Interface Calibration 101

Calibration of force and torque sensors is critical to receiving accurate data from measurement testing.  Calibration is the comparison of the instruments output against the known standard of measurement. For a load cell, it is the comparison of the load cell output against the standard test loads.

The calibration ensures the sensor is performing accurately and set for ideal output based on the capacity and configuration of the design. A standard calibration tests repeatability and linearity, which are both used to determine the accuracy. Calibration tests are run to identify any potential measurement errors caused by zero offset, non-linearity, hysteresis, non-repeatability, and shifts from zero.

The team of calibration experts at Interface are specifically trained to provide this specialized service as part of our quality and lab standard requirements of operations. Interface is ISO/IEC 17025:2017 and A2LA Accredited for Torque and Force Calibration in accordance with the recognized International Standard ISO/IEC 17025:2017.

Interface certifies all our load cells with accredited calibration before releasing the product for shipment. Certificate information includes tabulated measurement variables data, zero balance, computed nonlinearity and hysteresis, and traceability statements. We are often recognized as the most complete calibration certification in the industry

In a recent customer survey, we found that one of the most important roles that Interface force measurement solutions play is for our calibration services. This is due to the accuracy, reliability, and dependability over long periods of time of the load cells we manufacture and service.

Why Calibrate?

Calibration is important based on many different factors, including continued performance, safety, and compliance with ISO or industry specific standards. Interface’s standard recommended calibration interval is to recalibrate every 12 months. The frequency of calibrations should be determined by the following use case factors that may affect measurement accuracy:

  • Measurement quality and allowable tolerance range
  • Level of stress to which the equipment is subjected
  • Stability of past calibrations
  • Required measuring accuracy
  • Quality assurance requirements

Interface Calibration Services

Interface provides calibration and repair services on load cells and torque transducers, including devices made by other sensor manufacturers. In fact, Interface performs more than 100,000 calibrations every year. This includes new products as well as devices sent to Interface for recalibration and repair. Repairs include a complete evaluation of the device prior to repair and calibration upon completion.

In addition, here are some other benefits for choosing Interface as your calibration services partner:

  • ISO 17025 Accredited
  • Scheduled Repairs for Ongoing Inventory Management
  • Custom Calibration Services
  • RMA Tracking and Permanent Archive of Test Data
  • NMI Certified Gold and Platinum Standard Reference Load Cells
  • Interface Gold Standard Calibration Software Used for Data Collection and Analysis
  • Full-Service Machine Shop for any Mechanical Requirements

Calibration Services Process

The Interface calibration team consists of a team of professionals dedicated to an optimized calibration and repair process for timely management of our customer’s requests. We begin the calibration service process with our technical services group who manage the request and RMA process, in addition to evaluation and troubleshooting.

We evaluate all products at our headquarters with our team of experts. The sensor goes through a thorough inspection process to identify any necessary repairs and to ensure device is in working condition in preparation of a calibration. This includes an electrical test. Based on the extensive evaluation, if the device is found to be unrepairable, there is no charge. We also will work to find a replacement unit. All work beyond the evaluation is sent to the customer for approval.

The final step in our calibration services process is the actual calibration. Our calibration team is considered the most experienced in the industry due to the sheer volume of work product they calibrate every day.  Interface also is heavily invested in conducting all our calibrations with the most advanced equipment, including our proprietary Gold Standard® and Platinum Standard® systems. These machines ensure that the transducers are calibrated to the most accurate ability possible before returning to the customer.

Even the most high-end manufactured load cells and finely tuned components endure accuracy degradation over continued use. To ensure your sensors are always ready for peak performance, check out our calibration services request form. We also provide a full range of calibration grade products for metrology and testing labs. You can also give us a call at 480-948-5555 to discuss your specific calibration needs.



Engaging Interface Calibration and Repair Services Expertise

A high-quality load cell is a critical piece of technology for the design and testing of products throughout various, highly regulated industries including medical, aerospace and defense, automotive, and industrial automation. To get the most out of a load cell, just like anything else, you need to understand how to care for and maintain it. A poorly maintained load cell can lead to inaccurate data and poor performance.

Interface Calibration and Repair Services provide a valuable function for our customers in recalibration and technical support for the thousands of products manufactured by the leader in force measurement.  When cared for properly, a load cell should to be calibrated once a year or at least every two years under regular use. There are also certain circumstances where a load cell is damaged in use and needs immediate repair. Interface can handle calibration and repair of any load cell on the market, whether we build it or not.

A key differentiator for Interface is the fact that our calibration lab is ISO 17025 and A2LA accredited. These accreditations are typically for major calibration labs, not in a manufacturer’s facilities like ours. Our deep expertise in the development of load cells allows us to provide the highest quality calibration and repair services on the market because we know the product inside and out.

