Interface Load Cells for Press Machines

/0 Comments/in /by

Press machines are designed to measure and apply force for various reasons. Hydraulic presses can be used to shape materials or crush objects. Stamping presses make a visible impression or stamp onto materials, such as a pharmaceutical tablet or logo on a food product. Even sandwich presses follow many of the characteristics of more industrial presses.

Press machines are used across automotive, aerospace, construction, consumer goods, medical, agriculture, mining, and other industries.  The presses produce consistent, cost-effective quality parts, tools, and products. No matter what kind of press machine, it must undergo rigorous testing during the machine-building process. During operation, there must be continuous monitoring of the press force used in each application.

NEW! Interface Solutions for Machine Builders

Interface load cells are critical to designing, testing, and using accurate and reliable press machinery. Interface load cells come in various shapes, dimensions, and capacities, allowing press machine builders and engineers to find the best solution for their specific machinery use case. Whether selecting a miniature load button load cell for a small press test or our WMC Load Cell to integrate into the machine, Interface has a range of products for press machine applications.

Benefits of using load cells in press machines:

  • Enhance Operator Safety
  • Prevention of Overloading
  • Improve Consistency
  • Avoid Damage to Equipment
  • Reduce Waste and Scrap
  • Increase Quality and Consistency of Work Product
  • Improve Process Control
  • Extend the Life of the Machine’s Operation
  • Increase Productivity

In a press machine test, the load cell is typically placed between the ram of the press and the die, where it can measure the force being applied to the object. The load cell is usually connected to a readout or display showing the operator the force applied to the part or material. This readout may be a simple analog or digital display, depending on the specific press and load cell being used in the machine. Review our Instrumentation Selection Guide to find the best option for your press.

There are numerous options for the types of load cells used for press machine applications. Hydraulic presses are some of the most common presses that use load cells. These machines are often built to form metal parts, such as gears, shafts, and bearings. The construction industry uses presses to assemble and test concrete structures. These presses are designed to crush and process minerals and ore in mining.

Mechanical presses are typically used for high-precision applications, such as metal stamping and forming. Miniature load cells are used in more precise applications that require smaller measurements. These use cases are often reserved for the medical or consumer goods industry, where the goal is to provide a stamping force for medicine or candy to label the product without crushing or damaging it. A precision Interface load cell ensures that the force applied to the material is consistent and accurate.

Another type of press using a sensor is known as a screw press which forms and compacts materials such as plastic and rubber. These press machines are found in chemical, food, and waste processing facilities.

Depending on the measurement capacity needed in the machine’s application, two popular Interface options are the Rod End Load Cells and Mini WMC Sealed Stainless Steel Load Cells. A rod end load cell is typically installed at the end of the piston or ram, where it can measure the tension or compression force being applied during the pressing operation.  These load cells provide accurate and reliable force measurement in various presses.

Press Forming and Load Monitoring

Press forming is a method to deform different materials. For instance, materials such as steel can be bent, stretched, or formed into shapes. A force measurement solution is required to monitor the forces being applied by the press-forming machine. This ensures quality control and traceability during the production process. Interface recommended installing the 1000 High Capacity Fatigue-Rated LowProfile™ Load Cell for large press forming machines. When the material is placed under the punch plate to form a shape, the 1000 series load cell measures the force applied. The captured force results were sent to the INF-USB3 Universal Serial Bus Single Channel PC Interface Module, where results could be graphed and logged on the customer’s PC using the provided software. Interface’s force measurement products and instrumentation accurately monitored and logged the force results of the press force machine, ensuring zero-error production performance.

Tablet Forming Machine Optimization

A pharmaceutical tablet producer wanted to monitor the forces the tablet forming machine applied to understand the relationship between raw material, die set, form, force, and the motor’s cycle speed. The goal was to improve the productivity and efficiency of the tablet-forming process while reducing losses (i.e., cracked tablets or voids) by adding a dimension of feedback that could be used to assign specific press adjustment criteria for given inputs. An Interface Model WMC Sealed Stainless Steel Mini Load Cell (10K lbf Capacity) was mounted in the section of the downward press bar. The machine was modified to accomplish this. The load cell was then connected to a Model 9320 Portable Load Cell Indicator to collect the needed data. After analyzing the data, the tablet producer could quantify adjustment levels by monitoring which forces produced optimal results for a given cycle speed, die set, and raw material. The enhancement of the data feedback significantly improves productivity and efficiency.

Candy Stamp Force Testing

Manufacturers of hard-shell candies often stamp text or logos on the candy shells. Stamping too hard breaks the candy shell and stamping too light results in an uneven or incomplete imprint. Using a test apparatus with an Interface Model WMC Mini Load Cell attached to hydraulic actuators was discovered to be an accurate way to measure the compression force required. Engineers determined the specific force needed to properly apply the imprint without breaking the candy shell using this solution.

