Why Civil Engineers Prefer Interface Products

Infrastructure is one of the most vital industries that utilize Interface force measurement solutions. Our products are chosen for the design, engineering and construction of public works projects including roads, energy structures, bridges, dams, airports, sewage systems, and pipelines.

Civil engineering is a professional discipline that deals with the design, construction, and maintenance of the physical and naturally built environments. It’s the oldest engineering discipline after military engineering, and it was specifically defined to distinguish non-military engineering from military engineering.

Civil engineering is traditionally broken into several sub-disciplines including environmental engineering, geotechnical engineering, structural engineering, transportation engineering, municipal or urban engineering, water resources engineering, materials engineering, coastal engineering, surveying, and construction engineering.

Civil engineers choose Interface sensors for testing structural components as well as for embedding sensors within buildings, waterways, and railways to ensure sustainable and safe construction, modifications, improvements, repairs and use.

Civil engineers’ relationship with and use of force measurement devices is based on two things: testing designs and monitoring completed projects.

Load cells are used from a test perspective throughout the development of infrastructure projects. For example, load cells test specific materials used in the construction of a building to ensure they can handle the required weights and environmental conditions. In the design of a drawbridge bridge, engineers use load cells to test the hydraulic system to ensure it will provide enough force to lift the bridge from a single time to thousands of times by using stress test rigs.

The use of various sensors and measurement devices in civil engineering and construction sectors has grown significantly in recent years. The sensor data from Interface load cells is utilized in every aspect, from rugged construction equipment for regulatory and safety monitoring to real-time quality monitoring of physical structures. One of the reasons is due to the advances in monitoring and reporting capabilities of sensor data. Accessibility to data has improved the ability to use it for complex calculations as well as analyze enormous amounts of output information in real-time. The benefits are improvements in structural designs and overall engineering as a result.

By accessing data remotely through Interface digital instrumentation products, those within the industry can deploy more practical solutions than were historically impossible during some of the original designs. This has transformed approaches to force measurement and load monitoring, providing robust calculations in structural and material engineering. This functionality is why civil engineering sectors rely on Interface for advanced products that deliver accurate, quality and reliable performance.

The following video highlights many products utilized in the infrastructure industry by civil engineers and for the equipment used in construction of their designs.

Force measurement is even used by civil engineers in testing the construction equipment used in a variety of infrastructure projects. One example of this is when Interface supplied a force measurement system to construction engineers to test an aerial lifts capabilities and capacities for safe use.

Aerial Lift Overload Control

A manufacturing company for aerial lifts wanted to test its self-propelled boom lift to ensure it can operate at heavy capacities when in use, and at different angles. They also wanted to prevent any accidents in case of a lifting overload, for the safety of any working individual who uses it. Interface’s solution was to attach the 3A160 3-Axis Force Load Cell to the bottom of the bucket of the boom lift. The 3A160 3-Axis Force Load Cell gave high accuracy results, which can be displayed using the 920i Programmable Weight Indicator and Controller in real time. The manufacturing company tested their aerial boom lifts and determined it was safely operable when maximum capacities had been reached.

Adversely, engineers are also designing force sensors into projects allowing them to monitor the effects of force on certain infrastructure over time. Take for example a project that Interface was involved in that required the monitoring of a bridge.

Bridge Seismic Force Monitoring Solution

A customer wanted to monitor seismic activity that occurred to a bridge by using force sensors, and then continuously monitor bridge forces before, during and after earthquakes. Engineers on the project also preferred a wireless solution so they would not need to run long cables on the bridge. Using Interface’s LP Load Pin custom made to fit their needs, along with Interface Inc. WTS Wireless Telemetry System, continuous force monitoring was able to take place without long cables. The engineers were then able to monitor continuous loads, log information to the cloud and review information, ensuring the bridge would uphold over time and constant seismic activity. Or, allowing engineers to determine when and where repairs are necessary.

Civil engineers represent the minds and hands building critical infrastructure. This is why Interface works closely with those in this profession to ensure our sensors provide the highest quality, accuracy and reliability to keep people safe and moving across our country. To learn more about our work in infrastructure, please visit our Interface Infrastructure Solutions.

Additional Resources

Interface and Infrastructure Markets Form a Perfect Partnership

Infrastructure Industry Relies on Interface Force Measurement

Interface Solutions Designed for Infrastructure Challenges

Infrastructure Projects Rely on Interface

Monitoring the Seismic Force of a Suspension Bridge

Infrastructure-Brochure-1

Interface and Infrastructure Markets Form a Perfect Partnership

Infrastructure projects are growing, as investment continues to climb for projects related to rebuilding, renewing and innovating applications in this sector. These global investments come from public and private organizations as demands to address roads, bridges, water supplies, transportation, energy systems, and broadband requirements for the 21st century grow.

Experts who focus on infrastructure acknowledge these are means for civil existence and prosperity. Interface understands that our role in supporting the design, testing, manufacturing, constructing and maintenance required in infrastructure needs a top supplier of force measurement solutions.

