Force Measurement is Fundamental in Material Testing

/0 Comments/in /by

Material tests are run to determine the quality, durability, and resistance of materials for parts and products. Selecting the right material is critical to performance of a product, system, or part, especially as it relates to the environmental factors. It is also core for adhering to regulatory standards and compliance requirements.

Whether it is construction and concrete materials, metals, fabrics, biomaterial, plastics, packaging, or some other matter, material testing is fundamental throughout the entire development lifecycle.

Among the various ways to test materials, force measurement is one of the most important. Common uses of force measurement in material tests include applications to measure hardness, torsion, strength, compression, bending, shear, impact, creep, fatigue, and nondestructive capabilities.

The use of load cells provides an adaptable tool that can be utilized for various types of material tests. Using force measurement sensors help to detect changes in load, which is used to determine the flexibility, strength, or weakness of properties in materials. This is critical for research and quality control.

For example, in metal material testing load cells are frequently used for characterizing and assessing the quality of metallic components and structures. Material test engineers use load cells to accurately measure the tensile strength, compression resistance, and yield properties of metal samples. By subjecting metals to controlled loads and monitoring the metals deformation during tests, Interface load cells provide critical data that informs engineering decisions and quality control processes. Material tests confirm that the metals chosen for products like aircraft structures, automotive components, and sports equipment, meet stringent performance standards. The measurement sensors are also vital for determining the reliability, longevity and safety of metal materials used for any product or part. See other examples of testing in our new Interface T&M Material Testing Overview.

It is the responsibility of a material testing engineer to determine the resilience, safety, and value of materials through mechanical testing, of which material testing is one of the five categories. Ultimately, product designers and original equipment manufacturers (OEMs) rely upon material testing data to ensure their products can withstand the anticipated levels of force during use. They also need to know if the material will stretch or elongate, as well as pinpoint its exact breaking point.

Interface’s robust line of load cells, multi-axis sensors, and data acquisition systems are used for material testing. It is common to have our 1200 LowProfile load cells installed into material testing machines at test labs and onsite. We also supply a variety of miniature load cells and load pins for material testing, depending on the type of equipment and environment used for tests.

High accuracy load cells are essential in material testing due to their precision, versatility, and ability to provide real-time data, which helps researchers and engineers gain a better understanding of a material’s mechanical properties and behavior under different conditions.

If force must be measured, Interface has a solution. This applies to testing materials used for infrastructure, medical devices, aircraft, rockets, vehicles, robotics and consumer goods. As new materials and composites are introduced in revolutionary ways for use in construction, designing light weight products using polymers, and 3D printed components, it is imperative that material tests validate the use case based on high accuracy measurements.

Our force measurement products are being used to gather data from testing materials in applications used for machines, equipment, structures, packaging and more. Here are a few examples of material testing applications.

Inflatable Space Habitat

Inflatable habitats are the newest innovation in the space industry, creating a new interplanetary dwelling for humans to live and work past the Earth’s atmosphere. An innovative space industry company wanted to test the overall design and material of their inflatable habitats by conducting a burst test. Multiple clevises and LP Stainless Steel Load Pins were attached to the in the webbing material that create the inflatable habitat. When pressure was increased within the inflatable habitat, the load pins captured how much force the heavy duty material will hold at specific pressures until it explodes. Interface’s LP Stainless Steel Load Pins successfully measured the amount of force the inflatable habitat could withstand during the burst test.

Material Tensile Testing Load Frame

A customer wanted to conduct a tensile force test on different samples and materials until failure. Materials include plastic, steel, or woven fabric. They wanted to measure tensile strength, yield strength, and yield stress. Interface’s 1200 Standard Precision LowProfile™ Load Cell was installed into the customer’s test frame. The tensile test was conducted, and force results were captured by the load cell and extensometer were synced through the SI-USB4 4 Channel USB Interface Module. These results were then displayed on the customer’s PC with supplied software. With Interface’s force products, the customer was able to determine the tensile strength, yield strength, and yield stress of a variety of different materials.

Material testing is often the first step in any new product development process. With Interface force measurement solutions, our customers can expect industry-leading accuracy, quality and reliability in testing the materials that will go into their next project. Contact us for products used for various test types.

