nervous system of an automated production line, telling which machines must perform certain tasks, when, and how. They are a source for smart factories and smart manufacturing.

Sensors modernize manufacturing, assembly, and production lines by enabling real-time monitoring and control of the production process.

Measurement solutions provide accurate data on production parameters such as temperature, speed, pressure, force, and other relevant variables, which can then be used to optimize the production process, detect, and resolve problems in real-time, and prevent downtime. Additionally, sensors can be integrated into industrial IoT systems to provide valuable insights and analytics that can help manufacturers make data-driven decisions.

One of the sensor types that play a key role in these automated production lines are force sensors. Force sensors can be used by production line engineers across several different facets of an automated line. When designing a manufacturing line, there are quite a few factors that go into the full system. This includes process monitoring, quality control, predictive maintenance, energy management and inventory management. Force sensors play a role in each of these types of data points and processes.

For instance, a production line engineer can install sensors onto a machine that outputs a great deal of torque and monitor that torque to ensure the components creating that force are running smoothly, or if there are certain indicators that say it needs to be pulled off the line briefly for maintenance. When products on the line trigger certain force parameters such as weight, this can also tell the automated production line it is ready for the next stop in the process. Production line engineers design these lines around the sensing capabilities available and connected force sensing products have made a major difference in helping things become more efficient.

There is another automated process that also requires force sensors that is used as part of a manufacturing line, or as a standalone system – robotics. Production line engineers are doing a great deal of research and development into robotics to automate process that are repetitive, or far too delicate for human hands. Force sensors, in this use case, are used in both the testing of robotics to ensure accuracy or developed into the robotics to monitor certain functions over time.

Robotics can improve assembly and production processes, leading to higher efficiency, improved quality, and reduced costs. As technology continues to advance, the use of robotics by production line engineers in assembly and production is likely to become even more widespread.

Here at Interface, we have a great deal of experience in developing solutions for industrial automation and manufacturing lines. We have developed a few application notes to outline how production line engineers use our sensor solutions and force measurement products.

6-Axis Force Plate Robotic Arm

A customer wanted to measure the reaction forces of their robotic arm for safety purposes. The reaction loads occur at the robotic arm’s base; therefore, they needed a force measurement system at the base of the robotic arm. Interface suggested using their force plate option to install at the base of the robotic arm. Four 3-Axis Force Load Cells were installed between two force plates, then installed at the bottom of the arm. This creates one large 6-Axis Force Plate. The sensors force data is recorded and displayed through the two BX8 Multi-Channel Bridge Amplifier and Data Acquisition Systems onto the customer’s PC or laptop. Interface’s 6-Axis Force Plate was able to successfully measure the reaction forces of the customer’s robotic arm. Read more here.

Press Load Monitoring

Press forming is a method to deform varied materials. For instance, materials such as steel can be bent, stretched, or formed into shapes. A force measurement solution is required to monitor the forces being applied by the press forming machine. This ensures quality control and traceability during the production process. For large press forming machines, Interface recommends installing the 1000 High-Capacity Fatigue-Rated LowProfile™ Load Cell. When the material is placed under the punch plate to form a shape, the force applied is measured by the 1000 Series Load Cell. The force results captured is sent to the INF-USB3 Universal Serial Bus Single Channel PC Interface Module, where results can be graphed and logged on the customer’s PC with provided software. Interface’s force measurement products and instrumentation accurately monitored and logged the force results of the press force machine, ensuring zero-error production performance. Learn more about this application here.

Snack Weighing and Packaging Machine

A snack manufacturing brand wanted to weigh the amount of their snacks that is automatically dispersed into the bags during the packaging process. In this case, they wanted to weigh their potato chips being packaged. The company also wanted to ensure the potato chips are at the exact weight needed due to regulatory standards to be distributed out to consumers in the public. Interface’s solution was to use multiple SPI Platform Scale Load Cells, and install it to the potato multi-head weigher and packaging machine. The SPI Platform Scale Load cells were installed inside of the mount that attaches the head weigher to the packaging machine. Force results from the potato chips were read by the load cells and sent to the ISG Isolated DIN Rail Mount Signal Conditioner, where the customer is able to control the automated production from their command center. Using this solution, the customer was able to determine the weight of the potato chips being distributed into their bags with highly accurate results. They also were able to control the automated production process with the provided instrumentation. They will use this same weighing method for other snacks that need to be packaged. Read about the solution here.

Production line engineers turn to Interface due to our quality, accuracy, and reliability. Our products are used to test, monitor in real time, and created automated processes within a manufacturing line. As automation and robotics grow, you will continue to see new applications for sensors in this sector.

