Wireless Telemetry Systems 101

A wireless telemetry system enables the remote measurement and transmission of data from one location to another without the need for physical wired connections.  As technology continues to advance, wireless telemetry systems are becoming increasingly sophisticated, reliable, and secure, enabling them to be applied in a wide range of industries and use cases for test and measurement applications.

Interface offers a wide range of wireless telemetry products. Components in wireless telemetry systems typically include sensors, transducers, instrumentation, communication modules, transmitters, displays and printers.

The sensors are used to measure tension, compression, weight, torque, or any other measurable quantity. Interface utilizes proprietary strain gage sensor technologies. Transducers convert the analog signals from sensors into digital data that can be processed and transmitted to instrumentation.

Load cells are commonly used with wireless telemetry systems to measure and transmit data related to the force or weight applied to an object. The load cell converts the force exerted on it into an electrical signal, which can then be wirelessly transmitted to a remote monitoring system.

The most popular Interface wireless load cells are our WTS 1200 Standard Precision LowProfile® Wireless Load CellWTSTL Wireless Tension Link Load Cell, WTSLP Wireless Stainless Steel Load Pin and WTSSHK-D Wireless Crosby™ Load Shackle. Interface works with our customers to develop engineered-to-order wireless solutions by request.

The analog output from the load cell may require signal conditioning to ensure accuracy and compatibility with the wireless telemetry system. Signal conditioning can also be required for amplification, filtering, and analog-to-digital conversion to convert the analog signal into a digital format.

Wireless communications modules are responsible for transmitting the data over wireless channels. It can use various communication technologies like Wi-Fi and Bluetooth depending on the application’s requirements. The transmitter is responsible for wirelessly communicating the load data to the receiving end of the telemetry system.

There are various options for data collection. Data acquisition instrumentation is preferred in force measurement applications for the purposes of collecting vast amounts of the data from sensors and transducers and preparing it for transmission.

At the receiving end of the telemetry system, another wireless communication module receives the data from the load cell’s transmitter. Once the data is processed, it can be analyzed, logged, and displayed on a user interface, such as a computer dashboard or a mobile app. This allows operators, engineers, or users to monitor the load values in real-time and make informed decisions based on the data

Interface Wireless Telemetry System (WTS) Solutions

The Interface Wireless Telemetry System (WTS) offers flexibility by eliminating physical connections, making it easier to deploy sensors in remote or challenging environments. Wireless telemetry systems offer more flexibility in sensor placement and system configuration.

The absence of physical wires allows for easier repositioning or adding new sensors without significant infrastructure changes. This setup is particularly useful in scenarios where it is challenging or impractical to use wired connections, such as in large-scale industrial applications or when monitoring moving or rotating machinery.

Wireless Telemetry System Components

Wireless Transducers

Wireless Transmitters

Wireless Receivers

Wireless Output Modules

Wireless Displays and Instrumentation

This is a list of what types of products are available. The Interface WTS offering continues to grow with added products to the line. Check out the Wireless Modular System Overview for more system details.

Wireless Telemetry System Benefits

The Interface WTS is a wireless telemetry system that transmits high-quality data to single and multiple devices. It offers a wide variety of benefits, including:

  • High accuracy: The WTS offers measurement accuracy of ±0.02% of full scale, ensuring that you get accurate readings from your sensors.
  • High speed: It is a high-speed system that can transmit data at up to 1000Hz.
  • High resolution: The WTS has a resolution of 10,000 counts, which means that you can measure even slight changes in force.
  • Multiple configuration options: The WTS can be configured to meet a wide variety of needs. You can choose from a variety of transmitters, output modules, receivers, antennas, and displays.
  • Easy to use: It is a modular system that can be easily expanded to meet the needs of your application. It is supported by our powerful WTS Toolkit configuration software that makes it easy to set up and use.
  • IP-rated enclosures: The WTS transmitters and receivers are available in two different sized enclosures that are rated to IP67, making them dustproof and waterproof.

A major benefit of wireless telemetry systems is the ability to adapt and expand by adding additional sensors or devices to system, without the constraints of wireless and cables. They are easy to integrate, and installation is fast for immediate benefits.

Wireless telemetry seamlessly integrates with the Internet of Things (IoT) and cloud-based platforms, enabling centralized data storage, analysis, and easy access from multiple devices.

