Interface Load Cell Indicators

At Interface, our claim to fame is that we offer the most accurate and reliable force measurement devices on the market, from load cells to torque transducers and everything in-between. However, no test is complete without the system used to gather the data to evaluate performance results. That’s why we provide a wide variety of instrumentation solutions that include signal conditionersoutput moduleshigh speed data loggersportable load cell indicators, and weight indicators to complete any testing system.

Among the Interface instrumentation products, the most frequently purchased with a force measurement devices are our load cell indicators in various models including handheld, digital, wireless, multichannel, programmable, output modules, analog and bidirectional.

What is a load cell Indicator?

A load cell indicator is a high-accuracy device connected to the output of a load cell to amplify and display the value of the measured load force and weight. Load cell indicators are often needed where the force, load, or weight measurement needs to be visually displayed for the user and displaying the results on a PC is not feasible or desired in the testing environment. For example, testing in the field or confined spaces can make it impossible to connect directly to a PC. In these situations, indicators are used to quickly review and capture force data in real-time.

A few key benefits of load cell indicators include that they provide stable excitation voltage and converts force measurement sensor signals to a digital display. Commonly available features include analog or digital output, selectable digital filtering, peak and valley monitoring and set-point outputs. Additionally, each load cell indicator can be used to connect to four (or more) digital load cells and can display individual readings or the sum of all connected load cells.

Need a load cell indicator?

Interface offers a wide variety of load cell indicators in multiple configurations. Interface indicators come in single to multi-channel weight transmitters and can be found in handheld and portable designs. Things to consider when selecting an indicator are internal sample rate and update rate of the output. A few of our most popular indicators include:

9890 Strain Gage, Load Cell, & mV/V Indicator

Model 9890 is a powerful multipurpose digital load cell meter ideal for weight and force measurement applications. With a max current of 350 mA at 10 V, it can support up to 12 load cells making it perfect for multipoint weight measurement purposes. The dual-scale capability allows for displays in two different units of measure. See a demonstration video here.

9320 Battery Powered Portable Load Cell Indicator

Model 9320 is a bipolar 7-digit handheld meter featuring two independently scalable ranges, peak and valley monitoring, display hold, mV/V calibration, and a power save feature. Typical battery life exceeds 45 hours of continuous use and 450 in low power mode. IEEE1451.4 TEDS Plug and Play compliant.

482 Battery Powered Bidirectional Weight Indicator

Model 482 is battery powered, bidirectional, and comes in a NEMA 4X stainless enclosure. Standard options include 523,000 internal counts, 0.8-inch LCD 6-digit display and a measurement rate that goes up to 40 Hz. Available options include analog and relay outputs.

1280 Programmable Weight Indicator and Controller

The Interface 1280 Series programmable digital weight indicator with color touchscreen, web server view and multiple protocol types delivers uncompromising speed for today’s operations and expansive options for tomorrow’s requirements.

INF4-Ethernet IP Weight Transmitter and Indicator

The Interface INF4-Ethernet IP weight transmitter and indicator has a six-digit red LED display (8 mm height), space-saving compact design, four buttons for the system calibration, and a six-indicator LED.

See all the indicator options here.

Load Cell Indicator Application Note

The application note below provides an example of the benefit of a load cell indicator in real-world use within the medical industry.

A pharmaceutical tablet producer wanted to monitor the forces applied by the tablet forming machine to understand the relationship between raw material, die set, forming force, and motor-cycle speed. The goal was to improve productivity and efficiency of the tablet forming process while reducing losses, such as cracked tablets or voids, by adding a dimension of feedback that could be used to assign specific press adjustment criteria for given inputs.

An Interface Model WMC Sealed Stainless Steel Mini Load Cell (10K lbf Capacity) was mounted in the section of the downward press bar. The machine was modified to accomplish this. The load cell was then connected to a Model 9320 Portable Load Cell Indicator to collect the needed data.

