Interface force measurement devices are used for critical testing in both commercial and industrial vehicle design and production to ensure safety and reliability in the automotive industry.
As the industry has evolved and transformed, so has the products we supply to our customers in this market. Our range of solutions continues to expand in functionality and capabilities as complexities of testing throughout the entire journey, from component design and prototyping to rigorous safety testing of every piece of equipment progresses.
By creating highly responsive, critically accurate, and safer load cell and torque sensors, we are seeing our products used in all types of test and measurement applications, including:
- Engine dynamometers
- Lug nut assembly
- Airbag connector testing
- EV battery testing
- ICE and EV motor torque testing
- Equipment fatigue testing
- Motor test stands
- Brake and clutch pedal force
- Engine head bolt tightening
- Vehicle crash test walls
- Race car suspension testing
- Transmission gear box and gear mesh
- Autonomous vehicle tests
Research and development facilities with precision application requirements favor our 1200 Series LowProfile™ Load Cells with their special moment compensated design. These are used in auto manufacturer assembly lines in a variety of production monitoring and verification applications. Our exceedingly accurate LowProfile™ Load Cells have even been used in NASCAR and IndyCar garages for testing individual springs and entire vehicle suspensions.
Preview Interface products used in the automotive and vehicle markets in this new solutions video.
Here are two highlights of automotive application notes. You can find more about automotive and vehicle solutions here.
A top tire manufacturer needed a solution that would provide data analysis for stress testing. The research would provide advancements to their product by defining the tire’s dynamic control capabilities. In review with our application engineers, they detailed they need to measure both the torque and lateral force in their testing.
Interface recommended the new AT105 Contactless Force Torque Transducer. With the torque and lateral force testing requirements, they determined that the best option to review the results by display as well as with graphing is to connect the transducers to the 4-Channel USB Interface Module SI-USB4. You can see the entire solution and results in the Tire Testing App Note.
A manufacturer wanted to test the power steering for their vehicles. They want to test the linkage tension and compression between the rack and pinion. On a test frame, Interface’s 1200 Standard Precision LowProfile™ Load Cell was installed at the end of the rack and pinion actuator. As the wheel is turned, the load cell tests the push and pull forces. Force measurements can be displayed in real time using the highly accurate 9870 High-Speed High Performance TEDS Ready Indicator. The 1200 Standard Precision LowProfile Load Cell successfully measured the tension and compression between the rack and pinion of the customer’s MDPS system. You can see the entire solution and results in the MDPS testing App Note.