Interface’s Industry Leading Calibration and Repair Process

The Interface calibration team consists of 10 individuals dedicated to an optimized calibration and repair process that gets our customer’s load cells in and out as quickly as possible. The process begins with the front-end team, who manages the customer’s request, goes through the RMA process, and troubleshoots any additional concerns with the customer.

Once we review the product in-house at our Arizona headquarters, the load cell goes through a thorough inspection process to identify any necessary repairs and to ensure the load cell is in working condition for calibration. This includes an electrical test to evaluate if the load cell is in proper condition to calibrate. It’s also important to note that if the load cell can’t be repaired, there is no charge to the customer, and we work to find a replacement unit. The customer also approves any repairs that are necessary before work begins.

The final step in the process is the actual calibration. Our calibration team has many years of experience and know load cells inside and out. We also work with the most advanced equipment, including our proprietary Gold Standard® and Platinum Standard® systems. These devices ensure that the load cells are calibrated to the most accurate capability possible before returning to the customer. More information about Interface Calibration Systems can be found in our Calibration Systems 101 blog here.

Our commitment to building quality calibration systems is evident by the customers who also use them to do calibration in-house. In fact, in nearly every major manufacturing testing lab, you will find an Interface Gold Standard Calibration System and Gold or Platinum Standard Load Cells. This is because our customers are working on some of the most advanced hardware in their respective industries and fields. Engineers and testing labs trust Interface for accuracy, performance and quality.

Interface customers not only need to ensure their measurements are as accurate as possible to avoid product failure, they also need to prove the accuracy of their testing equipment for those products to pass inspection and make it to the market. We provide both our expert calibration services in our calibration lab, or through high-quality, high-reliability systems available that we build for our customers.

Interface Calibration and Repair Services

  • 50+ Years of Calibration Experience
  • Calibration of All Manufacturers Load Cells
  • 100,000+ Calibrations Performed Annually
  • Custom Calibrations
  • IPerform Service Software for RMA, Tracking and Permanent Archive of Test Data
  • NMI Certified Gold and Platinum Standard Reference Load Cells
  • Interface Gold Standard Calibration Software Used for Data Collection and Analysis
  • Full-Service Machine Shop for Mechanical Requirements

Force Capabilities:

  • NIST/NMI Traceable Calibration
  • 2 gf – 1 Million lbf Calibration Capability
  • (9) Hydraulic & (5) Deadweight Test Stands to Support Your Calibration Requirements

Torque Capabilities:

  • 0.022 – 100K in-lbf Capacities
  • NIST Traceable to 2.2K in-lbf
  • NMI Traceable 2.2K – 100K in-lbf

Interface calibration and repair services are designed with the customer in mind. Our process is fast, reliable and will ensure premium accuracy for our customer’s most complex and high-quality data-dependent design and test projects. Our team of experts work with every customer to ensure personalized world-class service.  It starts with engagement, how can we help?

For more information on Interface calibration and repair services, please visit /calibration-repair/.

Click here to schedule a service today.

Contributor:  Chris Brandenburg, Technical Services Manager at Interface

Calibration for Crane Scale and Dynamometer Applications

Interface is well-known for excelling at calibration services for load cells. Did you know this service excellence extends to dynamometers and crane scales?

Interface can calibrate dynamometers and crane scales with capacities of 100,000 pounds of force or more. This family of devices is often found in industrial, commercial, energy, military, and aerospace industry applications.

Crane scales are used as overhead weighing solutions ranging from light to heavy capacities and are normally placed in the load string of a crane. The devices provide crane overload protection, as well as information about the handling of bulk material.  Some models are equipped with wireless communications to allow monitoring from safe distances at multiple locations.

Dynamometers, which are sometimes referred to as tension links or dyna-links, are also used in many overhead weighing applications. These devices are usually smaller and lighter than crane scales allowing them to be used in vertical and horizontal positions.  In addition to weighing and crane overload protection applications, dynamometers are often used for crane certification, elevator certification, and several other inline test and measurement applications.

What really makes Interface different when it comes to our calibration services for crane scales and dynamometers?

First, our calibration equipment is custom-made for this exact purpose. That means we don’t take a one-size-fits-all approach to your specific calibration needs, giving you the peace of mind that your calibrations are done correctly.

Second, we have decades of experience providing industry-leading service and putting our customers first. We are sought out for this service for a reason—because we get it done right.

Additionally, Interface does not use hybrid systems for its calibrations. We use direct force application and NIST traceable force standards with customized fixture assemblies for each type of equipment. These important distinctions allow us to focus on providing the best-accredited calibrations for crane scales and dynamometers available in the industry.

