The Criticality of Thrust Measurement Testing in Aerospace

Interface is a force measurement solutions provider for many of the largest and most innovative aerospace and space systems organizations. Our measurement devices are utilized to test various aircraft and space vehicle components, including thrust testing for jet engines, gas turbines, and propulsion systems.

Thrust measurement is critical when designing and developing aircraft and spacecraft. These critical measurements are used to build and test rocket engines for launch vehicles and missiles. Thrust testing is also vital for maintenance and quality inspections of vehicle engines and systems. By measuring thrust over time, engineers can identify any potential engine problems and take corrective action before they cause a failure.

Thrust measurements ensure rocket and airplane engines produce enough thrust to safely launch, fly, and land. If an engine is not producing enough thrust, it could lead to a catastrophic failure. Trust testing also helps to improve fuel efficiency and reduce emissions.

The force emitted by a thrust engine dictates the size and speed at which a payload can be lifted off the ground. Enormous amounts of thrust are needed to get a spaceship out of the Earth’s atmosphere or propel a jet engine to move faster than the speed of sound. Thrust must be measured precisely because applying too much thrust to an aircraft may damage it, or using too much thrust at a rocket’s liftoff can use too much fuel.

Interface force sensors provide extremely accurate data to assess the amount of force, helping engineers tune thrusters to provide the right amount of force for the size and speed needed to launch or lift their vehicle.

Thrust is measured by placing the thrust engine on a test stand. Then, as the rocket engine burns fuel and creates thrust, the force of the thrust creates compression force on the load cell sensor. As this happens, a mechanical signal is converted to a digital signal, and this data is sent back to the engineer through a data acquisition device, who can then assess, monitor, and record that data.

A load cell used to measure thrust force must be rated for extreme heat. A typical load cell could not provide an accurate measurement when placed in a temperature environment that the sensor’s materials could not handle. Interface offers a wide range of load cells rated explicitly for this type of testing.

To give you a sense of the power and environment of thrust testing, you can see the thrust test of a jet engine in action posted on the U.S. Defense News YouTube channel.

Jet Engine Thrust Testing Application

A customer wanted to conduct a static jet engine thrust test that could accurately determine the engine’s thrust, burn time, chamber pressure, and other parameters, providing invaluable data to propellant chemists and engineers. They needed a high-accuracy load cell with excellent repeatability to withstand thrust forces in very harsh environments. From ignition to burn-out, Interface’s 1000 High Capacity Fatigue-Rated LowProfile™ Load Cell was ideally suited based on their performance for this application.

The load cell reacted to the thrust forces produced by the jet engine, and the signals were collected and recorded to create a “thrust curve” of the engine. The performance of an Interface LowProfile™ Load Cell allowed engineers to be confident in the data acquired from the static testing. Additionally, the repeatability of the load cell resulted in reduced time between tests, making static jet engine thrust testing more efficient. The 9330 battery-powered high-speed data logging indicator captured the data for analysis.

Thrust measurement ensures safety, reliability, and performance.

Interface is a long-time provider of  Aerospace and Defense Industry Solutions.  Here is another video to watch to learn more about Interface’s role in aerospace innovation.

Go here to learn more about thrust and other force test examples in the aerospace industry.

ADDITIONAL RESOURCES

Taking Flight with Interface Solutions for Aircraft Testing

Enabling A Look Way Beyond Yonder

Aerospace Solutions

Interface Space Economy Solutions

The Aviation Industry Soars Using Interface Solutions

Solutions Provider for Aerospace & Defense

Are Load Cells Used in Vacuum Environments?

Vacuum testing labs are essential for ensuring that products and materials are safe and dependable in vacuum environments. A vacuum environment is an area where there is little or no matter. This means that there are very few gas molecules present, and the pressure is incredibly low. Vacuum environments are often created using vacuum pumps, which remove gas molecules from an enclosed space.

Vacuum environments are used to simulate the conditions that products and materials will experience in space or other high-altitude environments. These types of testing labs typically have a vacuum chamber that can be evacuated to an incredibly low pressure. The vacuum chamber is then used to evaluate products and materials for a variety of properties. Engineers use vacuum environments in testing for reduced contamination, improving heat transfer, and to reduce the weight of products.

Tests performed in vacuum labs are used to determine the rate at which gases are released from a product or material and the ability of a product or material to withstand a vacuum without leaking. Thermal cycling tests are done to assess the ability of a product or material to withstand changes in temperature in a vacuum environment. Other tests are done to understand how the test article withstands exposure to radiation.

Vacuum testing labs are used by a variety of industries, including aerospace, medical, and defense. These labs are common for material process testing and used in R&D. Vacuum testing helps to identify potential problems with products and materials before they are used in a real vacuum environment. Engineers use this type of testing to improve the performance of products and materials and ensure they meet the required standards. Contact Interfaced to explore your options.

Can load cells be used in a vacuum environment?

Load cells can be used in a vacuum environment. However, not all load cells are created equal or suited for this specialized use case. Some load cells are designed that make them appropriate for vacuum environments, while others are not. Load cells that are not engineered to perform in vacuum environments may not be able to withstand the low pressures and outgassing that can occur in a vacuum. Using quality load cells that are manufactured by force measurement experts in sensor technologies is important in any consideration. It is critical to review the specifications and requirements with a qualified applications engineer.

Key considerations when choosing a load cell for a vacuum environment:

  • Outgassing: Load cells that are used in vacuum environments will have low outgassing rates. This means that they will not release gases into the vacuum chamber, which can contaminate the environment and interfere with measurements.
  • Mechanical strength: Load cells must be able to withstand the low pressures that can occur in a vacuum. They will also be able to withstand the conditions that can be generated by vacuum processes, such as outgassing and condensation. Form factor and model material of the load cell are important in choosing a load cell for this use case.
  • Temperature range: Load cells will need to operate in a wide range of temperatures. This is important because vacuum chambers can be very cold, especially when they are first evacuated, or when they are used to simulate high altitudes or space.

If you are looking for a load cell that can be used in a vacuum environment, please review with Interface application engineers to determine if the model fits your test requirements. We also can offer custom solutions to ensure that the load cell maintains the accuracy and performance specifications based on your exact test plan.

Can a load cell be vented for use in a vacuum testing lab?

Technically yes, you can vent a load cell to be used in vacuum. This allows the internal cavity of the load cell to equalize with external vacuum. However, this does not prevent outgassing and can cause the gages and wiring to be subject to humidity and condensation.

Cabling is extremely important when using any sensor in this environment. There are options to make the load cells wireless using Bluetooth technology.

Caution: Interface recommends that all our products used in this type of environment are designed, built, and calibrated for use in this environment. Venting an existing load cell can alter the performance and damage the cell.  By designing the load cell with venting for use, we can ensure that it will meet the vacuum test range.

Interface also can install thermocouples to work with the sensor to detect temperature in this type of testing environment. In fact, our engineers have designed load cells to package the thermocouples inside the form factor for convenience and performance benefits.

Interface engineers have worked with testing labs for decades. We are available to assist with any use case requirements to determine the best measurement solution.

Interface Airplane Static Testing Case Study

Interface is a preferred supplier of precision force measurement solutions for the aerospace industry and our products are frequently used to help perform critical testing on all types of commercial, industrial, and military aeronautical vehicles.

During the engineering and manufacturing of all types of aircraft, static testing is commonly used to validate designs and components, measure assembly and affirm performance and regulatory requirements. Accuracy and reliability of any type of sensor and instrumentation used during these tests is vital to the testing programs and ensures the safety for pilots, passengers and the public at large when these vehicles take flight.

What is a static test?

Static testing is a type of structural test which allows engineers to analyze an aircraft’s structural integrity while grounded. This is a useful part of the testing process before taking flight, which helps speed up the certification process as it does not require a completed and fully functional aircraft through the entire manufacturing process for aerospace vehicles.

How does Interface place a role in static testing for aircraft?

Our force measurement solutions such as precision load cells and torque transducers play an important role in static testing as force analysis results are used in nearly all structural tests. Interface manufacturers both off-the-shelf and custom solutions that are used by leading part and aircraft manufacturers. These sensor products are used on a static test stand to test frame structure integrity, endurance, and life cycles, with the goal generally being to validate aircraft design and ensure specified criteria are met. The strict accuracy is necessary because in aerospace, every micrometer and gram make a difference in both the performance and safety of an aircraft design.

