1000 9325 System - Interface

1000 Fatigue-Rated Universal LowProfile® Load Cell and 9325 Portable Sensor Display

Portable Load Cell System

The Interface 1000 Fatigue-Rated LowProfile® Load Cell and the 9325 Portable Sensor Display work together as a complete force measurement system. The 1000 series load cell accurately senses tension or compression forces and outputs a millivolt signal proportional to the load. The 9325 handheld display powers the load cell, amplifies the signal, and converts it into a readable digital value. With features like TEDS auto-calibration, multiple display modes, and USB data output, this system delivers portable, high-precision force measurement ideal for both lab and field applications.

1000 Fatigue-Rated Universal LowProfile® Load Cell:
- Capacities from 250 lbf to 50K lbf (1.11 kN to 222 kN)
- Proprietary Interface temperature compensated strain gages
- Performance to 0.03%
- Eccentric load compensated
- Low deflection
- 0.0008%/°F (.0015%/°C) temp. effect on output
- Barometric compensation
- Shunt calibration
- E74 NIST Traceable Tension and Compression Calibration (Optional)
9325 Portable Sensor Display:
- USB port providing configuration, calibration, save & restore, live logging
- Superior Linearity Performance Specifications
- Measurement Rate up to 2400 Samples per Second
- High Internal Resolution (up to 500,000 counts)
- IP64 Environmentally Protected Enclosure
- Battery Powered (Long Battery Life)
- 128 x 64 Graphical Display with Backlight
- Multiple Display Modes (Peak/Valley, Delta, Live, Gross and Net)
- Logging and Graphing to PC (Software is Included)
- Supports TEDS Template 33, 40 and 41
- Live Calibration and Multi-point Calibration
- Standard Audio Alarm
- CE Environmental Approved

Applications:

Aerospace
Robotics
Automotive Testing

Biomechanical Research
Dynamic Testing Environments
Precision Research

System Components

1000 Fatigue-Rated Universal LowProfile® Load Cell 9325 Portable Sensor Display Cable Assemblies Mating Connectors System Level Calibration

1000 Fatigue-Rated Universal LowProfile® Load Cell3A Series 3-Axis Force Load Cells

Eccentric Load Compensated High Safe Overload

250 lbf to 50K lbf
1.25 kN to 225 kN

Model 1000 series is a fatigue-rated low profile load cell with 300% safe overload, extremely low moment sensitivity of 0.1%/in and a higher fatigue life. If you need to measure 1 pound (4.45N) or 1 million pounds (4500kN) of force, Interface load cells can do it. With many variants and configurations our fatigue-rated load cells provide up to 100 million fully rendered cycles. The gaged sensors in every load cell are individually inspected and tested, and certified to meet our rigid standards.

Options Available for 2nd, 3rd Bridge and Overload Protection.

Models 1010, 1020, and 1032 are available.

Features & Benefits

Capacities from 250 lbf to 50K lbf (1.11 kN to 222 kN)
Proprietary Interface temperature compensated strain gages
Performance to 0.03%
Eccentric load compensated
Low deflection
0.0008%/°F (.0015%/°C) temp. effect on output
Barometric compensation
Shunt calibration
E74 NIST Traceable Tension and Compression Calibration (Optional)

9325 Portable Sensor Display

Portable, Digital, Hand Held, Battery and USB Powered, TEDS Ready

The 9325 allows simple display of strain bridge based measurements such as load cells, torque transducers, and other mV/V output transducers with sensitivity up to +/-1 V/V. Up to six calibration ranges are available allowing for different loading modes (tension and compression) or different sensors. Each calibration range will remember settings that contribute to the user experience such as selected units and tare values. TEDS devices using templates 33, 40, and 41 can be connected and will update the viewed calibration. The last twenty TEDS devices connected will be remembered and recognized when connected again reverting to the last user experience settings for that device. TEDS can be disabled and the internal calibration ranges become available again. There are also up to six display modes available. These determine what is visible on the LCD display and what actions are available from the set of three soft keys.
Full configuration is available with a PC based toolkit. Some simple configuration such as two point calibration is available from the handheld using the menu system.

Features & Benefits

USB port providing configuration, calibration, save & restore, live logging
Superior Linearity Performance Specifications
Measurement Rate up to 2400 Samples per Second
High Internal Resolution (up to 500,000 counts)
IP64 Environmentally Protected Enclosure
Battery Powered (Long Battery Life)
128 x 64 Graphical Display with Backlight
Multiple Display Modes (Peak/Valley, Delta, Live, Gross and Net)
Logging and Graphing to PC (Software is Included)
Supports TEDS Template 33, 40 and 41
Live Calibration and Multi-point Calibration
Standard Audio Alarm
CE Environmental Approved

Cable Assemblies

Accessories

Interface accessory products are made from the highest components and processes to ensure the specifications for your Interface products perform to meet their published specifications.

Features & Benefits

Interface uses the highest grade cables and connectors to ensure the performance of your force and torque systems are at the highest level.

Designed to work with Interface products
Made with the highest quality components and processes
Created to maintain the specification of the product they are intended for
For connecting transducers to instrumentation
Standard and custom lengths
Shielded cable

Mating Connectors

Accessories

Interface accessory products are made from the highest components and processes to ensure the specifications for your Interface products perform to meet their published specifications.

Models MC-001, MC-002, CN-207, CN-208, and CN-214 are available.

Features & Benefits

Interface uses the highest grade mating connectors to ensure that the performance of your force and torque solutions are not compromised.

Designed to work with Interface products
Made with the highest quality components and processes
Created to maintain the specification of the product they are intended for
Mating connector and cable
Dressed pigtails
Interconnects between load cell and instruments

System Level Calibration

Interface strongly recommends requesting a system-level calibration when purchasing a force measurement sensor with instrumentation. This final step ensures the sensor and instrumentation are properly calibrated and functioning together before leaving Interface.