Using Interface load cells on a press machine is a valuable investment that can help to improve the quality of the products being produced, extend the life of the press machine, and reduce the risk of accidents.

ADDITIONAL RESOURCES

Press Forming and Load Monitoring

Press Load Monitoring App Note

Hydraulic Press Machines and Load Cells

Metal Press Cutting Machine

Interface Solutions for Machine Builders

Force Measurement Sensors are Essential to Modern Industrial Machinery



Force Measurement Sensors are Essential to Modern Industrial Machinery

/0 Comments/in /by



Industrial machinery plays a vital role in the global economy. It helps to improve productivity and efficiency, and it is essential to produce many of the goods we rely on daily.

Industrial machinery use cases range from equipment used in manufacturing and construction to transportation and robotics. Force measurement sensors and instrumentation play a critical role in ensuring industrial machinery’s safe and efficient operation.

Interface sensor technologies, including our load cells and multi-axis sensors, provide critical data for various machinery designs and functions. Interface analog and digital instrumentation products are available to amplify, condition, and display the signals from force measurement sensors.

The accuracy of force, torque, and weight measurements guide industrial machinery’s design and performance mechanisms.

What types of industrial machinery are using Interface measurement products today?

  • Machine tools used for grinding, drills, and lathes
  • Fabrication apparatus used for bending, shearing, and welding
  • Assembly equipment for production environments that include conveyor belts, robotic arms, and picking devices
  • Testing, quality control, and safety inspection equipment
  • Heavy equipment operational controllers for forklifts, cranes, and hoisting gear
  • Construction machinery such as loaders, bulldozers, and lifts

Industrial machinery is prevalent in manufacturing vehicles, aircraft, consumer goods, medical devices, and pharmaceuticals. Heavy-duty machinery is standard in energy production, mining, forestry, agriculture, and transportation.

The machines’ quality heavily depends on the accuracy of measurements used in the initial design, retrofitting, production, and practice. Interface products provide the products that enable machines to operate at peak performance safely and efficiently. Learn more in our new Interface Industrial Machinery Solutions, a part of Industrial Automation market offerings.

How Interface Measurement Solutions Used in Industrial Machinery

Machine Safety Monitoring

Interface products are used for monitoring the performance of machines and for management in sensing potential problems before they cause a failure. Interface measurement technologies are used in construction machinery to enable operators to gauge the force applied to materials, preventing overexertion and potential damage. Read Interface Solutions for Safety and Regulation Testing and Monitoring

Heavy Machinery and Lifting Equipment

In material handling equipment, force sensors help prevent accidents and injuries. Interface load cells, including load pins and shackles, monitor loads, weight, and distribution. Learn more about lifting solutions in our Engineered Solutions for Lifting Webinar.

Manufacturing and Production Machines

Manufacturers rely on Interface sensor solutions in industrial machines such as injection molding machines to monitor the force applied to the mold or how they are used in machines to ensure correct product packaging. The efficiency of machines is enhanced by correctly measuring the forces applied during different operations. Force sensors help ensure products are assembled correctly and within tolerance on production lines.

Industrial Automation Machines and Robotics

Interface sensors in industrial machines such as robots allow for more precise and delicate tasks that measure force at touch and throughout the entire operation. In machine tools, load cells assist in monitoring cutting forces and prevent damage to tools and workpieces. In robotic arms and automated assembly lines, force sensors provide precise force application during welding, riveting, and material handling.

Benefits of Using Interface Products in Industrial Machinery

  • Improved safety: Load cells can help prevent accidents and injuries by monitoring the weight and distribution of loads and ensuring that machines operate correctly.
  • Increased productivity: Force measurement sensors can help improve machines’ efficiency by optimizing the force applied during different operations. Force measurement sensors can help reduce machine downtime and enhance the quality of products with accurate data, helping to make intelligent decisions.
  • Reduced waste and operating costs: Measurement devices can help to reduce costs by preventing machine failures and improving the quality of products.

Force measurement sensors and instrumentation are essential components of modern industrial machinery. They ensure the safe, efficient, and productive operation of these machines. Contact Interface application engineers to evaluate the best sensor technologies for your specific test and measurement pe failures and improving the quality of products.

ADDITIONAL RESOURCES

Hydraulic Press Machines and Load Cells

Sanding Machine Force Monitoring

Interface Solutions for Machine Builders

Metal Press Cutting Machine

Laser Machine Cutting Force App Note

Ice Machine Weighing

Force Measurement Testing Improves Products and Consumer Safety

Cobot Safety Programming

Crane Capacity Verification App Note

Interface Solutions for Machine Builders

/0 Comments/in /by

No matter the industry, if products are being made chances are industrial machines are involved in some part of R&D, testing, production, and distribution.