Interface Solutions for Material Testing Engineers

Tensile Testing for 3D Materials

Bending Beam Load Cell Basics

The Aviation Industry Soars Using Interface Solutions

Interface Solutions for Structural Testing

Interface Solutions Aid Pharmaceutical Industry

The Aviation Industry Soars Using Interface Solutions

/0 Comments/in /by

Interface is proud to offer a diverse range of force, torque, and weight measurement solutions to the aviation industry.

A sector within the aerospace industry, Interface aviation solutions are products we supply for use in the design, engineering and operation of aircraft.

The quality of our products, including the reliable form factor design, proprietary strain gages, and rugged materials, are built to withstand the rigorous performance standards and environments that aircraft safety demands. It is why Interface is a provider of choice for test and measurement solutions in the aviation industry. Check out our new Aircraft Solutions overview here.

The aircraft and aviation industries are vast and complex with many different sectors. Our products are currently used in commercial, general and military aviation, aviation infrastructure, equipment and systems. In addition to the mechanical component testing, Interface often supplies load cells, torque transducers and instrumentation for use in aviation training, education, research and development.

While aviation systems embody an extensive collection of interconnected components and technologies, this complexity does not lessen the requirements for rigorous sensor-based test and measurement programs for every part. Interface products help to collect critical data on the performance of aircraft components and systems. These aviation systems include aircraft, air traffic control, navigation and communication systems, infrastructure, ground support equipment, airport transport vehicles, aircraft testing labs, and tools.

We work with aeronautical and mechanical engineers who are involved in designing, developing, and maintaining aircraft, propulsion systems, avionics, and air traffic management technologies. Interface load cells and transducers provide accurate and reliable measurements of forces, weights and torques of aviation components and systems.

How does the aviation industry use Interface measurement solutions?

  • Aircraft engine manufacturers use our load cells and torque transducers to measure the operating performance within their design limits and for diagnostics and troubleshooting. Read: Aircraft Engine Hoist
  • Aviation system developers integrate our sensors into equipment and parts to provide continuous force monitoring and to trigger alarms for maintenance.
  • Rotorcraft part makers need to assess the loads and torques on blades and other components to the aircraft is safe to fly and to identify any weaknesses based on accurate measurements. Read:Propeller Testing
  • Landing gear experts use our load cells to confirm that the gear can withstand the forces encountered during takeoff, landing, and taxiing. Read: Landing Gear Joint Testing
  • Aircraft structures must be strong enough to withstand the forces encountered in flight. Testing is standard for cycle counts, environmental tests and assessment of materials. Interface products are used for assessing structural like wings and fuselages in wind tunnel tests. Read: Interface Solutions for Structural Testing and Aircraft Wing Fatigue App Note
  • Flight control systems are using measurement sensors to test and monitor the components used for various controls. Read: Aircraft Yoke Torque Measurement
  • In-flight systems and simulators utilize precision measurement devices to provide vital data that monitors aviation and aircraft health. This is important for real-time assessments and for training purposes. It is essential for the long-term growth of the industry to provide the best tools and equipment to learn the values of accurate measurement and how it impacts performance and safety.

Beyond the essential manufacturers of aircraft parts, aviation systems, and equipment, Interface supplies many of the leading aviation testing labs with load cells, load pins, torque transducers, wireless devices and instrumentation. The quality of our products is built to withstand the rigorous performance standards and environments that aircraft safety demands.

Our products are used for static testing, material testing, torque testing, fatigue testing, stress and tension tests, dynamic testing, environmental and wind tunnel testing, structural tests and compression testing. We also supply the aviation industry with measurement solutions for rigging, lifting, weighing and monitoring of equipment in use. Check out our Aircraft Lifting Equipment App Note.

Learn more about our range of solutions in this Airplane Jacking System solution.

The aviation industry is a dynamic and ever-changing industry, and the sectors within it are constantly evolving. New innovations in the aviation require extensive testing and accurate measurement. The aviation industry is a complex and demanding industry, and the development of new technologies requires a rigorous testing process.

The fact that Interface offers an extensive array of force measure devices in different models, capacities, configurations and capabilities helps aviation system suppliers and manufacturers. Our load cells and sensor technologies are used to measure a wide range of factors, such as tensions, weights, forces, and torques. This information can be used to ensure the safety and reliability of aircraft and their components.

With a surplus of options that can meet the specifications of each use case and testing application, Interface is an experience and preferred provider to the aviation industry.