Static Testing Applications for Airplane Jacking System and Jet Engine Thrust Tests

In the new Airplane Static Testing case study, we have detailed two application examples and how Interface products are specifically used in in static testing of aircraft. These examples demonstrate how our products are applied and utilized for testing an airplane jacking system and provide a solution for a jet engine thrust test.

In the airplane jacking system static testing application, our WTS 1200 LowProfile® Wireless Load Cells are placed on jack points measuring weights and forces on an aircraft. Our advanced Wireless Telemetry System provided instrumentation to capture real-time data, such as the individual load cells attached to each jack point, or any set alarms that may go off if it has exceeded a certain amount of force.

For the jet engine thrust static testing, Interface’s 1000 High Capacity Fatigue-Rated LowProfile™ Load Cell was best suited for this static testing. The load cell reacted to the thrust forces produced by the jet engine and the signals were collected and recorded to create a “thrust curve” of the engine.

To read the Airplane Static Test case study it in full, go here.

To learn more about the many ways Interface can serve the aerospace industry with premium force products and total solutions, watch this video to see the types of products we supply for static and other test and measurement programs in this industry.

Additional Resources

Examining Interface Aerospace Industry Solutions

Aerospace Brochure

Solutions Provider for Aerospace & Defense

Taking Flight with Interface Solutions for Aircraft Testing

Aircraft Screwdriver Fastening Control

Aerospace and Defense Industry Solutions

Aerospace and Defense Case Study



Taking Flight with Interface Solutions for Aircraft Testing

As a top supplier of premium force measurement solutions for the aerospace industry, one of our critical areas requiring precision accuracy and high-quality products is for testing airplanes. Interface load cells, torque transducers, and instrumentation are used regularly in testing of all types of aerospace apparatus, components, and machines, along with embedding our force sensors in aircraft for ongoing simulation tests and inflight data acquisition.

Aircraft, spacecraft, military, and defense companies such as Boeing, Airbus, Lockheed, Northrop Grumman, Bombardier, Embraer, Gulfstream, NASA, and Cessna and many others in the supply and production lines utilize Interface load cells for thrust, wing, static, and fatigue testing. While structural test applications use many types of LowProfile™ load cells, Interface also offers a wide variety of load washers, load buttons and miniature tension and compression load cells for test, production, and control monitoring applications for aircraft.

Why do aircraft testing professionals prefer Interface solutions?  One reason is our moment and temperature compensated load cells use proprietary alloy strain gages for extreme accuracy and reliability that is unmatched by other brands. Using eight proprietary strain gages per sensor, our 4mV/V output well exceeds the performance requirements for testing these specialized aerospace vehicles.

In addition, before the airplanes are even assembled, every manufactured part and components must go through rigorous testing. There are hundreds of machines that are used on the production line for the hundreds of thousands of components needed to complete these specialized craft. Interface load cells and torque transducers are found on many of these production and test machines. Our products are used to provide a wealth of insight to guide manufacturers through research, development and final build. Because testing is so inherent for any of these parts, Interface products provide reliability and accuracy when there are no exceptions.

We recently developed several new application notes on ways our products are used to test airplanes. Included below is a preview of a few of the latest additions to our application notes catalog.

Jet Engine Thrust Test

A customer wanted to conduct a static jet engine thrust test that can accurately determine the engine’s thrust, burn time, chamber pressure, and other parameters, providing invaluable data to propellant chemists and engineers. They needed a high accuracy load cell with excellent repeatability to withstand thrust forces in very harsh environments. Interface offered a 1000 High Capacity Fatigue-Rated LowProfile™ Load Cell, which is ideally suited based on their performance for this application. The load cell reacts to the thrust forces produced by the jet engine and the signals are collected and recorded to create a “thrust curve” of the engine. The performance of an Interface LowProfile™ Load Cell allowed the engineers to be confident in the data acquired from the static testing. Additionally, the repeatability of the load cell results in reduced time between tests, making static jet engine thrust testing more efficient. Read the new Jet Engine Thrust Test application note here.

Aircraft Yoke Torque Measurement

An aircraft manufacturer wanted to measure the torque of their aircrafts yoke or control wheel. They also wanted to monitor the torque and forces applied to ensure that the aircrafts controls are operating properly. Interface suggested using the AT103 2-Axis Axial Torsion Load Cell to measure both torque and force within this single sensor. It can be installed inside of the yoke, and can measure the rotation of the yoke, and the forward and backwards movements. Data can be measured and paired with the SI-USB4 4-Channel USB Interface Module and displayed with the customer’s laptop. Using this solution, the customer was able to measure and monitor the torque and force of the yoke control. Read the Aircraft Yoke Torque Measurement application note.

Aircraft Engine Hoist

An aerospace company wanted to test their aircraft engine hoist in order to safely lift, remove, or install engines efficiently and safety. Interface’s solution was to install WTSSHKB-HL Wireless Bow Shackles to the aircraft engine hoist. A heavy load was added to the hooks where the aircraft engine would be. Results from the heavy load are then sent wirelessly to both the WTS-BS-4 USB Industrial Base Station attached to the customers computer or laptop, and the WTS-1-HS Handheld display for single transmitters. With these products, the customer was assured that the aircraft engine hoist was strong and secure enough to lift a heavy engine when installing or removing an engine inside of an aircraft. Learn more about the Aircraft Engine Hoist application here.

Our expert application engineers help our customers by providing technologies that provide exceedingly accurate measurement used in all types of testing, including structural, static and fatigue. For more information on Interface and its solutions designed for airplanes and other aerospace applications, please visit https://www.interfaceforce.com/solutions/aerospace.

Additional Aircraft Testing Resources

Aircraft Wing Fatigue App Note

Aircraft Screwdriver Fastening Control App Note

Aircraft Lifting Equipment App Note

Examining Interface Aerospace Industry Solutions



Examining Interface Aerospace Industry Solutions

Among the many industries Interface serves, the aerospace industry is one of the fastest growing users of our precision force measurement solutions. This is because ultra-accurate force, weight and torque measurements and data are critical to testing, performance and safety for airplanes, helicopters, and rockets.

Aerospace engineers and manufacturers of commercial, industrial, and military aerospace vehicles and associated components must measure multitudes of factors such as fatigue, structure durability, materials, weight distribution, drag, effects of inclement weather, velocity changes, thrust, and center of gravity to name a few.

Interface is synonymous with high performance sensors used for all types of test and measurement applications. For more than five decades, aerospace innovators and industrial giants have relied upon Interface to provide precision products and services they can trust.  Our test and measurement solutions are designed for use in the aerospace industry to withstand extreme conditions, whether they are for testing wings on commercial airplanes or used to measure the force of an intergalactic vessel launch.

Interface showcases products and use cases in our new aerospace solutions brochure detailing many the products and custom solutions we provide to the industry. We provide an overview of our accurate and reliable lineup of force measurement products, as well as highlighting various application examples to outline different ways we have long served the makers, builders, testers and engineers across the diverse aerospace industry.

To work in the aerospace industry, you have to meet the highest quality industry requirements in manufacturing and calibration. We take our commitment towards quality assurance very seriously and guarantee our products meet or exceed the quality clauses outlined by the International Organization of Standardization (ISO). We test and calibrate all products we build in a certificated lab based in Arizona that holds A2LA, International Standard ISO/IEC 17025:2017 and ANSI/NCSL Z540-1- 1994 accreditations. The strict adherence to these standards demonstrates our technical competence for a defined scope and the operation of a laboratory quality management system. Every Interface manufactured sensor goes through rigorous testing and calibration before it’s released to our customers.

The sensors, instrumentation, and accessories we supply to aerospace equipment manufacturers and testing labs range from mini to jumbo load cells, torque transducers, multi-axis sensors, and various wireless, digital and analog instrumentation devices. Interface sensors have been used regularly in the engineering and testing of military aircraft, missiles, space, commercial airliners, and for general aviation components as demonstrated in this aerospace and defense industry case study.

One aerospace use case of our force sensors is for structural testing. Interface LowProfile™ Load Cells are utilized for structural static and fatigue testing. Our moment and temperature compensated load cells use proprietary alloy strain gages for extreme accuracy and reliability. Using eight proprietary strain gages per sensor, our 4mV/V output well exceeds the performance. These load cells are offered in single, dual, and triple bridge configurations for different data acquisition and control requirements in aerospace vehicle production.