Engineers involved in the design and manufacturing of these machines require the highest quality sensors, tools and equipment. In addition, humans often lean on machines for very precise or repetitive tasks, this means that precision and reliability is key for every aspect of these machines.

Machine builders are the backbone of product development and production. They are responsible for building, assembling, and integrating components for stand-alone and multi-station automated machine tools and systems. These automated machine-tool systems are used in all sectors of manufacturing, including assembly, processing, and fabricating systems.

Interface plays a critical role for machine builders, for those that design one machine or manufacture machines at scale for users around the world. We supply machine builders with precision load cells, torque transducers, instrumentation, data acquisition devices and accessories. They lean on Interface because of our experience in supplying the world solutions utilized for industrial product testing and production across all kinds of industries from agricultural machinery to medical testing machines.

The accuracy and quality of our products is why machine builders rely on Interface. In addition, our experience and diversity of product has led machine builders and engineers to choose Interface force measurement sensors throughout their careers. In fact, Interface has served machine builders for more than 50 years. It is a relationship and role we know very well.

The world of machine building has also changed over the years. In the past, machine builders used force sensors primarily to test products before going out to the market. This is still a prominent use case amongst product engineers. The fast-rising use cases over the past decade comes from the demand for smarter machines, automation and miniaturization of products.

Today, more machines builders and OEMs are designing force sensors directly into machines to allow users to activate components, monitor data on the machines in use for real-time feedback and adjustments. This type of innovation using sensors has opened opportunities for Industry 4.0 connectivity between machines.

To get a better idea of how machine builders are using force sensors, Interface has developed a wide range of applications notes to provide real world examples of force measurement in action in the machine building world. We have included a few of those examples below.

Metal Press Cutting Machine

A customer wanted to test the amount of force it takes to cut through different thicknesses of metal on their metal press cutting machine. They also wanted to ensure their metal press cutting machine is working properly and understand its maximum limitation. Interface suggested installing their 3AXX 3-Axis Force Load Cell underneath the plate where pieces of metal are placed to be cut, or punched holes in. When connected to the BX8-HD44 BlueDAQ Series Data Acquisition System, the force results of different metals being cut will be displayed, graphed, and recorded on the customer’s PC. It also has an analog output that can connect to the machines PLC in case of an overload. Using this solution, the customer was able to determine the different number of forces it took for their metal press cutting machine to cut through different types and thicknesses of metal. Read more here.

Snack Weighing and Packaging Machine

A snack manufacturing brand wanted to weigh the amount of their snacks that is automatically dispersed into the bags during the packaging process. In this case, they wanted to weigh their potato chips being packaged and ensure the potato chips are at the exact weight needed due to regulatory standards. Interface’s solution was to use multiple SPI Platform Scale Load Cells and install it to the potato multi-head weigher and packaging machine. The SPI Platform Scale Load cells were installed inside of the mount that attaches the head weigher to the packaging machine. Force results from the potato chips are read by the load cells and sent to the ISG Isolated DIN Rail Mount Signal Conditioner, where the customer is able to control the automated production from their command center. Using this solution, the customer was able to determine the weight of the potato chips being distributed into their bags with highly accurate results. They also were able to control the automated production process with the provided instrumentation. They will use this same weighing method for other snacks that need to be packaged. Read about this application here.

Tablet Forming Machine

A pharmaceutical company needs to precisely monitor the forces applied by the tablet (pill) forming machine to understand the relationship between raw material, die set, forming force, and motor cycle speed. Optimizing the equipment will improve productivity and efficiency of the tablet forming process, while reducing losses. For maximizing production and monitoring the process, Interface suggested a WMC Sealed Stainless Steel Mini Load Cell (10K lbf Capacity) be mounted in the section of the downward press bar. The load cell was then connected to a 9320 Portable Load Cell Indicator to collect the needed data. Read more here.

Machine builders require the best test and monitoring equipment. Interface has backed professional machine builders, machine design engineers, machine manufacturers and those that utilize the equipment for many years with top-of-the-line force sensing solutions.  Whether you are looking to build a machine, design machine tools and equipment or embed sensors into machines, we are here to help.

ADDITIONAL RESOURCES

Proving Theoretical Cutting Forces of Rotary Ultrasonic Machinery App Note

Force Solutions for Testing Machines

Interface Sensors Used for Internet of Things

OEM: Industrial Robotic Arm

Fitness Equipment and Machines

Ice Machine Weighing

GS-SYS04 Gold Standard® Portable E4 Machine Calibration System

Laser Machine Cutting Force App Note

Advancing Auto Testing with Interface Measurement Solutions

/0 Comments/in /by

What classifies as the automotive industry involves a complex and dynamic mix of suppliers, makers and designers of all types of vehicles, as well as prototypes of the changing demands and requirements of consumers both big and small.  Whether we look at where we are today with hybrid and electric motors, or autonomous rigs and people movers in test now, one thing that is constant is Interface’s role in providing vital measurement solutions for testing and real-time performance monitoring in the automotive and vehicle markets.