ADDITIONAL RESOURCES

Interface Supports Wind Tunnel Testing

LIFTING: Airplane Jacking System

LIFTING: Aircraft Engine Hoist

Taking Flight with Interface Solutions for Aircraft Testing

Aircraft Wing Fatigue App Note

Aircraft Screwdriver Fastening Control App Note

Airplane Static Testing Case Study

Are Load Cells Used in Vacuum Environments?

/0 Comments/in /by

Vacuum testing labs are essential for ensuring that products and materials are safe and dependable in vacuum environments. A vacuum environment is an area where there is little or no matter. This means that there are very few gas molecules present, and the pressure is incredibly low. Vacuum environments are often created using vacuum pumps, which remove gas molecules from an enclosed space.

Vacuum environments are used to simulate the conditions that products and materials will experience in space or other high-altitude environments. These types of testing labs typically have a vacuum chamber that can be evacuated to an incredibly low pressure. The vacuum chamber is then used to evaluate products and materials for a variety of properties. Engineers use vacuum environments in testing for reduced contamination, improving heat transfer, and to reduce the weight of products.

Tests performed in vacuum labs are used to determine the rate at which gases are released from a product or material and the ability of a product or material to withstand a vacuum without leaking. Thermal cycling tests are done to assess the ability of a product or material to withstand changes in temperature in a vacuum environment. Other tests are done to understand how the test article withstands exposure to radiation.

Vacuum testing labs are used by a variety of industries, including aerospace, medical, and defense. These labs are common for material process testing and used in R&D. Vacuum testing helps to identify potential problems with products and materials before they are used in a real vacuum environment. Engineers use this type of testing to improve the performance of products and materials and ensure they meet the required standards. Contact Interfaced to explore your options.

Can load cells be used in a vacuum environment?

Load cells can be used in a vacuum environment. However, not all load cells are created equal or suited for this specialized use case. Some load cells are designed that make them appropriate for vacuum environments, while others are not. Load cells that are not engineered to perform in vacuum environments may not be able to withstand the low pressures and outgassing that can occur in a vacuum. Using quality load cells that are manufactured by force measurement experts in sensor technologies is important in any consideration. It is critical to review the specifications and requirements with a qualified applications engineer.

Key considerations when choosing a load cell for a vacuum environment:

  • Outgassing: Load cells that are used in vacuum environments will have low outgassing rates. This means that they will not release gases into the vacuum chamber, which can contaminate the environment and interfere with measurements.
  • Mechanical strength: Load cells must be able to withstand the low pressures that can occur in a vacuum. They will also be able to withstand the conditions that can be generated by vacuum processes, such as outgassing and condensation. Form factor and model material of the load cell are important in choosing a load cell for this use case.
  • Temperature range: Load cells will need to operate in a wide range of temperatures. This is important because vacuum chambers can be very cold, especially when they are first evacuated, or when they are used to simulate high altitudes or space.

If you are looking for a load cell that can be used in a vacuum environment, please review with Interface application engineers to determine if the model fits your test requirements. We also can offer custom solutions to ensure that the load cell maintains the accuracy and performance specifications based on your exact test plan.

Can a load cell be vented for use in a vacuum testing lab?

Technically yes, you can vent a load cell to be used in vacuum. This allows the internal cavity of the load cell to equalize with external vacuum. However, this does not prevent outgassing and can cause the gages and wiring to be subject to humidity and condensation.

Cabling is extremely important when using any sensor in this environment. There are options to make the load cells wireless using Bluetooth technology.

Caution: Interface recommends that all our products used in this type of environment are designed, built, and calibrated for use in this environment. Venting an existing load cell can alter the performance and damage the cell.  By designing the load cell with venting for use, we can ensure that it will meet the vacuum test range.

Interface also can install thermocouples to work with the sensor to detect temperature in this type of testing environment. In fact, our engineers have designed load cells to package the thermocouples inside the form factor for convenience and performance benefits.

Interface engineers have worked with testing labs for decades. We are available to assist with any use case requirements to determine the best measurement solution.

Calibration Curve 101

/0 Comments/in , /by

Calibration curves are essential for ensuring the accuracy of force measurements. They are used in a wide variety of test and measurement applications, including quality control, research, and engineering.