Read: Interface Wireless Telemetry System Review

Applications Using Interface Wireless Telemetry System Solutions

Aerospace: Wireless options are preferred for large projects like require careful movement and testing of aircraft, components and systems. Providing flexibility in real-time data without the cable is a huge benefit. See these WTS solutions for Aircraft Engine Hoist and Airplane Jacking System

Industrial Automation: Load cells with wireless telemetry are commonly used in industrial environments for weighing large objects, such as in material handling, manufacturing, and logistics. Check out IoT Lifting Heavy Objects.

Medical and Healthcare: Wireless medical telemetry systems are used for patient monitoring, such as in wearable health devices. In medical settings, wireless load cells are used in patient lifts and hospital beds to monitor patient weight and movement. Learn more in our Patient Hoyer Lift application.

Agriculture: The agriculture industry uses WTS for monitoring crop management programs and measuring the weight of produce, animal feed, or livestock. Check out this use case: WTS Equine Bridle Tension System App Note.

Energy: The energy industry utilizes wireless load cells and telemetry products for remote monitoring of oil wells, pipelines, and storage facilities. Check out Tank Weighing and Center of Gravity

Infrastructure: Civil engineers use WTS for assessing the health and integrity of structures like bridges and dams. Monitoring loads on structures like bridges and cranes to ensure safety and structural integrity. Check out Road Bridge Lift Monitoring.

Manufacturing: There are many examples of manufacturing WTS use cases. Wireless load cells are being used to monitor the weight of products as they move through the production line. This information can be used to ensure that products are meeting quality standards, and to identify any potential problems early on by fully utilizing the wireless telemetry capabilities.

Construction: In the construction industry, wireless load cells and telemetry systems monitor the load on beams and columns during construction to ensure that structures are safe and stable, and to detect any potential problems before they cause an accident. Check out Jib Crane Tension Monitoring.

Transportation: In the transportation industry, wireless load cells are being used to monitor the weight of cargo on trucks and trains to ensure that loads are not overloaded, and to comply with regulations. Read IoT Waste Management Container Weighing.

Automotive: The industry utilizes a number of machines and systems to test components used in the making of automobiles. Read how WTS is used in this brake testing application: WTS Brake Pedal Force Testing.

Entertainment: Protecting the artists, equipment and attendees is top of mind for all venues. Wireless systems are used to monitor environmental conditions, rigging, display mounts and more. Read Multi Stage Load Monitoring.

Integrating load cells with wireless telemetry systems provides a convenient and efficient way to monitor force or weight data remotely, allowing for real-time data analysis and enhancing the automation and safety of various processes.

If you are looking for a reliable and accurate wireless telemetry system, the Interface WTS is a great option. It is a powerful and versatile system that can be used in a wide variety of applications. and industry use cases.

Interface Airplane Static Testing Case Study

Interface is a preferred supplier of precision force measurement solutions for the aerospace industry and our products are frequently used to help perform critical testing on all types of commercial, industrial, and military aeronautical vehicles.

During the engineering and manufacturing of all types of aircraft, static testing is commonly used to validate designs and components, measure assembly and affirm performance and regulatory requirements. Accuracy and reliability of any type of sensor and instrumentation used during these tests is vital to the testing programs and ensures the safety for pilots, passengers and the public at large when these vehicles take flight.

What is a static test?

Static testing is a type of structural test which allows engineers to analyze an aircraft’s structural integrity while grounded. This is a useful part of the testing process before taking flight, which helps speed up the certification process as it does not require a completed and fully functional aircraft through the entire manufacturing process for aerospace vehicles.

How does Interface place a role in static testing for aircraft?

Our force measurement solutions such as precision load cells and torque transducers play an important role in static testing as force analysis results are used in nearly all structural tests. Interface manufacturers both off-the-shelf and custom solutions that are used by leading part and aircraft manufacturers. These sensor products are used on a static test stand to test frame structure integrity, endurance, and life cycles, with the goal generally being to validate aircraft design and ensure specified criteria are met. The strict accuracy is necessary because in aerospace, every micrometer and gram make a difference in both the performance and safety of an aircraft design.

Static Testing Applications for Airplane Jacking System and Jet Engine Thrust Tests

In the new Airplane Static Testing case study, we have detailed two application examples and how Interface products are specifically used in in static testing of aircraft. These examples demonstrate how our products are applied and utilized for testing an airplane jacking system and provide a solution for a jet engine thrust test.

In the airplane jacking system static testing application, our WTS 1200 LowProfile® Wireless Load Cells are placed on jack points measuring weights and forces on an aircraft. Our advanced Wireless Telemetry System provided instrumentation to capture real-time data, such as the individual load cells attached to each jack point, or any set alarms that may go off if it has exceeded a certain amount of force.