The range of aircraft and space vehicles that use Interface solutions include all types from unpowered gliders to commercial and military aircraft, as well as rockets, missiles, drones, launch vehicles, and spacecraft. These vehicles go through extensive and rigorous test and measurement programs and processes requiring the reliability and accuracy of Interface made products. Here are a few types of aerospace applications using Interface measurement solution:

Aircraft Wing Fatigue

Before any of the U.S. Navy’s F/A-18 twin-engine supersonic fighter jets can be put into operation, the wings of the aircraft must undergo fatigue testing in a controlled environment to ensure that they are capable of withstanding the forces that will be encountered during real-world flight throughout the lifetime of the aircraft. Highly accurate measurements must be recorded in order to make sure that a near-exact replication of in-flight conditions are being achieved. During fatigue tests, Interface’s 1248 Standard Precision Flange LowProfile Load Cells are installed in line with the hydraulic cylinders, which apply back-and-forth loading forces to the aircraft. This is carried out over the course of 18 months to simulate in-flight stresses and strains on the wings. Load cells are connected to indicators, which record output. Capable of withstanding more than 100 million (1×108) fully reversible load cycles, Interface’s LowProfile Fatigue-Rated Load Cells have performed flawlessly in F/A-18 wing testing with zero recorded failures in the many years that testing facilities around the world have been using them.

Rescue Helicopter Hoist Test

When a customer wanted to test the strength of the cable line used in the hoist of their helicopter during rescue missions and situations, see if both the cable and the hoist can withstand a heavy load safely, and for long periods of time while the helicopter is in flight, they turned to Interface. We supplied a WTSSHK-D Wireless Crosby™ Load Shackle, which is attached to each mooring cable in use. Results are sent to the customers through the WTS-BS-4 USB Industrial Base Station when connected to the customer’s supplied computer. Data can also be transmitted to the WTS-BS-1-HS Handheld Display for Single Transmitters, giving the customer the option to view mooring cable line tension. Using this solution, the customer was able to add a heavy load to the end of the helicopter hoist, to ensure it is strong and safe enough to carry both rescue personnel and objects while being in midair.

The aerospace industry is responsible for some of the greatest inventions and innovation in our global history. The engineering and manufacturing of a single rocket engine design, using handwritten calculations and with less computing power than a modern smartphone, took us to the moon. The aerospace industry is an assembly of researchers, design houses, test labs and manufacturing companies that engineer and build vehicles to travel within and beyond Earth’s atmosphere using Interface products. Whether you need a million-pound jumbo load cell, custom load pin, or wireless instrumentation, we understand aerospace requirements and our engineers are on stand-by to assist. Get your copy of our new Aerospace Solutions Brochure here.

Additional Resources

Solutions Provider for Aerospace & Defense

Exploring Aerospace Force Measurement Solutions

Interface Displays Force Measurement Aerospace Applications at Space Tech Expo

Aerospace and Defense Industry Solutions

Interface Recognized as Contributor to Human Flight Success

Solutions Provider for Aerospace & Defense

Interface has developed highly innovative force measurement solutions for a variety of complex and highly regulated industries. These industries require the most accurate and reliable test and measurement equipment on the market because bad data and unknown variables can spell disaster. This fact has never been truer than it is in the aerospace and defense sector.

For our worldwide customers in aerospace, Interface supplies a variety of sensor solutions, including load cells, tension links, load shackles, wireless instrumentation and more. And Interface is a proud supplier to some of the world leading manufacturing aircraft, spacecraft, military, and defense organizations such as the U.S. Government, NASA, Lockheed, Northrop Grumman, Raytheon, Bombardier, Embraer, Boeing, Airbus Gulfstream, Cessna and more of the world’s most prominent (and well known) rocket builders.

To further highlight our work in the aerospace and defense industry, we’ve also put together a case study outlining, in detail, some of the specific applications in which force measurement sensors can be used. The case study dives deeper into three specific applications highlighting the products used for aircraft wing fatigue, aircraft engine hoist, and parachute deployment and deceleration testing.

READ: The new Aerospace & Defense Case Study can be read in full here.

As a premier partner to these and many other leading global aerospace and defense companies, we’ve seen a lot of high-profile applications which require both off-the-shelf and custom manufactured force solutions. Our engineers and application experts partner with our customers to ensure they get the product that fits the exact requirements, weather it’s a submersible sensor or built for extreme compression and fatigue condition tests.

Our precision load cells have been used on thousands of different projects, both big and small. From aircrafts to ground vehicles and infrastructure, here are a few examples of the projects we’ve supplied various load cells, from jumbo to mini, various torque transducers, multi-axis sensors, customized load pins and as well as wireless telemetry testing systems:

ADDITIONAL RESOURCES:

Exploring Aerospace Force Measurement Solutions Blog

Launching into Orbit with Interface

Force Measurement for Space Travel



Faces of Interface Featuring Richard Snelson

Richard Snelson, president of Measurements Incorporated, is the leader of our outstanding manufacturers’ representative firm serving the Mid-Atlantic coast of the US. The origin of the company, that supports customers in this region with application solutions for structural, material, and environmental testing, is an intriguing story.

In this new Faces of Interface feature, Richard highlights one of his favorite projects and provides his thoughts on representing the most reliable and accurate force measurement products in the industry from Interface.

Richard grew up in Philadelphia, Pennsylvania, and was brought up hearing all about his ‘old man’ and the incredible work he got to do with customers across the technology landscape. His father and two partners started Measurements Incorporated in 1976. The company had spun out of another company called Micro Measurements. At that time, they sold a limited range of product lines to a wide range of customers. Some of the most memorable customers Richard would hear about from his dad included those that worked with bridges, battle tanks and even cadavers.

After high school, Richard attended Indiana University of Pennsylvania, where he would go on to earn a split degree in business, marketing, and management. During his college years, Richard also received a ton of career experience working multiple jobs. His summers were spent as a technician in the Princeton Plasma Physics Lab, where his role include working on a reactor. He also worked on the Brooklyn Bridge, replacing cables on the massive structure, as well as working for a friend of his dad in the oil and gas industry. These jobs not only put Richard through college, but they also exposed him to hands-on experience working with organizations and on projects like what his dad would talk about at home when he was growing up.

The experiences and incredible stories he was told throughout his youth pushed Richard to accept a role working for his father’s company. He started out selling one product line, XY plotters, to major test labs and facilities across the Mid-Atlantic. After finding a great deal of success, Richard was given the entire state of Delaware to sell every product line in the company’s portfolio. This eventually expanded into Pennsylvania and Maryland.

As he grew his expertise as a sales rep at Measurements Incorporated, Richard also began buying out the other two owners as they retired and eventually retained sole ownership of the company in 2003. Today the company carries an ever-expanding product line of test and measurement equipment and serves some of the most reputable organizations across multiple industries including, aerospace, defense, medical, industrial, and more.

I put myself in the customer’s place and offer a complete solution, sometimes reminding them of things they might not initially think of and the end result is that we are all successful.” Richard Snelson, president of Measurements, Incorporated.

Like his father, Richard has also collected many of his own fun, interesting, and sometimes incredibly nerve-racking stories. Among his favorite are the two times he was asked to head over to One World Trade Center to oversee installation equipment and then later assess a challenge with a sensor on the building’s enormous spire on the very top. Richard and few other men from the company charged with some of the tower’s maintenance and caretaking went up to the top together. During the assessment, Richard and the maintenance company’s president were tasked with repelling up the spire to identify and fix the sensor. Richard enjoyed an unforgettable experience and got a sweat-inducing picture in the process that you can see in his photo above!

Richard has a long-time relationship with Interface that began in 2006. He raves about the quality of the brand and the confidence he and his customers have in the accuracy and reliability of our force measurement sensors. He has great respect for the people he works with regularly, including his Regional Sales Director, Elliot Speidell. Richard often finds himself identifying the signature blue paint job on our load sensors during customer facility tours. He’s proud that he’s able to offer the industry’s leading force measurement solutions to some of the world’s most prominent organizations.

When he’s not dangling off one of the tallest buildings in the world or helping solve key customer challenges with a bevy of critical instrumentation, Richard enjoys time spent with family, his wife of 36 years Tracey, their two children Courtney and Derek, and their grandson Everett. The family loves to spend their time outdoors and can often be found sailing on the Chesapeake Bay.  Richard also enjoys recreational shooting and cruising around on his motorcycle.

