1606 Gold Standard Low Capacity Calibration Universal Load Cell

PRICING NOTICE

The pricing listed on our website is only for U.S. buyers and all pricing is subject to change without notice. Any inquiries for products from buyers outside of the U.S. will receive a quote and availability from the licensed distributor nearest your region. These prices will be based on product availability, currency conversions, markets, taxes, shipping costs, as well as local support.

1606 Gold Standard Low Capacity Calibration Universal Load Cell

Name: 1606 Gold Standard Low Capacity Calibration Universal Load Cell
SKU: 29821

Tension and Compression Calibration Grade

Get Your Free Quote

50 lbf to 300 lbf
222 N to 1330 N

Model 1606 Gold Standard® load cell is designed for calibrating other load cells where the best possible load cell is required. It has a 4% lower load limit per ASTM E74 and is a step above the 1100. The 1606 is especially made for low capacity applications.

Option Available for 2nd Bridge.

Product Downloads

Please login or register for Product Pricing and File Access

Data Sheet
1606 50-300lbf STP File
1606 250-1500N STP File
1606 Drawing

Option Available for 2nd Bridge.

Need a quote or looking to purchase this item?

Login, scroll to see your model descriptions and SKU part number, then use the Request for Quote button to submit your request.

Request a Quote Request a CAD File

SKU: N/A Categories: Calibration Equipment, Calibration Grade, Calibration Grade Load Cells, Load Cells, Low Profile Load Cells, Quickship, Side Load Sensitivity, Tension and Compression Tag: quickship

Features and Benefits

Tension and compression in one unit
0.02% creep
Factory installed calibration adapter
3-run NIST traceable ASTM E74 calibration
Eccentric load compensated
0.0008%/°F temperature effect on output
4% lower load limit
Transducer Electronic Data Sheet (TEDS)

Options

Connector protection
Standardized output
Custom calibration
Multiple bridge
Special threads
Dual diaphragm
Special temperature range
Cable length
Add connector to cable

Connector Options

PT02E-12-8P bayonet connector

Accessories

Mating connector
Mating cable
Instrumentation
Loading hardware
Calibration software

Specifications

International System of Units (SI) dimensions and capacities are provided for conversion only. Standard products have U.S. capacities and dimensions. SI capacities available upon special request and at an additional cost.

Dimensions

Connector Pin Diagram

CONNECTOR PINOUT
PIN	FUNCTION
PIN	8 WIRE (C2)	8 WIRE (C2 WITH TEDS OPTION)
A	+ EXCITATION	+ EXCITATION
B	+ SIGNAL	+ SIGNAL
C	- SIGNAL	- SIGNAL
D	- EXCITATION	- EXCITATION
E	- SENSE	- SENSE
F	+ SENSE	+ SENSE
G	- RCAL	TEDS DATA
H	+ RCAL	TEDS GROUND
ALL READ UPSCALE IN TENSION

For more information visit Electrical Wiring Diagrams

Additional Information

Dimensions	2.75 × 2.75 × 1.50 in

Product Video

Features and Benefits

Tension and compression in one unit
0.02% creep
Factory installed calibration adapter
3-run NIST traceable ASTM E74 calibration
Eccentric load compensated
0.0008%/°F temperature effect on output
4% lower load limit
Transducer Electronic Data Sheet (TEDS)

Options

Connector protection
Standardized output
Custom calibration
Multiple bridge
Special threads
Dual diaphragm
Special temperature range
Cable length
Add connector to cable

Connector Options

PT02E-12-8P bayonet connector

Accessories

Mating connector
Mating cable
Instrumentation
Loading hardware
Calibration software

Specifications

Dimensions

Connector Pin Diagram

CONNECTOR PINOUT
PIN	FUNCTION
PIN	8 WIRE (C2)	8 WIRE (C2 WITH TEDS OPTION)
A	+ EXCITATION	+ EXCITATION
B	+ SIGNAL	+ SIGNAL
C	- SIGNAL	- SIGNAL
D	- EXCITATION	- EXCITATION
E	- SENSE	- SENSE
F	+ SENSE	+ SENSE
G	- RCAL	TEDS DATA
H	+ RCAL	TEDS GROUND
ALL READ UPSCALE IN TENSION

For more information visit Electrical Wiring Diagrams

Additional Information

Dimensions	2.75 × 2.75 × 1.50 in

Product Video

Short Description	Sku	Price
Model 1606 Series Gold Standard Calibration Grade Low Capacity Load Cell 50 lbf Capacity, PT01E-12-8P Bayonet-type Connector and comes with an ASTM E74 Class A Calibration	1606BGR-50	$ 2820
Model 1606 Series Gold Standard Calibration Grade Low Capacity Load Cell 100 lbf Capacity, PT01E-12-8P Bayonet-type Connector and comes with an ASTM E74 Class A Calibration	1606BGR-100	$ 2815
Model 1606 Series Gold Standard Calibration Grade Low Capacity Load Cell 200 lbf Capacity, PT01E-12-8P Bayonet-type Connector and comes with an ASTM E74 Class A Calibration	1606BGR-200	$ 2815
Model 1606 Series Gold Standard Calibration Grade Low Capacity Load Cell 300 lbf Capacity, PT01E-12-8P Bayonet-type Connector and comes with an ASTM E74 Class A Calibration	1606BGR-300	$ 2815
Model 1606 Series Gold Standard Calibration Grade Low Capacity Load Cell 250N Capacity, PT01E-12-8P Bayonet-type Connector and comes with an ASTM E74 Class A Calibration	1606BGR-250N	$ 2820
Model 1606 Series Gold Standard Calibration Grade Low Capacity Load Cell 500N Capacity, PT01E-12-8P Bayonet-type Connector and comes with an ASTM E74 Class A Calibration	1606BGR-500N	$ 2820
Model 1606 Series Gold Standard Calibration Grade Low Capacity Load Cell 1000N Capacity, PT01E-12-8P Bayonet-type Connector and comes with an ASTM E74 Class A Calibration	1606BGR-1000N	$ 2820
Model 1606 Series Gold Standard Calibration Grade Low Capacity Load Cell 1500N Capacity, PT01E-12-8P Bayonet-type Connector and comes with an ASTM E74 Class A Calibration	1606BGR-1500N	$ 2820