ADDITIONAL RESOURCES

IoT Industrial Robotic Arm App Note

Quality Engineers Require Accurate Force Measurement Solutions

Vision Sensor Technology Increases Production Reliability

Force Measurement Solutions for Advanced Manufacturing Robotics

Robotics and Automation are Changing Modern Manufacturing at Interface

Industrial-Automation-Brochure-1



Interface Best Selling Products in 2022

/0 Comments/in /by

Interface sells tens of thousands of force measurement products every year. As a manufacturer of the world’s highest quality load cells, it is no surprise that our top selling products are the precision load cells that we engineer and build in our US headquarters.

We have been manufacturing high-accuracy load cells in all kinds of configurations and capacities for 55 years. With growing demands for complete systems, instrumentation, and specialty sensors, we continue to add new products and expand our line of standard and engineered to order offerings. In 2022, we again have grown our Interface Product Catalog significantly.

As is tradition, we want to share our best selling products and what garnered the most views by product categories and models. The criteria for what constitute a best seller can vary depending on the industry and the specific market. A best seller is typically considered to be a product that is in high demand and is selling well consistently over a period.  In general, Interface best sellers are products that have a strong record of success and are highly sought after by our customers year-over-year.

In our annual recap, we do not include products that are custom OEM, as these unique sensors are built for a particular use case.  Interface defines a best seller as a product model series that ranks among the top sellers in our entire force measurement solutions line.

2022 Interface Best Selling Products

Load Cells

Mini Load Cells

Torque Transducers

Specialty Products

Instrumentation

What captured the greatest interest in 2022 by users and researchers of force measurement solutions? We have cataloged what is capturing the greatest interest from you and your peers. The following are Interface products most frequently viewed this past year by test and measurement professionals, engineers, product designers, and manufacturers around the world.

Interface Top 10 Product Categories Ranked by Online Interest in 2022

  1. Load Cells
  2. Torque Transducers
  3. Instrumentation
  4. Tension and Compression Load Cells
  5. Accessories
  6. Mini Load Cells
  7. Multi-Axis Sensors
  8. Compression-Only Load Cells
  9. Load Button Load Cells
  10. LowProfile Load Cells

Interface Products Most Viewed Online in 2022

Summary Catalog 8 Pages

Trending at Interface

/0 Comments/in /by

As in years past, the Interface team looks at trends in what products caught the greatest interest of our customers, along with those that are top sellers throughout the year.

We’ve gathered our key findings based on searches and purchases by industry-leading engineers, product designers, testing labs, manufacturers and T&M pros using Interface solutions. Here is a summary of the trends over the past 12 months.

TRENDING PRODUCT CATEGORES IN 2020

#1 LOAD CELLS – There is no surprise that topping the 2020 list is what we are best known for, our precision load cells. When quality, accuracy, and reliability matter Interface Models 1000, 1100, 1500 and 1600 in various capacities ranked highest in interest. What’s the top seller? The 1200 Standard Precision LowProfile® Load Cell ranks number one, with the 1000 Fatigue Rated Load Cell in second place.

#2 TORQUE TRANSDUCERS – Torque is definitely trending, taking the number two spot. Hot picks are the MRT Miniature Flange Style Reaction Torque Transducer, T8, T25 and our proprietary AxialTQ. Read Torque 101 here.

#3 INSTRUMENTATION – One of the most popular adds to any purchase is instrumentation like the DMA2, SGA, 9320 or 9840.

#4 MULTI-AXIS SENSORS – Watch Dimensions of Multi-Axis Sensors to learn more about why multi-axis is trending, including the popular 3AXX 3-Axis Force Load Cell.

#5 MINIATURE LOAD CELLS – Interface’s expertise for engineering force measurement applies to a wide range of capacities and sizes, including Interface Mini best sellers: SSM and SSM2 Sealed S-Type Load Cells, SM-S Type and SMT Miniature Load Cells followed closely by MB, MBP, WMC Stainless Steel Miniature Load Cell and SMTM models.

#6 CALIBRATION SYSTEMS – These Interface systems are growing in popularity. Read why here.

#7 CALIBRATION SERVICES AND REPAIR ­­­– Our customers can depend on us for our services. Click here to request service today.

#8 DIGITAL INSTRUMENTATION – Interface has expanded our line of digital instrumentation based on growing demands. See what’s hot here, like our BX8.

#9 LOAD PINS, LOAD SHACKLES AND TENSION LINKS – A new entry to the trends list this year based on the high interest for these specialty products including the wireless options.

#10 LOAD BUTTON LOAD CELLS – Robotics, automation and testing in confined and compact spaces has raised greater interest in highly-accurate load button load cells, including our new ConvexBT and our popular LBM and LBS models.

Based on feedback and our analysis of trends, we know that getting exactly what you want is as important as the product category selection. Engineered to order, custom solutions and complete systems are rapidly growing in demand as Interface customers evaluate ways to embed sensor technologies into products or utilize advances sensor technologies, along with wireless and Bluetooth communication capabilities.