We couldn’t have asked for a better partner in Richard and his team at Measurements Incorporated. We are happy to share his story. Looking for more Faces of Interfaces? Go check out our ForceLeaders here.



Load Shackles 101

A load shackle is a u-shaped, load-bearing connecting device designed to be used with a removable pin. Load shackles can be used in a number of different rigging and load securement applications to provide sensor technologies in the connection of different types of lifting slings, chains or ropes to an object or to each other.  A load shackle is essentially the installation of a load monitoring pin into the shackle body allowing you to replace existing rigging hardware with a load cell for force measurement and weighing data.

Load shackles are rugged in design and are used to provide accurate and reliable measurement of tensile loads, as well as support applications for harsh and challenging environments. The industries that most regularly take advantage of our load shackles include industrial, aerospace and defense, agriculture, and construction. Applications for lifting, moving and weighing objects can be monitored as well as optimized for performance using load shackles. They are often designed into engineered structures or for use with cranes, winches or other robust lifting mechanisms.

Interface offers a wide variety of load shackle designs for different environments and force measurement needs, ranging from 2.2K to 2205K lbf. Our load shackles come in both cabled and wireless, as well as environmental resistance options including flameproof and IP67. Visit our overview here.

Load shackles come in many standard shapes and sizes, including customization options to meet a specific design or use requirement. Some of our shackles are exclusively designed to meet the needs of applications in hazardous environments like the oil and gas industry, or marine industry where they’ll be submerged in water during testing and for continuous use, or in areas with high heat and flames. Some of our most popular load shackles are listed below:

WTSSHK-B Wireless Crosby™ Bow Load Shackle  – Suitable for use in a wide range of industrial and marine weighing applications, these load shackles are robust, reliable and easy to install. The unique telemetry housing is manufactured from tough high-performance polyamide resin making it strong yet light, resulting in a better-balanced load shackle when compared to others available on the market.

ISHK-B Bow Type Crosby™ Cabled Load Shackle – The Interface range of ISHK-B load shackles are designed for lifting and weighing in rugged or harsh environments, including submersible applications. The shackle pins are forged from high tensile stainless steel to 6.5 MT (14.3K lbf) and high tensile carbon steel from 9.5 MT (20.9K lbf), and are machined to an exacting specification. The basic shackle uses the Crosby G2130 (1 to 25 MT / 2.2K to 55.1K lbf), G2140 (40 to 120 MT / 88.2K to 265K lbf) and GN Rope H10 (150 to 1K MT / 331K to 2205K lbf).

Flame Proof Bow Type Crosby™ Cabled Load Shackle – The Interface range of flameproof load shackles is designed for lifting and weighing in rugged or harsh environments, and also meet the requirements for operation in Zone 1 and 2 hazardous areas. The shackle pins are forged from high tensile stainless steel and are machined to an exacting specification. The basic shackle uses the Crosby G2130 (1 to 25MT or 2.2K to 55.1K lbf) and G2140 (40 to 400MT or 88.2K to 882K lbf) series.

Load Shackle Application:

Load shackles are commonly used in the construction industry to measure heavy machinery. For cranes outfitted with a lifting attachment such as a claw, a tension sensing load shackle is used on the pulley mechanism to measure the weight lifted by the crane. The tension sensor can provide real-time data to the construction crew to help monitor the lifting process and provide the operator with the information necessary to refrain from lifting weights that are too heavy for the crane to handle. If the claw arm lifts more than the crane is able to withstand, the attachment could break off, or worse, the crane could topple over.

In a recent example, Interface’s customer used a WTSSHK-B Wireless Load Shackle connected to load-bearing strings and a WTS-BS-1-HA Wireless Handheld Indicator to gather data. The customer was able to successfully lift and read the weight (wirelessly) on a handheld display while the material was being relocated.

Learn more in this product video

To learn more about our wide variety of load shackles and their many applications, please contact our application specialists today.  You can see all of Interface’s Load Pins, Load Shackles and Tension Links here.

This post is part of our Interface 101 series where we provide a basic overview of the wide variety of product lines we offer here at Interface. In this series, we explain our force measurement product line and its benefits and then provide a few examples of our product’s in real-world situations. Here are some of our other popular 101 posts.



Aerospace and Defense Industry Solutions

Among the many applications Interface products are used for across multiple markets, there may be none that require the highest levels of accuracy, quality and reliability as does the aerospace and defense industry.

By classification, aerospace largely comprises of those engaged in producing and servicing of commercial aircraft. The defense market is defined as those providing military weapons and systems designed to operate in the air, in the sea or on land.

The aerospace and defense industries are global markets that continue to expand their use of precision sensor technologies for advancing innovations in autonomous vehicles and flight systems, electric and hydrogen engines, as well additive manufacturing applications. Interface proudly serves the world’s largest manufacturers and suppliers in the aerospace industry by providing world-class force and torque measurement solutions for these types of requirements, as well as for their future inventions.

Over the past two years, the trends in the global commercial space ecosystem along with defense needs have created unique requirements that benefit from our five decades of being a premium provider for A&D equipment manufacturers and testing labs. We are able to meet these trending demands through our standard, engineered to order and completely custom force, torque and systems. These solutions are being utilized in testing of all types of vehicles, on the ground, in the water, and for flight.

A&D is a unique industry because of the complex needs of many applications. When we develop applications for other industries, we’re typically focused on solving a few specific challenges, whether it’s related to cost, safety, performance, environment, or other engineering specified design requirements. In aerospace and defense, every one of these factors needs to be addressed, as well as some special needs. Applications in the aerospace and defense industry cannot fail. If they do, it can put people, both military and civilians, in danger. That’s why force products in the defense industry need to be of the highest quality in all key factors.

Below are a few applications for force measurement in the defense industry. Each demonstrates the criticality of proper force testing, as well as the complexity of the projects Interface has been involved in.

SLS Tank Test

As outlined in NASA’s article on the SLS Tank Test, NASA’s goal was to push the very limits of a test version of the world’s largest rocket fuel tank. The project put incredible flight test strain on the tank to try and push it to its breaking point. After five hours of testing and more than 260% of the expected flight load, the tank finally buckled. Doing this helped engineers gather data on the tank to help intelligently optimize the final rocket ship.

In this application, load cells played the key role of collecting the flight force data. The extreme nature of the flight tests meant that the load cells needed to be incredibly durable and provide accurate data all the way through the breaking point.

Structural Testing

For the many hundreds of thousands of commercial and military vehicles on the market, especially those that fly, there are numerous force tests involved to validate a design and ensure they’re safe and of the highest quality to move into production. Load cells and torque transducers are used across a wide variety of vehicles for structural testing. The torque of the helicopter rotor is measured and validated using a torque transducer, or the wings and hull of an airplane are put through wind tunnels and other stress tests with load cells installed to collect data. All of these force applications are critical to ensuring that these vehicles can last beyond their intended breaking point and offer complete peace of mind to operators and passengers. There are a million different things that a military pilot is thinking about – the structural integrity of his or her aircraft should never be one of them.

Custom Sensors

Another area that has grown in recent years as technology pushes the aerospace and defense market forward is custom sensors. Test has gotten more sophisticated as the move to big data becomes more prevalent, and Interface has addressed this by working directly with customers to develop custom sensors that address unique challenges.

One of the biggest areas where we have seen a growing need for custom sensors is on test stands in thrust application. Test stands are often used in field testing on rocket or plane engines. In certain field applications, the test stand is outfitted with numerous load cells that must be custom designed with features like weatherization, multiple bridges, very-high precision, and more. The reason for this is because the cost of a thrust test in fuel alone can be incredibly high. You usually only get one shot at a successful thrust test. If there are any issues with the sensor, it’s going to be costly.

Interface has deep experience developing custom sensors for our aerospace and defense partners. We understand their needs and work closely with their engineering team to ensure they get it right the first time. If you’re interested in learning more about Interface and our solutions for the aerospace and defense industry, please visit us at www.interfaceforce.com/solutions/aerospace.

For additional references, check out our A&D related case studies and application notes:

Launching Into Orbit with Interface

Force Measurement for Space Travel

Interface’s Crucial Role in Vehicle and Urban Mobility Markets

Aircraft Wing Fatigue Test

Rocket Structural Test

Wind Tunnel Testing

Contributor: Elliot Speidell, Interface Regional Sales Director

Solutions

The Criticality of Thrust Measurement Testing in Aerospace

Interface is a force measurement solutions provider for many of the largest and most innovative aerospace and space systems organizations. Our measurement devices are utilized to test various aircraft and space vehicle components, including thrust testing for jet engines, gas turbines, and propulsion systems.