The indicator was selected as the data collection device because a laptop could have interfered with the test cycle due to space restrictions. The output of the load cell was connected to the 9320 Portable Load Cell Indicator and set aside so that the cable did not interfere with the cycle and no snagging would occur. A cable tie was used to stow aside the cable and to ensure there was enough clearance for the entire cycle.

After analyzing the data, the tablet producer was able to quantify adjustment levels by monitoring which forces produced the most optimal results for a given cycle speed, die set, and raw material. Productivity and efficiency were greatly improved by the enhancement of the data feedback.

To learn more about Interface load cell indicators and for a complete list of products, you can download our instrumentation brochure here. You can also read more about instrumentation options in test and measurement in this post.

Instrumentation Options in Test and Measurement

Force and torque measurement technologies such as load cells and torque transducers are a single part of an overall system often used for test and measurement projects and programs. Instrumentation is also a key component of force and torque measurement systems. Instrumentation tools are functional for visualizing and logging the sensor data.

When considering all the options for your project, product designers and engineers need to evaluate the type of instrumentation required to read and gather the sensor output and display the results.

Common questions to ask in preparing your test and measurement project, building a system or setting up a lab:

  • Where are you going to connect your sensor technology and how?
  • Do you need to store your data?
  • Do you prefer an analog or digital output device?
  • Are you going to plug-in your instrumentation or use hand-held, wireless or Bluetooth connectivity?
  • How will your data output be displayed?
  • How many channels do you need for your project or program?

These are all questions related to instrumentation devices and how they interact with and connect to your test and measurement products. Because of the wide variety of instrumentation options, from transmitters and indicators to data logging, it is critical to carefully review the features, specifications, capacities for each. Engineers and testers should review capabilities for data collection of a device, connectors and adapter requirements, and how the device works with specific types of load cells, torque transducers, multi-axis sensors, and other testing equipment.

A valuable tip is to spend time reviewing the specifications of any instrumentation device you are considering, as well as speak with an experienced application engineer. The critical model and design details are provided in the product datasheet to help in your selection.

Key areas to consider in your review and design of a force and torque measurement systems include:

  • Excitation
  • Outputs
  • Performance standards
  • Environmental performance
  • Power
  • Mechanical definitions
  • Connections
  • Protocols

There are dozens of instrumentation options available through Interface including signal conditionersoutput moduleshigh-speed data loggersportable load cell indicatorsweight indicators, and junction boxes. Here are some of our latest additions and most popular instrumentation products:

Download our Instrumentation Brochure
Download our NEW Digital Instrumentation Brochure

Terms and Definitions

To help get you started on the process of selecting the right instrumentation for your project, we have compiled a list of common terms used for instrumentation and in force measurement and sensor technology product descriptions.