Take a look at why Interface Engineered to Order Solutions continue to be in high demand by helping our customers get exactly what they need.

Interface has played an important role in shaping the test and measurement industry and though we know our standard catalog is robust, we are always here to get the exact product for our customer’s exact requirements. How can we help you get what you want in 2021 and beyond?  Reach out and let’s start the conversation now.

Introduction to Interface Application Notes

/0 Comments/in /by

Interface has a long history of sharing valuable resources to help our fellow colleagues and customers with various use cases for test and measurement applications. Whether it be with our in-depth technical library, the Interface Load Cell Field Guide, free access to design files for our breadth of products, or industry case studies highlighting how our customers use Interface products. Access to all of these resources is available on Interface’s website www.interfaceforce.com.

A frequently visited area of these online resources is our Interface Application Notes archive. These resourceful explainers are of interest to engineers, new product designers, metrology and engineering students, as well as T&M industry professionals.

Interface created a large collection of App Notes to showcase how Interface load cells, torque transducers, accessories and instrumentation are used by OEMs and for various test and measurement projects across all types of industries.

Each Interface App Note has the following details:

  • Name of the App Note with Primary Product
  • Industry
  • Summary of the Application Use Case Need or Challenge
  • Interface Solution
  • Results
  • Materials
  • How it Works
  • Visual Representation of the Application

Interface App Notes are great conversation starters. They help to showcase how various Interface products and systems are used across all types of industries including medical, automotive, energy, industrial automation, consumer products testing, and aerospace. Additionally, several application notes highlight specific test and measurement lab projects.

Interface Top 10 Application Notes

  1. Race Car Suspension Testing
  2. Aircraft Wing Testing
  3. Surgical Stapler Force Verification
  4. Drone Parcel Delivery
  5. Bluetooth Brake Pedal
  6. Medical Bag Weighing
  7. Seat Testing Machine
  8. Industrial Automation Friction Testing
  9. Vascular Clamp Testing
  10. Bolt Fastening and Torque

We have many more for you to check out. Visit the entire library of Interface Application Notes here. We are adding new application notes on a regular basis, so check back frequently.

Be sure to check out the full line of Interface solutions here. If you have questions or would like to talk with our application engineering experts, drop us a note or give us a call.

Load Cells for Consumer Product Applications

/0 Comments/in /by

Typically, when engineers talk about load cells and their multitude of uses, it is assumed the applications are large-scale industrial projects like airplanes, rockets, and automobiles. However, did you know Interface load cells are regularly used for research and development (R&D), manufacturing, and end-of-line testing for countless consumer products?

Force is one of the most critical pieces of measurement in product development. This is especially true for consumer products that we interact with every day. Load cells are the tools that ensure products feel, handle and react the way they should in a consumer’s hand.

Here are a few examples showcasing how load cells touch almost everything the consumer touches.

A perfect example of a consumer product where force measurement plays a critical role in human interaction is in the abundance of numerous touch screens. Load cells are used in the R&D process to measure the accuracy, pressure, and sensitivity of the touch screen consumer interacts with on a minute-by-minute basis. The little things we don’t think about when using a tablet or smartphone, such as the smooth feeling of scrolling through social media pages, is possible because of testing using a load cell.

Another common consumer application type of load cells being used to improve product feedback and interaction is with simulation programs. High-end flight simulators often use load cells to measure the force of haptic feedback on the joysticks or chair when interacting with a flight simulator. The feeling of drag or rough winds a pilot experiences in a simulation is measured and refined for accuracy using a load cell.

Load cells are also an integral part of the manufacturing process for consumer goods. If you’ve ever seen a piece of candy with a logo stamped on it, chances are high a load cell was involved in determining the level of force to apply an exact brand stamp. Load cells are used on the stamping machine to ensure the right amount of force is used to apply the logo without crushing the candy.

In the food and drug industries, load cells are used in manufacturing facilities and on a wide variety of packaging machines. They are used for ultrasonic welding, which is the sealing process for plastic, paper or fabric shopping bags, garbage bags, and diapers. Potato chip assembly lines use load cells to weigh the bags as they fill them with chips to know when to stop and move on to the next bag. And the same stamping process used for candy in applying labels is used on pills.

Companies also incorporate load cells in end-of-line product testing. Furniture often goes through rigorous testing to ensure reliability. The furniture has various loads applied to it to confirm it can hold heavier weights over time, the furniture can also be bent and flexed to check the quality of the materials.  To reduce waste and ensure product quality, many consumer bottles use a torque transducer for end-of-line testing to test the proper cap implementation.

Batteries are another consumer product that goes through R&D and end of line testing to measure the force needed to damage the casing.  This is used to eliminate poorly designed and assembled batteries, as the acid inside can do immense harm if a child or adult is able to accidentally crush one.

