Compression Force Testing 101

Compression is a type of force that we apply every day often without thinking and compression is intensely tested in many of the products we use on a daily basis.

Compression force is defined as the energy generated from compressing an object or substance. Compressive force is simply the direction of the force applied to the load cell. The compressive strength of materials and structures is an incredibly important engineering consideration in both designs and build.

Whether you are clicking the keys on your laptop at work or slamming on your brakes to avoid an accident on your morning commute, you are using the compression force. Testing of the compression force is essential in developing a reliable and sturdy product that can withstand the pressure applied to it many times over. Often, safety is at the core of compression testing.

Load cells incorporated into the testing process work by measuring the pushing force of an application on a single axis. The strain gage compresses to measure the load applied. The deformation of the strain gage provides the measurement data. Application tests measure the total compression force the products or structures can handle, as well as the effects of compression over time through stress tests. In both cases, original equipment manufacturers (OEMs) need accurate measurements to guarantee their products can withstand compression in the short and long-term.

Interface supplies a variety of compression-focused load cells and accessories for all types of applications, both for test and measurement, as well as for inclusion in originally manufactured products and solutions. These compression load cells are often used in vehicles, industrial automation, aerospace, and defense industries. Applications are wide-ranging, from testing the impact of drones dropping packages to the material strength of bridges during an earthquake. Interface load cells are highly-rated to provide the most accurate data and reliability over time, which is why engineers rely on Interface compression-only load cells.

Here are a few of the compression load cells available from Interface:

1601 Gold Standard® Calibration Compression-Only LowProfile® Load Cells – Interface’s Gold Standard® Load Cells are designed for calibrating other load cells. The 1601 load cell is compression-only and has options available for a second and third bridge and overload protection.

1201 Compression-Only Standard Precision LowProfile® Load Cells – The Interface 1201 LowProfile® load cell provides a “compression-only” force measurement. Its spherical-shaped top surface helps provide minimal off-axis loading. 1201 is our most popular load cell designed for static applications and has a higher output than most competitive load cells.

2101 Dual Range Standard Compression-Only Load Cells – The Interface Model 2101 consists of lower and higher capacity model 1200 type load cells which are stacked with overload protection built into the lower capacity load cell permitting the high resolution to be obtained at both low and high levels of capacity. The Model 1201 is LowProfile® moment compensated.

LBM Compression Load Button Load Cells – The Interface LBM Compression Load Button is constructed from stainless steel and has a small size for all types of sensor apps and testing. This product is available in capacities that range from 25 lbf up to 50K lbf.

There is a variety of other standard compression-only load cells, including modified and custom Interface compression testing options in multiple capacities. For more information on our compression-only products or any of Interface’s industry-leading force measurement solutions, contact our Application Engineers.