A calibration curve is a graph that shows the relationship between the output of a measuring instrument and the true value of the quantity being measured. In force measurement, a calibration curve is used to ensure that the force measuring device is performing accurately. In the context of load cell calibration, a calibration curve is a graphical representation of the relationship between the output signal of a load cell and the applied known loads or forces.

The load cell user will use a known force standard to create the calibration curve. The known force standard is applied to the force measuring device and the output of the instrument is logged via the supporting instrumentation. This process is repeated for a range of known forces.

The calibration curve for a load cell is created by plotting the output signals (typically in voltage or digital units) on the y-axis against the corresponding applied loads or forces on the x-axis. The resulting graph is the calibration curve.

Test and measurement professionals use the calibration curve to convert the load cell output to the true value of the force being measured. The curve helps to establish the relationship between the load and the output signal, and it provides a means to convert the load cell’s output into accurate force or weight measurements. For example, if the output is 100 units when a known force of 100 N is applied, then the calibration curve will show that the measurement using the load cell is accurate to within a certain tolerance.

Benefits of using a calibration curve in force measurement:

  • It ensures that the force measuring instrument is accurate and dependable.
  • It provides a way to convert the load cell output to the true value of the force being measured.
  • It can be used to identify and correct errors, including drift, sensitivity, overload and hysteresis.
  • It should be used for traceability and to track the performance of the measurement device over time.

Why does a calibration curve matter when calibrating load cells?

Load cells can be affected by a range of factors, including temperature variations, drift, and environmental conditions. The calibration curve helps identify and compensate for these factors. By periodically calibrating the load cell, any deviations from the original calibration curve can be detected, and appropriate corrections can be made to ensure accurate and reliable measurements.

The calibration curve for a load cell should be linear, indicating a consistent and predictable relationship between the applied load and the output signal. However, load cells may exhibit non-linear behavior, such as sensitivity variations or hysteresis, which can be accounted for and corrected through calibration.

The calibration curve allows for the determination of the load cell’s sensitivity, linearity, and any potential adjustments or corrections needed to improve its accuracy. It serves as a reference to convert the load cell’s output signal into meaningful and calibrated measurements when the load cell is used in practical applications for force or weight measurement.

Calibration curves are an essential tool for ensuring the accuracy of force measurements. They are used in a wide variety of applications, and they offer several benefits. If you engage in using load cells, it is important to understand the importance of calibration curves and how they can help you ensure accurate measurements.

Find all of Interface 101 posts here.

Interface recommends annual calibration on all measurement devices. If you need to request a service, please go to our Calibration and Repair Request Form.

ADDITIONAL RESOURCES

Interface Calibration 101

Interface Guides

Load Cell Sensitivity 101

Interface Force Measurement 101 Series Introduction

Extending Transducer Calibration Range by Extrapolation

Top Five Reasons Why Calibration Matters

Accurate Report on Calibration

A Promising Future in Measurement and Analysis Using Multi-Axis Sensors

/0 Comments/in /by

By combining the measurements from multiple axes, multi-axis sensors provide a better assessment of an object’s motion or orientation in three-dimensional space. Measuring the changes in resistance or output voltage from the sensing elements along multiple axes, multi-axis load cells can accurately determine the forces acting on them. The combination of the signals from different axes provides a comprehensive understanding of the force distribution, enabling engineers to analyze and optimize designs, evaluate structural integrity, and ensure safe and efficient operation in various applications.

Multi-axis load cells have significant advantages and provide valuable benefits in testing labs. The top reason to use multi-axis sensors is to get more measurement data. The data provided when using a 2, 3 or 6-Axis load cell is used in various applications, including robotics, space projects, virtual reality, motion tracking, navigation systems, and innovative consumer products.

Engineers and product designers prefer multi-axis load cells for several reasons. Multi-axis load cells enable engineers and designers to capture forces along multiple directions simultaneously. This capability is particularly beneficial when dealing with complex and multidirectional forces, which are common in real-world applications. By obtaining a complete understanding of how forces act on a structure or product, engineers can design more robust and optimized solutions.