Force measurement is also something that plays a role directly in the products we use. For instance, scales we use to weigh ourselves, food, and more, have load cells in them. Racecar gaming brake pedals are another example. High-end racing simulators need their brake pedal to be very accurate at measuring the amount of force applied to it to react as a real car would. Load cells are implemented in the base to provide accurate force readouts to the simulator in real-time.

Most products we all interact with every day have had some force testing or are currently using a sensor to manage its use and reliability.  Other consumer products that use Interface load cells, in all capacities and models, include treadmills, skis, bicycles, coffee makers, gaming brake pedals, boats, golf balls, desk drawers, guitars and robotic vacuums. And that is just to name a few.

Load cells and other force measurement tools like torque transducers are an integral part of developing, testing, and manufacturing reliable and accurate consumer goods. Think about this the next time you are handling your smartphone or carrying in groceries from the store. None of it would be possible without the use of force measurement equipment.

Contributor:  Kim Williams, Business Development Manager at Interface

Interface Holiday Wish List

/0 Comments/in /by

As we turn the corner on another great year at Interface, it comes with grace and gratitude to everyone that played part in our 2019 story. And with that, we wish everyone a very joyous holiday season.

To our customers, we appreciate your loyalty and trust. We know you rely on us to accomplish big things and ensure what you do is safe, reliable, durable and accurate. To our team members, our partners, our representatives, and distributors around the world, our success is your success. You are the faces of Interface and everything you do makes a difference.

Reflecting on the past year, we thought we would share what we know best. That’s what you like best!  We compiled a quick list of the top 10 products we sold this year to give you an idea of what’s hot and trending in force measurement.

Here are the items that were on the wish lists of engineers, testers, and lab technicians around the world by quantity of most frequently purchased.  By the way, this list excludes our calibration services and the unique solutions we design for our OEM customers.

BEST SELLING FORCE MEASUREMENT PRODUCTS OF 2019

  1. Mini Compression Load Button Load Cell – This top-selling Interface LBM load cell is available in capacities from 25 to 50K lbf, is environmentally-sealed and made of stainless steel.
  2. LW General Purpose Load Washer Load Cell – A big seller, the Interface Load Washer is available with a wide selection of OD, ID, heights and in various combinations. It is also made of stainless steel.
  3. SGA AC/DC Powered Signal Conditioner – Our SGA Signal Conditioner is a very popular instrumentation device that provides user-selectable analog output ±10V, ±5V, 0-10V, 0-5V, 0-20mA and 4-20mA as a single channel that powers up to four transducers.
  4. SM S-Type Load Cell – This high-demand S-Type Load Cell is for high-performance tension and compression testing. It utilizes proprietary Interface temperature compensated strain gages.
  5. 1200 Standard Precision LowProfile® Load Cell – The 1200 LowProfile Load Cell model series outsells all others. It is eccentric load compensated and has low deflection and shunt calibration. It can be used in tension and compression testing.
  6. T4 Standard Precision Shaft Style Rotary Torque Transducer – With more than 50 torque models available, this particular Interface T4 Torque Shaft Style Rotary Transducer has capacities from 0.1 Nm to 1K Nm (0.88 lbf-in to 8.85K lbf-in). It has contactless data transmission with digital electronics with on-shaft design.
  7. MB Mini Beam Load Cell – Our low capacity mini load cell has Interface temperature compensated strain gages with performance to 0.03%, low deflection and low height with 1-inch max.
  8. 1100 Ultra Precision LowProfile® Load Cell – The Interface model 1100, with a range of capacities, is selected among our best low profile load cells. It has very low nonlinearity, hysteresis, eccentric load sensitivity, and temperature sensitivity.
  9. 9320 Battery Powered Portable Load Cell Indicator – A very popular instrument, Interface’s 9320 Indicator is handheld and features two independently scalable ranges, peak and valley monitoring, display hold, mV/V calibration, and a power save feature. Typical battery life exceeds 40 hours of continuous use (450 hours in power-save mode), and is TEDS plug and play compliant.
  10. WTS 1200 Standard Precision LowProfile® Wireless Load Cell – Our most popular wireless load cell, often purchased as part of the entire Wireless Telemetry System (WTS), is compact in size and has capacities from 300 to 100K lbf (1.5 to 450 kN), with performance to 0.0425% and a 2.4 GHZ transceiver.

With thousands of products, we certainly have a diverse and broad selection of products and force measurement solutions. We didn’t include all our custom and OEM solutions or calibration services in our best selling list.

As we head into 2020, we look forward to working together to supporting your latest projects and unique applications, as well as helping to achieve your goals in the new decade!  We appreciate you and thank you for your business!

Happy Holidays from your Interface Team!