For the jet engine thrust static testing, Interface’s 1000 High Capacity Fatigue-Rated LowProfile™ Load Cell was best suited for this static testing. The load cell reacted to the thrust forces produced by the jet engine and the signals were collected and recorded to create a “thrust curve” of the engine.

To read the Airplane Static Test case study it in full, go here.

To learn more about the many ways Interface can serve the aerospace industry with premium force products and total solutions, watch this video to see the types of products we supply for static and other test and measurement programs in this industry.

Additional Resources

Examining Interface Aerospace Industry Solutions

Aerospace Brochure

Solutions Provider for Aerospace & Defense

Taking Flight with Interface Solutions for Aircraft Testing

Aircraft Screwdriver Fastening Control

Aerospace and Defense Industry Solutions

Aerospace and Defense Case Study



Interface Crane Use Cases and Application Notes

Manufacturers and engineers of heavy equipment are rigorous about the design quality, performance and most importantly preserving safety. Having tools to test and monitor this type of equipment allows equipment producers and users to review performance at all stages, ultimately maintaining a safe working environment which is critical to any construction, transportation, or infrastructure project job site. That’s why Interface provides quality force measurement products for a host of industrial equipment machines to accurately measure force, load capacity, weight, tension and more.

Interface has been a long-time supplier of force and torque sensors along with instrumentation products for projects involving all types of cranes and lifting machines. We are frequently asked to provide crane force measurement solutions for applications used in hoisting, lifting, moving, and transporting heavy objects. These use cases range across all types of environments, from constructing high rises in metropolitan centers around the world to maritime industry users loading docks and lifting watercraft.

To outline how force measurement is used to monitor cranes, we developed a series of application notes explaining the components Interface provided to allow our customer to measure safety, reliability, and efficiency of their equipment.

Crane Capacity Verification

The first application note outlines a project in which the customer wanted to verify that their crane was strong enough to safely lift a heavy load at its rated maximum load capacity. It was determined that because of the size of the crane, a wireless solution was needed to avoid long wires and burdensome installation. Interface provided a WTSTL Lightweight Wireless Tension Link Load Cell to measure the load’s maximum capacity. WTS-RM1 Wireless Relay Output Receiver Modules were also used to trigger an alarm that can be set when the maximum capacity of weight/force has been reached. To review the data the customer could transmit the data to a PC or laptop with a WTS-BS-4 USB base station. The data can also be reviewed through a WTS-BS-1-HS Wireless Handheld Display. With this solution, the customer was able to verify if the crane is safe and functional enough to lift it’s working load limit (WLL), or safe working load (SWL) capacity.

Read the full Crane Capacity Verification Application Note here.

Crane Block Safety Check

The next example features a crane application in which the customer wanted to detect whether a crane block could lift a heavy load securely to keep working conditions safe for personnel. The customer specifically wanted the solution to include an alarm feature that notified them if lifting capacity was exceeded in real-time. Using a WTSLP Wireless Stainless Steel Load Pin in place of a load bearing pin in the crane block, they could measure the force being applied by the heavy load. Data will be transmitted and displayed through both the WTS-BS-4 USB Base Station. It can also be paired with the WTS-BS-1-HA Wireless Handheld for real-time safety monitoring. The WTS-RM1 Wireless Relay Output Receiver Module triggers an alarm when maximum capacity has been reached. The customer was able to verify if the crane was operating safely and was always functional enough to lift it’s working load limit (WLL) or safe working load (SWL) capacity. The added alarm feature is critical for notifying users when the crane reaches unsafe limits during operations.

Read the entire Crane Block Safety Check Application note here.

Crane Force Regulation

In the final application note, a customer wanted to regulate the maximum number of heavy loads being lifted, so that production time was both safe for workers and efficient. The goal was to complete lifting duties faster and with little or no expense. A wireless solution was also preferred, so that there would be no long cable interference during production. Interface supplied a WTSLP Wireless Stainless Steel Load Pin, which can be custom made to be used for any and all types of cranes. It is also great for lifting both short and long distances. The load pin was paired with the WTS Wireless Telemetry System, where force could be measured and logged. The customer was able to monitor the continuous force from the crane, and gather information on loads being lifted for continuous safety and production reporting requirements.

Read the complete Crane Force Regulation Application Note here.

You can read more about heavy equipment testing and use cases in our post, Force Measurement Solutions for the Construction Industry.