The Promises of Multi-Axis Sensors

  • Comprehensive force measurement and better data analysis: Multi-axis load cells enable precise measurement of forces in multiple directions simultaneously. Multi-axis load cells provide richer and more comprehensive data for analysis. The data is valuable for evaluating structural integrity, load distribution, and performance characteristics of a design.
  • Compact size with robust capabilities: Smaller sensors with digital outputs are easier and less expensive to permanently install into their machines. Size impacts the install, testing and monitoring. Multi-axis sensors are best embedded into products for a real-world application that needs the data, while reducing the number of single load cells and overall size of a product.
  • Increased accuracy and reliability: Multi-axis sensors track performance and reliability better than traditional sensors with more measurements in more directions, enhancing the accuracy and reliability of test results. They provide a more complete understanding of how forces are distributed and interact within a structure, helping researchers and engineers make informed decisions based on reliable data.
  • Wide range of applications: Multi-axis sensors are needed to keep up with modern technologies and application requirements. Multi-axis load cells are used in various testing scenarios, including materials testing, structural testing, product development, and quality control. They are used in industries such as aerospace, automotive, manufacturing, civil engineering, and more. As technology advances and testing requirements become more sophisticated, the demand for multi-axis load cells is likely to grow.
  • Efficiency and cost-effectiveness: A single multi-axis load cell can replace multiple sensors. This consolidation simplifies the testing setup, reduces complexity, and lowers costs. Multi-axis sensors maximize return on investment for testing devices.
  • Enhanced testing capabilities: Multi-axis load cells enable more advanced testing procedures. Digitized sensor information allows for remote monitoring increased analytics, easy access and data collection. This expands the range of tests that can be performed and provides more comprehensive data for analysis and evaluation.
  • Saving space in testing: Using a single multi-axis load cell saves physical space in the testing. This is particularly important in situations where space limited or when performing tests in confined environments. By reducing the footprint of the load cell setup, engineers and designers can optimize the use of their workspace.
  • Simplifying set-up: Using a single multi-axis load cell simplifies the testing setup compared to using multiple single-axis load cells. It reduces the number of sensors, cables, and connections required, leading to a streamlined testing process. This simplicity improves efficiency, saves time, and reduces the chances of errors associated with multiple sensors and connections.

Interface Multi-Axis Sensor Models

2-AXIS LOAD CELLS: Interface’s 2-Axis Load Cells measure any two forces or torques simultaneously, have minimal crosstalk, are standard off-the-shelf and are high accuracy sensors.

3-AXIS LOAD CELLS: Interface’s 3-axis load cell measures force simultaneously in three mutually perpendicular axes: X, Y, and Z – tension and compression. Options include:

6-AXIS LOAD CELLS: Interface’s 6-Axis Load Cell measures force simultaneously in three mutually perpendicular axes and three simultaneous torques about those same axes. Six full bridges provide mV/V output on six independent channels. A 36-term coefficient matrix is included for calculating the load and torque values in each axis. In the end, they provide more data, accuracy, are very stiff and cost-effective for a wide range of testing options.

Interface continues to add to our product line of advanced multi-axis sensors. Read New Interface Multi-Axis Load Cells to see our latest model additions.

The future of multi-axis is evolving in versatility for various system level health monitoring for products and components. Data is valuable now and in the future. These sensors enable test engineers to collect more data now for future analysis. For example, an automotive electronics manufacturer could limit recall to only parts that match extremely specific build criteria based on the detailed sensor data that is captured and stored during product evaluations and testing.

The outlook for multi-axis load cells is promising. Their ability to provide comprehensive force measurement, improve efficiency, and enhance testing capabilities makes them a valuable tool for researchers, engineers, and quality assurance professionals. With ongoing advancements in sensor technology and increasing demand for precise and reliable testing, multi-axis load cells are expected to play a crucial role in the future of testing labs.

ADDITIONAL RESOURCES

Using Multi-Axis Sensors To Bring Robotics To Life

Mounting Tips For Multi-Axis Sensors

BX8-HD44 BlueDAQ Series Data Acquisition System For Multi-Axis Sensors With Lab Enclosure

Enhancing Friction Testing With Multi-Axis Sensors

Recap Of Inventive Multi-Axis And Instrumentation Webinar

Interface Multi-Axis Sensor Market Research

Dimensions of Multi-Axis Sensors Virtual Event Recap

Better Data and Performance with Interface Multi-Axis Sensors

Multi-Axis Sensor Applications

Testing Lab Essentials Webinar Recap

/0 Comments/in /by

Interface recently hosted an in-depth discussion about one of our favorite topics, testing labs. Our focus in this technical webinar centered on test lab devices, instrumentation, industry testing lab challenges and considerations, along with best practices. We also took a deep dive into different testing lab applications and how to modernize your test lab.