  • Accuracy: The closeness of an indication or reading of a measurement device to the actual value of the quantity being measured. Usually expressed as ± percent of full-scale output or reading.
  • Adapter: A mechanism or device for attaching non-mating parts.
  • Amplifier: A device that draws power from a source other than the input signal and which produces as an output an enlarged reproduction of the essential features of its input.
  • Analog Output: A voltage or current signal that is a continuous function of the measured parameter.
  • Analog-to-Digital Converter (A/D or ADC): A device or circuit that outputs a binary number corresponding to an analog signal level at the input.
  • Bluetooth: A standard for the short-range wireless interconnection of mobile phones, computers, and other electronic devices.
  • Bus Formats: A bus is a common pathway through which information flows from one computer component to another. The common expansion bus types include, Industry Standard Architecture (ISA), Extended Industry Standard Architecture (EISA), Micro Channel Architecture (MCA), Video Electronics Standards Association (VESA), Peripheral Component Interconnect (PCI), PCI Express (PCI-X), Personal Computer Memory Card Industry Association, (PCMIA), Accelerated Graphics Port (AGP), Small Computer Systems Interface (SCSI).
  • Calibration: Process of adjusting an instrument or compiling a deviation chart so that its reading can be correlated to the actual value being measured.
  • Communication: Transmission and reception of data among data processing equipment and related peripherals.
  • Controller: Controllers deliver measurement and control functions that may be used in a wide variety of applications. They feature compact form and versatility in systems that require precise measurement of weight or force combined with processing and storage.
  • Digital Output: An output signal which represents the size of an input in the form of a series of discrete quantities.
  • Environmental Conditions: All conditions in which a transducer may be exposed during shipping, storage, handling, and operation.
  • Frequency: The number of cycles over a specified time period over which an event occurs. The reciprocal is called the period.
  • Indicator: Load cell indicators are often needed where the force, load or weight measurement needs to be displayed to a user visually and displaying the results on a PC is not feasible.
  • Intelligent Indicator: Intelligent Indicators ensure sensor equipment is used for the correct amount of time, thereby helping to safeguard against mistakes or purposeful misuse.
  • Output: The electrical signal which is produced by an applied input to the transducer.
  • Protocol: A formal definition that describes how data is to be exchanged.
  • Range: Those values over which a transducer is intended to measure, specified by its upper and lower limits.
  • Signal Conditioner: A circuit module which offsets, attenuates, amplifies, linearizes and/or filters the signal for input to the A/D converter. The typical output signal conditioner is +2 V dc.
  • Strain Gage: A measuring element for converting force, pressure, or tension into an electrical signal.
  • Transducer Electronic Data Sheet (TEDS): Provides a force or torque transducer with electronic identification, allows sensor instrument to be “Plug & Play Ready” meets IEEE 1451.4
  • Wireless: Broadcasting, computer networking, or other communication using radio signals, microwaves, and other signals.

If you still have questions about load cells, torque transducers, and the instrumentation options please give us a call at 480-948-5555 or visit www.interfaceforce.com.

For some of the key terms, we used an online reference you can find here: Source

Interface Products Available to Buy Online with QS48 E-Commerce Service

The new QuickShip48® e-commerce service from Interface provides customers with an easy way to get the industry-leading force measurement products quickly and shipped within two business days.

The new QS48® Now service brings hundreds of Interface’s highest in-demand load cells, mini load cells, torque transducers, multi-axis sensors, indicators, and signal conditioners to customer’s doorsteps within a few days for their important test and measurement projects.

“As the pace of innovation continues to accelerate in the digital age, our customers need reliable and accurate test and measurement tools quickly. Our new online QuickShip48 e-commerce service guarantees fast access to in-demand products to meet our customer’s urgent development schedules and helps them get their innovations tested and to market faster.” Joel Strom, CEO, Interface

QS48 TruckInterface has hundreds of in-stock force measurement products available with the one-stop online shopping experience. The QuickShip48 accelerated e-commerce service offers a wide range of Interface’s readily available products that can be purchased with a credit card and shipped within two business days. All QS48 Now products ship from the company’s manufacturing headquarters in Arizona and are sent with expedited shipping to arrive within three to five days within the U.S.

Popular Interface products in multiple capacities and models are now available for online purchase at new QS48 e-commerce store, including:

For a complete list of QuickShip48 Interface products that are available for online purchase and 48-hour shipment, visit our new QS48 store at https://quickship.interfaceforce.com/.

If you need a quote or a custom solutions request, contact our experienced Application Engineers or connect with our local Representatives and International Distributors for assistance.



Force Measurement Instrumentation 101

There are many types of instrumentation devices used in force measurement applications. Interface provides high-quality instrumentation tools to use with our wide range of load cells and torque transducers.

The variety of instrumentation solutions includes signal conditioners, output modules, high-speed data loggers, portable load cell indicators, weight indicators, and junction boxes.

Depending on the application requirements, Interface has solutions for full-data acquisition as well as wireless technology telemetry systems. Our multi-channel bridge amplifier has 4-channel capability, while the INF-USB2 universal serial has a sensor to USB output converter.  With more than 50 instrumentation products, the solutions range for all types of uses.