Thrust measurement is critical when designing and developing aircraft and spacecraft. These critical measurements are used to build and test rocket engines for launch vehicles and missiles. Thrust testing is also vital for maintenance and quality inspections of vehicle engines and systems. By measuring thrust over time, engineers can identify any potential engine problems and take corrective action before they cause a failure.

Thrust measurements ensure rocket and airplane engines produce enough thrust to safely launch, fly, and land. If an engine is not producing enough thrust, it could lead to a catastrophic failure. Trust testing also helps to improve fuel efficiency and reduce emissions.

The force emitted by a thrust engine dictates the size and speed at which a payload can be lifted off the ground. Enormous amounts of thrust are needed to get a spaceship out of the Earth’s atmosphere or propel a jet engine to move faster than the speed of sound. Thrust must be measured precisely because applying too much thrust to an aircraft may damage it, or using too much thrust at a rocket’s liftoff can use too much fuel.

Interface force sensors provide extremely accurate data to assess the amount of force, helping engineers tune thrusters to provide the right amount of force for the size and speed needed to launch or lift their vehicle.

Thrust is measured by placing the thrust engine on a test stand. Then, as the rocket engine burns fuel and creates thrust, the force of the thrust creates compression force on the load cell sensor. As this happens, a mechanical signal is converted to a digital signal, and this data is sent back to the engineer through a data acquisition device, who can then assess, monitor, and record that data.

A load cell used to measure thrust force must be rated for extreme heat. A typical load cell could not provide an accurate measurement when placed in a temperature environment that the sensor’s materials could not handle. Interface offers a wide range of load cells rated explicitly for this type of testing.

To give you a sense of the power and environment of thrust testing, you can see the thrust test of a jet engine in action posted on the U.S. Defense News YouTube channel.

Jet Engine Thrust Testing Application

A customer wanted to conduct a static jet engine thrust test that could accurately determine the engine’s thrust, burn time, chamber pressure, and other parameters, providing invaluable data to propellant chemists and engineers. They needed a high-accuracy load cell with excellent repeatability to withstand thrust forces in very harsh environments. From ignition to burn-out, Interface’s 1000 High Capacity Fatigue-Rated LowProfile™ Load Cell was ideally suited based on their performance for this application.

The load cell reacted to the thrust forces produced by the jet engine, and the signals were collected and recorded to create a “thrust curve” of the engine. The performance of an Interface LowProfile™ Load Cell allowed engineers to be confident in the data acquired from the static testing. Additionally, the repeatability of the load cell resulted in reduced time between tests, making static jet engine thrust testing more efficient. The 9330 battery-powered high-speed data logging indicator captured the data for analysis.

Thrust measurement ensures safety, reliability, and performance.

Interface is a long-time provider of  Aerospace and Defense Industry Solutions.  Here is another video to watch to learn more about Interface’s role in aerospace innovation.

Go here to learn more about thrust and other force test examples in the aerospace industry.

ADDITIONAL RESOURCES

Taking Flight with Interface Solutions for Aircraft Testing

Enabling A Look Way Beyond Yonder

Aerospace Solutions

Interface Space Economy Solutions

The Aviation Industry Soars Using Interface Solutions

Solutions Provider for Aerospace & Defense

Are Load Cells Used in Vacuum Environments?

Vacuum testing labs are essential for ensuring that products and materials are safe and dependable in vacuum environments. A vacuum environment is an area where there is little or no matter. This means that there are very few gas molecules present, and the pressure is incredibly low. Vacuum environments are often created using vacuum pumps, which remove gas molecules from an enclosed space.

Vacuum environments are used to simulate the conditions that products and materials will experience in space or other high-altitude environments. These types of testing labs typically have a vacuum chamber that can be evacuated to an incredibly low pressure. The vacuum chamber is then used to evaluate products and materials for a variety of properties. Engineers use vacuum environments in testing for reduced contamination, improving heat transfer, and to reduce the weight of products.

Tests performed in vacuum labs are used to determine the rate at which gases are released from a product or material and the ability of a product or material to withstand a vacuum without leaking. Thermal cycling tests are done to assess the ability of a product or material to withstand changes in temperature in a vacuum environment. Other tests are done to understand how the test article withstands exposure to radiation.

Vacuum testing labs are used by a variety of industries, including aerospace, medical, and defense. These labs are common for material process testing and used in R&D. Vacuum testing helps to identify potential problems with products and materials before they are used in a real vacuum environment. Engineers use this type of testing to improve the performance of products and materials and ensure they meet the required standards. Contact Interfaced to explore your options.

Can load cells be used in a vacuum environment?

Load cells can be used in a vacuum environment. However, not all load cells are created equal or suited for this specialized use case. Some load cells are designed that make them appropriate for vacuum environments, while others are not. Load cells that are not engineered to perform in vacuum environments may not be able to withstand the low pressures and outgassing that can occur in a vacuum. Using quality load cells that are manufactured by force measurement experts in sensor technologies is important in any consideration. It is critical to review the specifications and requirements with a qualified applications engineer.

Key considerations when choosing a load cell for a vacuum environment:

  • Outgassing: Load cells that are used in vacuum environments will have low outgassing rates. This means that they will not release gases into the vacuum chamber, which can contaminate the environment and interfere with measurements.
  • Mechanical strength: Load cells must be able to withstand the low pressures that can occur in a vacuum. They will also be able to withstand the conditions that can be generated by vacuum processes, such as outgassing and condensation. Form factor and model material of the load cell are important in choosing a load cell for this use case.
  • Temperature range: Load cells will need to operate in a wide range of temperatures. This is important because vacuum chambers can be very cold, especially when they are first evacuated, or when they are used to simulate high altitudes or space.

If you are looking for a load cell that can be used in a vacuum environment, please review with Interface application engineers to determine if the model fits your test requirements. We also can offer custom solutions to ensure that the load cell maintains the accuracy and performance specifications based on your exact test plan.

Can a load cell be vented for use in a vacuum testing lab?

Technically yes, you can vent a load cell to be used in vacuum. This allows the internal cavity of the load cell to equalize with external vacuum. However, this does not prevent outgassing and can cause the gages and wiring to be subject to humidity and condensation.

Cabling is extremely important when using any sensor in this environment. There are options to make the load cells wireless using Bluetooth technology.

Caution: Interface recommends that all our products used in this type of environment are designed, built, and calibrated for use in this environment. Venting an existing load cell can alter the performance and damage the cell.  By designing the load cell with venting for use, we can ensure that it will meet the vacuum test range.

Interface also can install thermocouples to work with the sensor to detect temperature in this type of testing environment. In fact, our engineers have designed load cells to package the thermocouples inside the form factor for convenience and performance benefits.

Interface engineers have worked with testing labs for decades. We are available to assist with any use case requirements to determine the best measurement solution.

Interface Airplane Static Testing Case Study

Interface is a preferred supplier of precision force measurement solutions for the aerospace industry and our products are frequently used to help perform critical testing on all types of commercial, industrial, and military aeronautical vehicles.

During the engineering and manufacturing of all types of aircraft, static testing is commonly used to validate designs and components, measure assembly and affirm performance and regulatory requirements. Accuracy and reliability of any type of sensor and instrumentation used during these tests is vital to the testing programs and ensures the safety for pilots, passengers and the public at large when these vehicles take flight.

What is a static test?

Static testing is a type of structural test which allows engineers to analyze an aircraft’s structural integrity while grounded. This is a useful part of the testing process before taking flight, which helps speed up the certification process as it does not require a completed and fully functional aircraft through the entire manufacturing process for aerospace vehicles.

How does Interface place a role in static testing for aircraft?

Our force measurement solutions such as precision load cells and torque transducers play an important role in static testing as force analysis results are used in nearly all structural tests. Interface manufacturers both off-the-shelf and custom solutions that are used by leading part and aircraft manufacturers. These sensor products are used on a static test stand to test frame structure integrity, endurance, and life cycles, with the goal generally being to validate aircraft design and ensure specified criteria are met. The strict accuracy is necessary because in aerospace, every micrometer and gram make a difference in both the performance and safety of an aircraft design.