Force measurement experts Elliot Speidell and Jeff Boyd delivered an engaging and knowledgeable seminar, Testing Lab Essentials: Today + Tomorrow.  Bringing decades of first-hand experience, they were able to provide product examples, tips, recommendations and lessons learned in working with testing lab professionals across industries, from automotive to medical devices.

Initial discussions in the event covered test lab basics, including types of products should be in every lab that performs testing of force, torque, and weight. The quick summary, force, torque and weight measurement devices including load cells and torque transducers of various models, calibration grade equipment and published standards, test stands, data acquisition systems and safety equipment.

One of the first steps in assessing any lab is the type of measurement equipment on hand to perform various testing requirements. Transducer selection criteria includes mechanical connection and load application, force magnitude and loading condition, cycle count, form factor restrictions, environmental conditions, additional measurements needs, such as multiple axis.

Testing labs often require different types of load cells depending on the type of products being tested and the applications in which the load cells will be used. Here are some common types of load cells used in testing labs:

  • Compression load cells: Used to measure the compressive force applied to an object. They are commonly used in materials testing to measure the strength of materials such as concrete, metals, and plastics.
  • Tension load cells: Used to measure the tensile force applied to an object. They are commonly used in materials testing, such as in tensile strength testing of metals and other materials.
  • Shear load cells: Used to measure the shear force applied to an object. They are commonly used in materials testing, such as in shear strength testing of materials.
  • Multi-axis load cells: These load cells are capable of measuring forces in multiple directions and are commonly used in structural testing applications.
  • Torque transducers: Used to measure torque or twisting forces. They are commonly used in automotive testing, industrial machinery, and other applications where rotational forces are important.
  • Fatigue-rated load cells: These load cells are designed to withstand high-cycle fatigue testing and are commonly used in materials testing and durability testing of products.
  • Low profile load cells: These load cells are designed to fit into tight spaces and have a low profile, making them ideal for use in small-scale applications.
  • High-capacity load cells: These load cells are designed to measure large forces and are commonly used in heavy machinery and structural testing.

Instrumentation is central to any testing lab environment. The three most common types of instrumentation found in test lab includes:

  • Indicators: Indicators are used to convert the input signal to a local displayed value.  Often they will have features like, peak capture, alarms, and analog outputs.
  • Signal Conditioners: Signal conditioners are used to convert (amplify) one type of electrical signal into another.
  • DAQ: Data acquisition systems are used to collect and analyze data from measurement devices. These systems may include software, hardware, and data processing equipment.

In a series of follow-up InterfaceIQ Blog posts we will detail other topics covered in this information packed discussion, including modernization, load frames and test stands, do and don’t tips, plus frequently asked questions.

Watch the complete webinar here:

Interface Force Measurement 101 Series Introduction

/0 Comments/in /by

In our ongoing commitment to provide valuable resources through self-help guides and online reference materials, we are introducing our 101 Series.

This new online resource is an easy-to-use guide for load cell basics and force measurement topics. The series is a collection of content in various formats that detail subjects related to test and measurement.

Interface prioritizes helping our customers understand the inner workings of our expanding line of sensors, accessories, and instrumentation by creating guides, technical manuals, and solution applications for force measurement.

The Interface 101 Series will introduce you to relevant subjects about our products and how we can help you get the most accurate and reliable force data in the industry by using our solutions.

Our new 101 Series guide is an effortless way to navigate through high-level test and measurement topics. Each section of the new 101 Series includes a featured 101 IQ blog on a single subject, as well as quick links to videos, case studies, white papers, application notes, product information, technical specifications and more related to that subject.

The goal in creating the 101 Series is to provide a basic understanding on how our products are used for various test and measurement applications across all industries. The references are an effective way to learn about the broad depth of Interface products like our precision load cells, torque transducers, multi-axis sensors, calibration systems and instrumentation. We also provide relevant test and measurement content related to types of force measurement testing, components, systems, and materials used in engineering highly accurate measurement technologies.

There are thousands of references found throughout our site, like our design files for product engineers and digital instrumentation set-up videos for lab techs. It is our pledge to develop material that support our 35,000 products, as well as provide educational content like the 101 Series and our ForceLeaders Webinars you can watch on-demand.