Not only are we recognized experts in calibration services, but Interface is also known globally for reliability, accuracy, and longevity of its products. Interface manufactures force products which are used worldwide in test and measurement applications, as well as our own renowned metrology lab. Our specialized engineering and metrology teams pay close attention to the performance data of these standards. With proper maintenance and regular calibrations by Interface, we provide assurance that load cells are operating at the highest standard.

Interface understands that aerospace and military engineering professionals cannot wait long periods of time to receive their load cells after calibration service. We are known for our quick turnaround time. We make sure load cells, crane scales, dynamometers, and other force measurement equipment is calibrated to perfection expeditiously, to prevent significant disruption to any operations.

“Interface’s 51 years of experience in manufacturing and calibrating force measurement devices makes us one of the largest and most sought-after calibration service providers in the world. Our team follows strict standards and protocols to make sure our customers are receiving the best calibrations possible.”  Mike Cobb, Director of Services.

This year, Interface introduced a new Tiered Calibration Services Program to offer customized and expedited services.  No matter the tier of service, Interface services receive a warranty and all our service is ISO 17025 accredited calibration service. To schedule a service, visit here.



Introducing Interface Tiered Calibration Services Program

Interface understands our customers have thousands of applications for more than 16,000 Interface force measurement products. We also know many customers have specific needs for calibration and repair services.

How do we know? We are the preferred provider for calibration services in the market, performing more than 100,000 in-house calibrations every year for thousands of customers. Interface even calibrates load cells manufactured by others.

Choosing Interface for calibration and repair ensures that industry certified experts perform the work, guarantee and certify the calibration service, and provide a detailed report with a warranty on all our work. Basically, we design it, build it and service it. It is the true meaning of one-stop-shop.

We are now taking it to the next level. Today, we are introducing the new Interface Tiered Calibration Services Program.

Our Tiered Calibration Services Program is designed with the customer in mind. It allows customers to pick and choose their exact calibration requirements, fast and easy. This means that if a customer needs a basic service, a fully-customized service solution, or anything in between, Interface is capable to fulfill and exceed expectations.

We are excited to announce that we have found additional ways to extend our services through tailored programs that are designed to meet the exact needs of our valued customers.” Michael Cobb, Director, Interface Service

Quality matters—and we excel at this. However, we know what matters just as much as quality to our customers is the speed of services. Speed isn’t just shipping, it’s the actual time from leaving the customer’s location to returning a fully calibrated or repaired product to them. To meet the “local” needs for expedited services, while offering the highest quality and largest range of service options, our new Tiered Calibration Services Program provides in-house turnaround times ranging from 7-10 days, and as fast as 24-hours for urgent requests. We can even build a program tailored the exact requirements of the customer.

The Interface Tiered Calibration Services Program is now available for all our customers, providing four distinct service tiers: Standard, Gold, Platinum, and Custom.

Standard Calibration Service

  • Expert Calibration Services Performed at In-House at Interface Headquarters
  • Accredited and ISO 376 and ISO 17025 Certified Calibration
  • Detailed Performance Evaluation
  • Easy Online RMA (Return Merchandise Authorization) Creation with Interface’s IPerform Service software
  • IPerform Service Data Archive
  • Real-Time Tracking Online through IPerform Service for All Requests
  • Interface Guarantee and Warranty
  • 7-10 Business Day In-House Calibration Time

Gold Calibration Service

  • Everything Standard PLUS priority service turnaround and free return 2-day shipping
  • Maximum of 5 Business Days In-House Calibration Time
  • IPerform Service Software for RMA, Archive plus Asset Management
  • Return Shipping in Interface Specialized Packaging for Safety and Storage
  • Free 2-Day Express Return Shipping for Non-Freight Weights (US Only)

Platinum Calibration Service

  • Everything Standard and Gold PLUS expedited​ ‘front of the line’ service for fastest turnaround and free 2-day shipping in both directions
  • Maximum 3 Business Days In-House Calibration Time, Able to Request 24-Hour Rush Turnaround
  • IPerform Services RMA, Asset Management, Data History, Scheduling, and Tracking
  • Return Shipping in Interface Specialized Packaging for Safety and Storage
  • Free 2-Day Express Bi-Directional Shipping for Non-Freight Weights (US Only)
  • Concierge Pick-Up and Delivery Options for Non-Freight Weights

Custom Calibration Services

  • All Standard, Gold and Platinum Services PLUS
  • Managed Inventory
  • Expedited Repair
  • Automated Service Requests
  • IPerform Software
  • Maintenance Programs
  • Discounts

Note, all turnaround times are calculated by time in-house at Interface headquarters.

To learn more about how Interface’s NEW Calibration Tiered Services Program can help your company, visit /calibration-repair/tiered-calibration-services-program/.  To schedule a calibration or repair from Interface, submit a request here.