Static Testing Applications for Airplane Jacking System and Jet Engine Thrust Tests

In the new Airplane Static Testing case study, we have detailed two application examples and how Interface products are specifically used in in static testing of aircraft. These examples demonstrate how our products are applied and utilized for testing an airplane jacking system and provide a solution for a jet engine thrust test.

In the airplane jacking system static testing application, our WTS 1200 LowProfile® Wireless Load Cells are placed on jack points measuring weights and forces on an aircraft. Our advanced Wireless Telemetry System provided instrumentation to capture real-time data, such as the individual load cells attached to each jack point, or any set alarms that may go off if it has exceeded a certain amount of force.

For the jet engine thrust static testing, Interface’s 1000 High Capacity Fatigue-Rated LowProfile™ Load Cell was best suited for this static testing. The load cell reacted to the thrust forces produced by the jet engine and the signals were collected and recorded to create a “thrust curve” of the engine.

To read the Airplane Static Test case study it in full, go here.

To learn more about the many ways Interface can serve the aerospace industry with premium force products and total solutions, watch this video to see the types of products we supply for static and other test and measurement programs in this industry.

Additional Resources

Examining Interface Aerospace Industry Solutions

Aerospace Brochure

Solutions Provider for Aerospace & Defense

Taking Flight with Interface Solutions for Aircraft Testing

Aircraft Screwdriver Fastening Control

Aerospace and Defense Industry Solutions

Aerospace and Defense Case Study



Taking Flight with Interface Solutions for Aircraft Testing

As a top supplier of premium force measurement solutions for the aerospace industry, one of our critical areas requiring precision accuracy and high-quality products is for testing airplanes. Interface load cells, torque transducers, and instrumentation are used regularly in testing of all types of aerospace apparatus, components, and machines, along with embedding our force sensors in aircraft for ongoing simulation tests and inflight data acquisition.

Aircraft, spacecraft, military, and defense companies such as Boeing, Airbus, Lockheed, Northrop Grumman, Bombardier, Embraer, Gulfstream, NASA, and Cessna and many others in the supply and production lines utilize Interface load cells for thrust, wing, static, and fatigue testing. While structural test applications use many types of LowProfile™ load cells, Interface also offers a wide variety of load washers, load buttons and miniature tension and compression load cells for test, production, and control monitoring applications for aircraft.

Why do aircraft testing professionals prefer Interface solutions?  One reason is our moment and temperature compensated load cells use proprietary alloy strain gages for extreme accuracy and reliability that is unmatched by other brands. Using eight proprietary strain gages per sensor, our 4mV/V output well exceeds the performance requirements for testing these specialized aerospace vehicles.

In addition, before the airplanes are even assembled, every manufactured part and components must go through rigorous testing. There are hundreds of machines that are used on the production line for the hundreds of thousands of components needed to complete these specialized craft. Interface load cells and torque transducers are found on many of these production and test machines. Our products are used to provide a wealth of insight to guide manufacturers through research, development and final build. Because testing is so inherent for any of these parts, Interface products provide reliability and accuracy when there are no exceptions.

We recently developed several new application notes on ways our products are used to test airplanes. Included below is a preview of a few of the latest additions to our application notes catalog.

Jet Engine Thrust Test

A customer wanted to conduct a static jet engine thrust test that can accurately determine the engine’s thrust, burn time, chamber pressure, and other parameters, providing invaluable data to propellant chemists and engineers. They needed a high accuracy load cell with excellent repeatability to withstand thrust forces in very harsh environments. Interface offered a 1000 High Capacity Fatigue-Rated LowProfile™ Load Cell, which is ideally suited based on their performance for this application. The load cell reacts to the thrust forces produced by the jet engine and the signals are collected and recorded to create a “thrust curve” of the engine. The performance of an Interface LowProfile™ Load Cell allowed the engineers to be confident in the data acquired from the static testing. Additionally, the repeatability of the load cell results in reduced time between tests, making static jet engine thrust testing more efficient. Read the new Jet Engine Thrust Test application note here.

Aircraft Yoke Torque Measurement

An aircraft manufacturer wanted to measure the torque of their aircrafts yoke or control wheel. They also wanted to monitor the torque and forces applied to ensure that the aircrafts controls are operating properly. Interface suggested using the AT103 2-Axis Axial Torsion Load Cell to measure both torque and force within this single sensor. It can be installed inside of the yoke, and can measure the rotation of the yoke, and the forward and backwards movements. Data can be measured and paired with the SI-USB4 4-Channel USB Interface Module and displayed with the customer’s laptop. Using this solution, the customer was able to measure and monitor the torque and force of the yoke control. Read the Aircraft Yoke Torque Measurement application note.

Aircraft Engine Hoist

An aerospace company wanted to test their aircraft engine hoist in order to safely lift, remove, or install engines efficiently and safety. Interface’s solution was to install WTSSHKB-HL Wireless Bow Shackles to the aircraft engine hoist. A heavy load was added to the hooks where the aircraft engine would be. Results from the heavy load are then sent wirelessly to both the WTS-BS-4 USB Industrial Base Station attached to the customers computer or laptop, and the WTS-1-HS Handheld display for single transmitters. With these products, the customer was assured that the aircraft engine hoist was strong and secure enough to lift a heavy engine when installing or removing an engine inside of an aircraft. Learn more about the Aircraft Engine Hoist application here.

Our expert application engineers help our customers by providing technologies that provide exceedingly accurate measurement used in all types of testing, including structural, static and fatigue. For more information on Interface and its solutions designed for airplanes and other aerospace applications, please visit https://www.interfaceforce.com/solutions/aerospace.

Additional Aircraft Testing Resources

Aircraft Wing Fatigue App Note

Aircraft Screwdriver Fastening Control App Note

Aircraft Lifting Equipment App Note

Examining Interface Aerospace Industry Solutions



Examining Interface Aerospace Industry Solutions

Among the many industries Interface serves, the aerospace industry is one of the fastest growing users of our precision force measurement solutions. This is because ultra-accurate force, weight and torque measurements and data are critical to testing, performance and safety for airplanes, helicopters, and rockets.

Aerospace engineers and manufacturers of commercial, industrial, and military aerospace vehicles and associated components must measure multitudes of factors such as fatigue, structure durability, materials, weight distribution, drag, effects of inclement weather, velocity changes, thrust, and center of gravity to name a few.

Interface is synonymous with high performance sensors used for all types of test and measurement applications. For more than five decades, aerospace innovators and industrial giants have relied upon Interface to provide precision products and services they can trust.  Our test and measurement solutions are designed for use in the aerospace industry to withstand extreme conditions, whether they are for testing wings on commercial airplanes or used to measure the force of an intergalactic vessel launch.

Interface showcases products and use cases in our new aerospace solutions brochure detailing many the products and custom solutions we provide to the industry. We provide an overview of our accurate and reliable lineup of force measurement products, as well as highlighting various application examples to outline different ways we have long served the makers, builders, testers and engineers across the diverse aerospace industry.

To work in the aerospace industry, you have to meet the highest quality industry requirements in manufacturing and calibration. We take our commitment towards quality assurance very seriously and guarantee our products meet or exceed the quality clauses outlined by the International Organization of Standardization (ISO). We test and calibrate all products we build in a certificated lab based in Arizona that holds A2LA, International Standard ISO/IEC 17025:2017 and ANSI/NCSL Z540-1- 1994 accreditations. The strict adherence to these standards demonstrates our technical competence for a defined scope and the operation of a laboratory quality management system. Every Interface manufactured sensor goes through rigorous testing and calibration before it’s released to our customers.

The sensors, instrumentation, and accessories we supply to aerospace equipment manufacturers and testing labs range from mini to jumbo load cells, torque transducers, multi-axis sensors, and various wireless, digital and analog instrumentation devices. Interface sensors have been used regularly in the engineering and testing of military aircraft, missiles, space, commercial airliners, and for general aviation components as demonstrated in this aerospace and defense industry case study.

One aerospace use case of our force sensors is for structural testing. Interface LowProfile™ Load Cells are utilized for structural static and fatigue testing. Our moment and temperature compensated load cells use proprietary alloy strain gages for extreme accuracy and reliability. Using eight proprietary strain gages per sensor, our 4mV/V output well exceeds the performance. These load cells are offered in single, dual, and triple bridge configurations for different data acquisition and control requirements in aerospace vehicle production.