To provide you with more insight, here’s an overview of a few of Interface’s instrumentation offerings along with educational video demonstrations to help you.

4 Channel 9840-400-1-T Intelligent Indicator

The Model 9840 is TEDS plug-and-play ready! It is suitable for use in calibration labs, field service, or anywhere high accuracy is important.  This intelligent digital indicator has auto-setup for multiple load cells with fast, direct analog output.  Features include two interactive 7″ graphical touch screen displays, remote sense, low noise, 24-bit internal resolution. It has a USB port with RS232 communication, mV/V calibration and can store calibrations for up to 25 sensors.  This unit also has self-calibration and is TEDS plug and play ready and IEEE 1451.4 compliant. It is fully compatible with the Gold Standard® Calibration Systems.

9860 High Speed Digital Indicator

Recently updated with new software, Interface’s Model 9860 High Speed Digital Indicator features an internal, high gain, fully differential amplifier with a 16-bit analog-to-digital converter combined to accurately digitize the input signal. The analog input is digitally filtered, with user-selected sample size and filter window (band), allowing optimization for specific operating conditions. With this model, self-calibrating ±10Vdc and 4-20mA analog output signals are standard. This product has an RS232 interface, which gives the instrument the ability to communicate, command, query operating modes and parameters and to continuously read data.

The Interface Transducer Electronic Data Sheet (TEDS) status indicator on the Model 9860 provides the information on the configuration of the input. A front panel RCAL switch provides a convenient calibration feature. Both calibration functions are easily performed via front panel pushbuttons.

Watch this video to learn how to calibrate your 9860 High Speed Digital Indicator and to see some of the product features.

DIG-USB Output Module

Interface’s DIG-USB Module is a compact, high-precision strain gage converter used for converting a strain gage sensor input to a digital output. It connects to a computer via a USB port. This product allows high precision measurements to be communicated directly to a computer and is aimed at applications which require high-accuracy measurement repeatability. With the appropriate drivers installed, the DIG-USB appears as a virtual serial port to the computer.

Simply by plugging the device into a computer, data can be extracted from most strain gage bridge input sensors and acquired by software which allows data manipulation removing the need for amplifiers, filters, and multi-meters.

Watch this video for a getting started demonstration with the DIG-USB Output Module.

9890 Strain Gage Indicator

Our 9890 Strain Gage Indicator is a full-featured multipurpose and easy-to-use digital strain gage and load cell meter ideal for weight and force measurement applications. With a max current of 350 mA at 10 V, it can support up to twelve 350 Ω load cells (minimum load resistance of 28 Ω), making it ideal for multipoint weight measurement applications. It accepts mV input signals up to 300 mV (unipolar) and ± 250 mV (bipolar). The 9890’s powerful dual-scale capability allows the measurement to be displayed in two different units of measure.

This video provides an overview of the 9890 Strain Gage Indicator and how it works.

920i Programmable Weight Indicator/Controller

The Interface 920i instrumentation device is a programmable, multi-channel digital weight indicator and controller. The configuration can be performed using the front panel, with an attached USB-type keyboard (or PS/2 keyboard if using a serial interface), or by using the iRev 4 utility. Model 920i is bidirectional and comes in a NEMA 4X stainless enclosure. Standard options include 8,000,000 internal counts, 4.6 x 3.4-inch LCD 7-digit display and a measurement rate that goes up to 960 Hz. Options are available that allow you to include analog and relay outputs.

This video provides an easy-to-follow getting start guide for the 920i Programmable Weight Indicator/Controller.

These are just a few of the dozens of instrumentation solutions Interface offers, all designed for unique application needs.  For more information on Interface’s instruments, visit our web product page or review our product brochure for detailed specifications on every product.

Instrumentation Brochure

DOWNLOAD

Visit Interface’s YouTube channel for all our indicator and product video demonstrations at https://www.youtube.com/interfaceforce and be sure to subscribe to stay current with our new releases.