Included below are the current 101 IQ Blogs you will find featured on the 101 Series online guide. We will add additional references to this 101 Series, as we post new subjects. Go to Force Measurement 101 Series to bookmark this reference.

101 Series IQ Blogs

You can find additional reference materials related to our products and services including manuals, product catalogs, technical references, and events.  Go to our online support to find helpful educational and advanced resources like our technical glossary, engineering tips and installation guides.

If you are mostly interested in why you should choose Interface, here is a good reference to start.

If you are not able to find the information you need or you have a specific question about our products or services, be sure to contact us to help.

Interface Solutions for Lifting Applications

/0 Comments/in /by

Lifting is the action of raising an object to a higher level or moving an object to a different position. Tension load cells accurately measure forms of lifting, as they measure pulling by design. Choosing the right sensor for this type of measurement requires consideration of the size of object that is lifted, and mechanism used in the act to create the lift. Read more in our latest case study Cranes and Lifting.

Often large capacity load cells are used in industrial equipment, cranes, forklifts, rigging, and even aircraft testing equipment to measure forces applied in heavy lifting and for load monitoring, as well as to maintain accuracy in movement. Larger capacity load cells can range from 10,000 to million lbf, or even larger. Rugged load cells are frequently selected for this type of equipment to sustain harsh environmental conditions for both testing and during real-time use.

Smaller capacity load cells, such as s-types and miniature beams, measure the lift action in machines, medical equipment, packaging, robotics, drones and moving equipment. In all circumstances, force measurement sensors help product engineers and manufacturers improve safety and the quality of products they build. They are versatile and easily integrated into machines and components.

Beyond the measurement specifications, other top feature considerations when selecting the right sensor include weight of the sensor, requirements for overload protection, enclosures and ruggedized material used to construct the device, signal outputs for data, cabling, or wireless functionality, mounting or clamping, and instrumentation for data acquisition.

For measurement in lifting applications, Interface products provide the industry’s most accurate and reliable data available through force measurement sensors. Products we provide for lifting include multi-axis sensors, load washer load cells, low profiles, miniature load cells, load shackles, load pins, tensions links, instrumentation, and torque transducers.

The following are examples of products we supply for lifting equipment and use cases.

AERIAL BOOM LIFT OPERATION


A manufacturer aerial lifts wants to test its self-propelled boom platform to ensure it can operate at heavy capacities when in use, and at different angles. This testing is vital for safety and protecting operators as well as those at the site of where equipment is in use. The sensors help to prevent any accidents in case of a lifting overload. The Interface application engineers recommends the multi-axis 3AXX 3-Axis Force Load Cell model 3A160 to capture the required data for monitoring in real-time. Paired with the 920i Programmable Weight Indicator and Controller, the operator had accurate information when using the equipment.

AIRCRAFT LIFTING TEST RIG



An aerospace manufacturer is looking to accurately measure the valves in their aircraft lifting test equipment. Interface’s solution is to install a 1200 High Capacity Standard Precision LowProfile™ Load Cell in between the aircraft testing rig and the lifting jack. The load cell will measure the load’s force safety valve when the lifting equipment opens. Results will be sent to the 9890 Strain Gage, Load Cell, & mV/V Indicator, where the customer can see it displayed in real-time.

LIFTING HEAVY OBJECTS


In this common use case, a customer needs to measure the load when using a crane to move heavy construction materials around the work site. This includes monitoring the weight of these objects as they are lifted in the air. It was critical that the device offer high accuracy readings and also work within the equipment already in place. Key is the instrumentation capabilities to provide wireless outputs. Interface recommends using our WTSSHK-B Wireless Load Shackle connected in crane load string to measure forces. Model WTS-BS-1-HA Battery Powered Handheld Display is used to wirelessly receive load information and display results.

Read more about these types of lifting applications in our new case study.  If you need help in deciding which product works best for your lifting application, contact us.

Cranes and Lifting Case Study

Interface Solutions for Material Testing Engineers

/0 Comments/in /by

Force measurement inherently is part of all types of engineering throughout the entire development process of products, structures, consumer goods, and the materials used to construct them.

In the beginning of the design and development processes, material testing engineers utilize sensor technologies and instrumentation to measure the durability, fatigue, safety, and quality of the materials used for their projects.