Interface force measurement solutions have and are currently used around the world for infrastructure projects including bridges, generators, dams, waterways, transportation structures, construction projects, cranes and lifting apparatus, and heavy machinery.

Interface supplies durable and accurate sensor technologies used in testing equipment, technology, vehicles, tools and machines used in all types of infrastructure subsectors. We also find our products often designed into structures for regulatory and safety monitoring, whether that be to maintain tunnels or support wind generating farms.

Interface details force measurement products we commonly provide to those working and supporting the infrastructure sector in our Infrastructure Solutions Brochure. You can see some of these products in our Infrastructure Solutions video.

Interface load cells, load pins, instrumentation, multi-axis sensors, and torque transducers are top choices for those engaged in infrastructure projects and testing. Sensors are commonly used in measuring the related hardware used for industry products and structures. The types of infrastructure projects that Interface has supplied measurement solutions for includes transportation systems, communication structures, water and electrical facilities, and numerous inventions that are used to build, support, and maintain them, as outlined in Infrastructure Projects Rely on Interface.

Our expert engineers can help design customizable force measurement solutions for all types of applications that require sensors for OEMs and to be used in the actual structure for continuous measuring and monitoring. We have engineered sensor products used for civil engineering designs and infrastructures used in structural monitoring, vibrational monitoring, load bearing testing, tunnels, bridges, and road construction. The range of projects are broad, so we are highlighting a few below that highlight our capabilities when accuracy, quality and reliability matter in design, testing, construction, and assessing current and limitations for safety requirements.

Hydraulic Jacking System Testing

An equipment manufacturer needed to test their hydraulic jacking system’s ability to lift heavy loads and objects, like a bridge during construction. They wanted to monitor the forces being applied to ensure the hydraulic jack is not only safe to use, but works well enough to avoid any potential structural issues. Interface’s 1200 Standard High Capacity Load Cell can be attached in between the hydraulic jack and a heavy load. The load cell measures the forces of the hydraulic jack as it lifts the load cell located in between the jack and the object. With the 9890 Strain Gage, Load Cell, & mV/V Indicator, the customer is also able to see the results in real-time. Read more here.

Aerial Lift Overload Control

A manufacturing company for aerial lifts wanted to test its self-propelled boom lift to ensure it can operate at heavy capacities when in use, and at different angles. They also wanted to prevent any accidents in case of a lifting overload, for the safety of any working individual who uses it. Interface’s solution was to attach the 3A160 3-Axis Force Load Cell to the bottom of the bucket of the boom lift. The multi-axis sensor provides high accuracy results, which were displayed using the 920i Programmable Weight Indicator and Controller in real time. The manufacturing company tested their aerial boom lifts and determined it was safely operable when maximum capacities has been reached in use. Read more here.

Truck Weighbridge Monitoring

A transportation company needed to record the weight or loads being carried by their vehicles. They would like a wireless weighing bridge that is able to transmit, log, and display the results in real time. Interface suggests installing multiple WTS 1200 LowProfile™ Load Cells under a weighbridge. When a truck drives over it, the load cells will transmit the force results wirelessly to the WTS-BS-4 Industrial Base Station connected to the customer’s PC with provided Log100 software. The WTS-LD2 Wireless Large LED Display can also display the weight inside for the driver to see in real time. The customer was able to measure, log, and graph the different loads their trucks carried wirelessly onto the weighbridge with success, providing for safe passage across transportation ways. Read more here.

Hydropower Turbine Generator Monitoring

A customer wanted to monitor and detect any turbine generator faults in their hydroelectric power plant located on a river. Interface’s solution was to use the T2 Ultra Precision Shaft Style Rotary Torque Transducer and attach it to the turbine generator with Interface’s Shaft Style Torque Transducer Couplings. When water from the river pushes through the penstock to the outflow, it moves the turbine blades, creating electricity through the generator shaft. Torsion measurements can be graphed and logged with the 9850 Torque Transducer and Load Cell Indicator catching any unusual fluctuations and vibrations. Using this solution, the customer was able to monitor, graph, and log the torque measurement results of the turbine generator. Read more here.

Bridge Seismic Force Monitoring

A customer wanted to monitor seismic activity that occurs to a bridge by using force sensors and then continuously monitoring bridge forces before, during and after earthquakes occur. The customer also preferred a wireless solution so they would not need to run long cables on the bridge. Using Interface’s LP Load Pin custom made to fit their needs along Interface’s WTS Wireless Telemetry System for continuous force monitoring the designed solution was able to take place without long cables. The solution allowed the customer to monitor continuous loads, log information to the cloud and review information. Read more here.

Interface’s work with all facets of the infrastructure industry spans far and wide. Interface is a supplier of choice and key partner for providing reliable sensors and instrumentation solutions used in testing and monitoring of both the infrastructure and the equipment used to upgrade and refine it.