The range of aircraft and space vehicles that use Interface solutions include all types from unpowered gliders to commercial and military aircraft, as well as rockets, missiles, drones, launch vehicles, and spacecraft. These vehicles go through extensive and rigorous test and measurement programs and processes requiring the reliability and accuracy of Interface made products. Here are a few types of aerospace applications using Interface measurement solution:

Aircraft Wing Fatigue

Before any of the U.S. Navy’s F/A-18 twin-engine supersonic fighter jets can be put into operation, the wings of the aircraft must undergo fatigue testing in a controlled environment to ensure that they are capable of withstanding the forces that will be encountered during real-world flight throughout the lifetime of the aircraft. Highly accurate measurements must be recorded in order to make sure that a near-exact replication of in-flight conditions are being achieved. During fatigue tests, Interface’s 1248 Standard Precision Flange LowProfile Load Cells are installed in line with the hydraulic cylinders, which apply back-and-forth loading forces to the aircraft. This is carried out over the course of 18 months to simulate in-flight stresses and strains on the wings. Load cells are connected to indicators, which record output. Capable of withstanding more than 100 million (1×108) fully reversible load cycles, Interface’s LowProfile Fatigue-Rated Load Cells have performed flawlessly in F/A-18 wing testing with zero recorded failures in the many years that testing facilities around the world have been using them.

Rescue Helicopter Hoist Test

When a customer wanted to test the strength of the cable line used in the hoist of their helicopter during rescue missions and situations, see if both the cable and the hoist can withstand a heavy load safely, and for long periods of time while the helicopter is in flight, they turned to Interface. We supplied a WTSSHK-D Wireless Crosby™ Load Shackle, which is attached to each mooring cable in use. Results are sent to the customers through the WTS-BS-4 USB Industrial Base Station when connected to the customer’s supplied computer. Data can also be transmitted to the WTS-BS-1-HS Handheld Display for Single Transmitters, giving the customer the option to view mooring cable line tension. Using this solution, the customer was able to add a heavy load to the end of the helicopter hoist, to ensure it is strong and safe enough to carry both rescue personnel and objects while being in midair.

The aerospace industry is responsible for some of the greatest inventions and innovation in our global history. The engineering and manufacturing of a single rocket engine design, using handwritten calculations and with less computing power than a modern smartphone, took us to the moon. The aerospace industry is an assembly of researchers, design houses, test labs and manufacturing companies that engineer and build vehicles to travel within and beyond Earth’s atmosphere using Interface products. Whether you need a million-pound jumbo load cell, custom load pin, or wireless instrumentation, we understand aerospace requirements and our engineers are on stand-by to assist. Get your copy of our new Aerospace Solutions Brochure here.

Additional Resources

Solutions Provider for Aerospace & Defense

Exploring Aerospace Force Measurement Solutions

Interface Displays Force Measurement Aerospace Applications at Space Tech Expo

Aerospace and Defense Industry Solutions

Interface Recognized as Contributor to Human Flight Success

Solutions Provider for Aerospace & Defense

Interface has developed highly innovative force measurement solutions for a variety of complex and highly regulated industries. These industries require the most accurate and reliable test and measurement equipment on the market because bad data and unknown variables can spell disaster. This fact has never been truer than it is in the aerospace and defense sector.

For our worldwide customers in aerospace, Interface supplies a variety of sensor solutions, including load cells, tension links, load shackles, wireless instrumentation and more. And Interface is a proud supplier to some of the world leading manufacturing aircraft, spacecraft, military, and defense organizations such as the U.S. Government, NASA, Lockheed, Northrop Grumman, Raytheon, Bombardier, Embraer, Boeing, Airbus Gulfstream, Cessna and more of the world’s most prominent (and well known) rocket builders.

To further highlight our work in the aerospace and defense industry, we’ve also put together a case study outlining, in detail, some of the specific applications in which force measurement sensors can be used. The case study dives deeper into three specific applications highlighting the products used for aircraft wing fatigue, aircraft engine hoist, and parachute deployment and deceleration testing.

READ: The new Aerospace & Defense Case Study can be read in full here.

As a premier partner to these and many other leading global aerospace and defense companies, we’ve seen a lot of high-profile applications which require both off-the-shelf and custom manufactured force solutions. Our engineers and application experts partner with our customers to ensure they get the product that fits the exact requirements, weather it’s a submersible sensor or built for extreme compression and fatigue condition tests.

Our precision load cells have been used on thousands of different projects, both big and small. From aircrafts to ground vehicles and infrastructure, here are a few examples of the projects we’ve supplied various load cells, from jumbo to mini, various torque transducers, multi-axis sensors, customized load pins and as well as wireless telemetry testing systems:

ADDITIONAL RESOURCES:

Exploring Aerospace Force Measurement Solutions Blog

Launching into Orbit with Interface

Force Measurement for Space Travel



Faces of Interface Featuring Richard Snelson

Richard Snelson, president of Measurements Incorporated, is the leader of our outstanding manufacturers’ representative firm serving the Mid-Atlantic coast of the US. The origin of the company, that supports customers in this region with application solutions for structural, material, and environmental testing, is an intriguing story.

In this new Faces of Interface feature, Richard highlights one of his favorite projects and provides his thoughts on representing the most reliable and accurate force measurement products in the industry from Interface.

Richard grew up in Philadelphia, Pennsylvania, and was brought up hearing all about his ‘old man’ and the incredible work he got to do with customers across the technology landscape. His father and two partners started Measurements Incorporated in 1976. The company had spun out of another company called Micro Measurements. At that time, they sold a limited range of product lines to a wide range of customers. Some of the most memorable customers Richard would hear about from his dad included those that worked with bridges, battle tanks and even cadavers.

After high school, Richard attended Indiana University of Pennsylvania, where he would go on to earn a split degree in business, marketing, and management. During his college years, Richard also received a ton of career experience working multiple jobs. His summers were spent as a technician in the Princeton Plasma Physics Lab, where his role include working on a reactor. He also worked on the Brooklyn Bridge, replacing cables on the massive structure, as well as working for a friend of his dad in the oil and gas industry. These jobs not only put Richard through college, but they also exposed him to hands-on experience working with organizations and on projects like what his dad would talk about at home when he was growing up.

The experiences and incredible stories he was told throughout his youth pushed Richard to accept a role working for his father’s company. He started out selling one product line, XY plotters, to major test labs and facilities across the Mid-Atlantic. After finding a great deal of success, Richard was given the entire state of Delaware to sell every product line in the company’s portfolio. This eventually expanded into Pennsylvania and Maryland.

As he grew his expertise as a sales rep at Measurements Incorporated, Richard also began buying out the other two owners as they retired and eventually retained sole ownership of the company in 2003. Today the company carries an ever-expanding product line of test and measurement equipment and serves some of the most reputable organizations across multiple industries including, aerospace, defense, medical, industrial, and more.

I put myself in the customer’s place and offer a complete solution, sometimes reminding them of things they might not initially think of and the end result is that we are all successful.” Richard Snelson, president of Measurements, Incorporated.

Like his father, Richard has also collected many of his own fun, interesting, and sometimes incredibly nerve-racking stories. Among his favorite are the two times he was asked to head over to One World Trade Center to oversee installation equipment and then later assess a challenge with a sensor on the building’s enormous spire on the very top. Richard and few other men from the company charged with some of the tower’s maintenance and caretaking went up to the top together. During the assessment, Richard and the maintenance company’s president were tasked with repelling up the spire to identify and fix the sensor. Richard enjoyed an unforgettable experience and got a sweat-inducing picture in the process that you can see in his photo above!

Richard has a long-time relationship with Interface that began in 2006. He raves about the quality of the brand and the confidence he and his customers have in the accuracy and reliability of our force measurement sensors. He has great respect for the people he works with regularly, including his Regional Sales Director, Elliot Speidell. Richard often finds himself identifying the signature blue paint job on our load sensors during customer facility tours. He’s proud that he’s able to offer the industry’s leading force measurement solutions to some of the world’s most prominent organizations.

When he’s not dangling off one of the tallest buildings in the world or helping solve key customer challenges with a bevy of critical instrumentation, Richard enjoys time spent with family, his wife of 36 years Tracey, their two children Courtney and Derek, and their grandson Everett. The family loves to spend their time outdoors and can often be found sailing on the Chesapeake Bay.  Richard also enjoys recreational shooting and cruising around on his motorcycle.