The role of a materials engineer is to develop, process, combine, and test materials to be used in production. Based on data gathered, combined with their expertise, the materials engineer will identify and recommend the appropriate materials for specific applications. Ultimately, they are the foundation of product development because it is their responsibility to select materials based on the use of the product, its ability to perform its task and function, and durability of materials to hold up over time. They also test for environmental impact and exposure considerations.

Five Categories of Material Testing

  • Mechanical testing
  • Testing for thermal properties
  • Testing for electrical properties
  • Testing for resistance to corrosion, radiation, and biological deterioration
  • Nondestructive testing (NDT)

Force measurement is most often used is in the material testing category of mechanical testing. This applies to testing materials used in all types of industries, including infrastructure, aerospace, automotive, industrial automation, manufacturing of consumer goods and in the machines used to assemble products. In mechanical testing, Interface sensors are commonly used to conduct:

  • Hardness Testing
  • Tensile Testing
  • Impact Testing
  • Fracture Toughness Testing
  • Creep Testing
  • Fatigue Testing
  • Nondestructive Testing

Interface Material Test Engineer Solutions

Material testing has been around since the first invention, to determine quality, durability and resilience of products and parts. What has changed over the centuries and decades is the sophistication of force testing and measurement. Interface’s robust line of load cells, torque transducers, multi-axis sensors, and instrumentation are used in about every industry for material testing. If it must be measured, Interface has a solution.

Interface’s force measurement products are being used to gather data from testing materials in applications used for industrial automation, structures, medical devices, vehicles on the ground and in the air, packaging, sports equipment and more. Material testing engineers ensure reliability and safety of the chosen materials. Here are examples of how material testing engineers use our products.

Tensile Testing of 3D Printing Materials

Interface was contacted by a test engineering team in search of a solution for conducting a tensile force test on different 3D printing materials until failure. They wanted to test several types of material types. The 3D printing materials to be tested to see how it performed included PLA, PETG and ASA.  The test of the materials was to assess strength, quality, ductility, and stiffness. Interface supplied our most popular load cell, the 1200 Standard Precision LowProfile™ Load Cell, to install into the engineer’s test frame. The tensile test gathered the force results from the load cell that was synced through Interface’s instrumentation solution, the INF-USB3 Universal Serial Bus Single Channel PC Interface Module. The results were displayed on their computer with supplied software from Interface. Read more about this material testing application solution here.

Bike Frame Fatigue Testing

Fatigue testing is a critical material test used to ensure the materials used in a product hold up over time. A bike manufacturing company wanted to perform a fatigue test on their bike frames to analyze the strength of their frames, ensure durability and high-quality standards. Interface suggests installing Model 1000 Fatigue-Rated LowProfile™ Load Cell to the customer’s bike frame fatigue tester. This load cell will provide the customer highly accurate results through the fatigue cycling. Results are collected using the INF-USB3 Universal Serial Bus Single Channel PC Interface Module and displayed on the customer’s computer with Interface’s provided software. The bike manufacturing company successfully had their bikes undergo fatigue frame testing, receiving highly accurate results with Interface’s load cell and instrumentation. Watch the fatigue testing of the bike frame in this animated app note.

Spring Compression Testing

A customer wanted to evaluate the performance of their springs, but also the functionality of their spring test stand with a wireless solution. Interface suggested using one of their WTS-5200XYZ 3-Axis Force Moment Load Cell which has three integral WTSAM-1E Wireless Transmitters and installing it into the customer’s spring compression frame. The WTS-5200XYZ 3-Axis Force Moment Load Cell measured the force compression of the spring. The integral WTS-AM-1E Wireless Strain Bridge Transmitter Modules transmitted and displayed the information wirelessly to the LCCAXXX Wireless Instrument Enclosure. Using Interface’s solution, the customer was able to wirelessly get compression results on the spring being tested. They were also able to verify their spring compression test stand was working effectively.

Selecting the right material is critical to product develop and material testing engineers rely on Interface due to the accuracy and reliability of our solutions. If you have questions on what products are best suited for your material testing applications, please contact us.

ADDITIONAL RESOURCES

Tensile Testing for 3D Materials

Furniture Fatigue Cycle Testing

Bike Handlebar Fatigue Testing App Note

Aircraft Wing Fatigue App Note

Material Tensile Testing

Why Civil Engineers Prefer Interface Products

Beam Stress Test