We couldn’t have asked for a better partner in Richard and his team at Measurements Incorporated. We are happy to share his story. Looking for more Faces of Interfaces? Go check out our ForceLeaders here.



Load Shackles 101

A load shackle is a u-shaped, load-bearing connecting device designed to be used with a removable pin. Load shackles can be used in a number of different rigging and load securement applications to provide sensor technologies in the connection of different types of lifting slings, chains or ropes to an object or to each other.  A load shackle is essentially the installation of a load monitoring pin into the shackle body allowing you to replace existing rigging hardware with a load cell for force measurement and weighing data.

Load shackles are rugged in design and are used to provide accurate and reliable measurement of tensile loads, as well as support applications for harsh and challenging environments. The industries that most regularly take advantage of our load shackles include industrial, aerospace and defense, agriculture, and construction. Applications for lifting, moving and weighing objects can be monitored as well as optimized for performance using load shackles. They are often designed into engineered structures or for use with cranes, winches or other robust lifting mechanisms.

Interface offers a wide variety of load shackle designs for different environments and force measurement needs, ranging from 2.2K to 2205K lbf. Our load shackles come in both cabled and wireless, as well as environmental resistance options including flameproof and IP67. Visit our overview here.

Load shackles come in many standard shapes and sizes, including customization options to meet a specific design or use requirement. Some of our shackles are exclusively designed to meet the needs of applications in hazardous environments like the oil and gas industry, or marine industry where they’ll be submerged in water during testing and for continuous use, or in areas with high heat and flames. Some of our most popular load shackles are listed below:

WTSSHK-B Wireless Crosby™ Bow Load Shackle  – Suitable for use in a wide range of industrial and marine weighing applications, these load shackles are robust, reliable and easy to install. The unique telemetry housing is manufactured from tough high-performance polyamide resin making it strong yet light, resulting in a better-balanced load shackle when compared to others available on the market.

ISHK-B Bow Type Crosby™ Cabled Load Shackle – The Interface range of ISHK-B load shackles are designed for lifting and weighing in rugged or harsh environments, including submersible applications. The shackle pins are forged from high tensile stainless steel to 6.5 MT (14.3K lbf) and high tensile carbon steel from 9.5 MT (20.9K lbf), and are machined to an exacting specification. The basic shackle uses the Crosby G2130 (1 to 25 MT / 2.2K to 55.1K lbf), G2140 (40 to 120 MT / 88.2K to 265K lbf) and GN Rope H10 (150 to 1K MT / 331K to 2205K lbf).

Flame Proof Bow Type Crosby™ Cabled Load Shackle – The Interface range of flameproof load shackles is designed for lifting and weighing in rugged or harsh environments, and also meet the requirements for operation in Zone 1 and 2 hazardous areas. The shackle pins are forged from high tensile stainless steel and are machined to an exacting specification. The basic shackle uses the Crosby G2130 (1 to 25MT or 2.2K to 55.1K lbf) and G2140 (40 to 400MT or 88.2K to 882K lbf) series.

Load Shackle Application:

Load shackles are commonly used in the construction industry to measure heavy machinery. For cranes outfitted with a lifting attachment such as a claw, a tension sensing load shackle is used on the pulley mechanism to measure the weight lifted by the crane. The tension sensor can provide real-time data to the construction crew to help monitor the lifting process and provide the operator with the information necessary to refrain from lifting weights that are too heavy for the crane to handle. If the claw arm lifts more than the crane is able to withstand, the attachment could break off, or worse, the crane could topple over.

In a recent example, Interface’s customer used a WTSSHK-B Wireless Load Shackle connected to load-bearing strings and a WTS-BS-1-HA Wireless Handheld Indicator to gather data. The customer was able to successfully lift and read the weight (wirelessly) on a handheld display while the material was being relocated.

Learn more in this product video

To learn more about our wide variety of load shackles and their many applications, please contact our application specialists today.  You can see all of Interface’s Load Pins, Load Shackles and Tension Links here.

This post is part of our Interface 101 series where we provide a basic overview of the wide variety of product lines we offer here at Interface. In this series, we explain our force measurement product line and its benefits and then provide a few examples of our product’s in real-world situations. Here are some of our other popular 101 posts.



Aerospace and Defense Industry Solutions

Among the many applications Interface products are used for across multiple markets, there may be none that require the highest levels of accuracy, quality and reliability as does the aerospace and defense industry.

By classification, aerospace largely comprises of those engaged in producing and servicing of commercial aircraft. The defense market is defined as those providing military weapons and systems designed to operate in the air, in the sea or on land.

The aerospace and defense industries are global markets that continue to expand their use of precision sensor technologies for advancing innovations in autonomous vehicles and flight systems, electric and hydrogen engines, as well additive manufacturing applications. Interface proudly serves the world’s largest manufacturers and suppliers in the aerospace industry by providing world-class force and torque measurement solutions for these types of requirements, as well as for their future inventions.

Over the past two years, the trends in the global commercial space ecosystem along with defense needs have created unique requirements that benefit from our five decades of being a premium provider for A&D equipment manufacturers and testing labs. We are able to meet these trending demands through our standard, engineered to order and completely custom force, torque and systems. These solutions are being utilized in testing of all types of vehicles, on the ground, in the water, and for flight.

A&D is a unique industry because of the complex needs of many applications. When we develop applications for other industries, we’re typically focused on solving a few specific challenges, whether it’s related to cost, safety, performance, environment, or other engineering specified design requirements. In aerospace and defense, every one of these factors needs to be addressed, as well as some special needs. Applications in the aerospace and defense industry cannot fail. If they do, it can put people, both military and civilians, in danger. That’s why force products in the defense industry need to be of the highest quality in all key factors.

Below are a few applications for force measurement in the defense industry. Each demonstrates the criticality of proper force testing, as well as the complexity of the projects Interface has been involved in.

SLS Tank Test

As outlined in NASA’s article on the SLS Tank Test, NASA’s goal was to push the very limits of a test version of the world’s largest rocket fuel tank. The project put incredible flight test strain on the tank to try and push it to its breaking point. After five hours of testing and more than 260% of the expected flight load, the tank finally buckled. Doing this helped engineers gather data on the tank to help intelligently optimize the final rocket ship.

In this application, load cells played the key role of collecting the flight force data. The extreme nature of the flight tests meant that the load cells needed to be incredibly durable and provide accurate data all the way through the breaking point.

Structural Testing

For the many hundreds of thousands of commercial and military vehicles on the market, especially those that fly, there are numerous force tests involved to validate a design and ensure they’re safe and of the highest quality to move into production. Load cells and torque transducers are used across a wide variety of vehicles for structural testing. The torque of the helicopter rotor is measured and validated using a torque transducer, or the wings and hull of an airplane are put through wind tunnels and other stress tests with load cells installed to collect data. All of these force applications are critical to ensuring that these vehicles can last beyond their intended breaking point and offer complete peace of mind to operators and passengers. There are a million different things that a military pilot is thinking about – the structural integrity of his or her aircraft should never be one of them.

Custom Sensors

Another area that has grown in recent years as technology pushes the aerospace and defense market forward is custom sensors. Test has gotten more sophisticated as the move to big data becomes more prevalent, and Interface has addressed this by working directly with customers to develop custom sensors that address unique challenges.

One of the biggest areas where we have seen a growing need for custom sensors is on test stands in thrust application. Test stands are often used in field testing on rocket or plane engines. In certain field applications, the test stand is outfitted with numerous load cells that must be custom designed with features like weatherization, multiple bridges, very-high precision, and more. The reason for this is because the cost of a thrust test in fuel alone can be incredibly high. You usually only get one shot at a successful thrust test. If there are any issues with the sensor, it’s going to be costly.

Interface has deep experience developing custom sensors for our aerospace and defense partners. We understand their needs and work closely with their engineering team to ensure they get it right the first time. If you’re interested in learning more about Interface and our solutions for the aerospace and defense industry, please visit us at www.interfaceforce.com/solutions/aerospace.

For additional references, check out our A&D related case studies and application notes:

Launching Into Orbit with Interface

Force Measurement for Space Travel

Interface’s Crucial Role in Vehicle and Urban Mobility Markets

Aircraft Wing Fatigue Test

Rocket Structural Test

Wind Tunnel Testing

Contributor: Elliot Speidell, Interface Regional Sales Director