Automotive is one of the industries in which Interface has worked with since the introduction of our first load cells more than five decades ago. Force and torque measurement is critical to testing at every stage of design and manufacturing. Our sensor solutions, instrumentation and accessories are used across all facets of component development, including the testing of engines and exterior bodies, tires, batteries, fuel pumps and more.

Interface products are used for crash walls, brake testing, energy storage tests in the lab, seat belt and headrest testing, just to name a few. The fact is torque and force play a major role in making the vehicle move and ensuring it’s safe for drivers and pedestrians alike.  Interface is showcasing some of these solutions at the upcoming Automotive Test Expo. Registration to attend is free.

As the industry evolves, so do we. In fact, our advanced product AxialTQ was created for the automotive industry for testing of EVs. This revolutionary torque transducer is now used in all types of line production, assembly and part, including:

  • Internal Combustion Engine (ICE) Lab Testing and End of Line (EOL) Testing
  • Drivetrain Lab Testing
  • Automotive Accessory Lab Testing
  • Electric Vehicle (EV) Motor EOL and EV Lab Testing

For more about this dynamic product, you can watch our latest AxialTQ Webinar here.

Interface supplies high quality, precision load cells to automotive manufacturers, including custom one-off sensors and special application-specific designs. Standard off-the-shelf models such as our 2400 series , our 3200 series Stainless Steel LowProfile™ Load Cells, and our WMC Miniature Load Cell family are popular with machine builders and used anywhere a rugged stainless steel load cell is required.

Research and development facilities with precision applications favor our 1200 Series LowProfile™ Load Cells with their special moment compensated design. These are used in auto manufacturer assembly lines in a variety of production monitoring and verification applications. Our exceedingly accurate LowProfile™ Load Cells have been used in NASCAR and IndyCar garages for testing individual springs and entire vehicle suspensions.

A moment compensated Interface load cell has as much as 1,000 times less error from side load or moment as our competitor’s products. And many of our sensors feature 10x mechanical overload protection, which helps protect against unintended loads. Our Model BPL Load Cell is a very LowProfile™ load cell used for measuring force on gas, brakes or clutch pedals.

With a wide range of automotive vehicle load cell sensors, force and torque measurement capabilities, and features such as moment compensation, temperature compensation, and mechanical overload protection, Interface can help you design a solution perfect for your automotive application. In fact, here are a few examples of our products in action.

Airbag Connector Testing

Testing airbag connectors functionality is needed ensure perfect deployment to meet the ultimate test of saving lives. There are eight to twelve connectors installed in each vehicle, and tests are needed to be made in order to clarify the connectors are working effectively. The amount of force needs to be tested in order to see when an electrical current has triggered use.  Utilizing the WMC Sealed Stainless Steel Miniature Load Cell to the actuator of the test rig. The airbag connector is held in place at the bottom of the test rig. Forces are applied and measured using the 9330 High Speed Data Logger as the connector is pushed down to latch together.  Read more about this use case.

Seat Testing

During testing there was consistent overloading and replacing of the single-axis load cells. After a thorough inspection, it was discovered that this was due to bending moments that had never been quantified so a multi-axis sensor was defined as the best solution.  An Interface Model 6A68C 6-Axis load cell was installed in their existing test machine. The 6-Axis Sensor was intentionally oversized allowing the customer to measure the unidentified bending moments while preventing any damage. Data Acquisition and Amplifier BX8 was used to graph, log, & store the data collected at the sensor. Read more here.

Automotive Headrest Testing

When a manufacturer for automotive head rests wanted to test the durability of their products by conducting several fatigue tests and force tests on the head rests to make sure it meets durability and high-quality standards, Interface was able to help. The solution was to install Model 1000 Fatigue-Rated LowProfile™ Dual Bridge Load Cell to the customer’s actuator mechanism. This load cell is perfect for fatigue testing and reports highly accurate results through the fatigue cycling. The results are collected by using the SI-USB4 4-Channel USB Interface Module, which synchronizes the data directly from the load cell and the string pot (for measuring distance) to the customer’s computer. Using this system, the head rest manufacturer was able to get highly accurate data through the fatigue testing cycle. Watch the testing video in action!



Engine Dynamometer

Internal combustion engines are by far the most common power source for land vehicles. From a 2-stroke motor in a lawn mower, to a V-8 stock car engine, horsepower and torque are the benchmarks of engine performance. Engine manufacturers and aftermarket suppliers use an engine dynamometer (dyno for short) to accurately measure an engine’s performance. An engine dyno isolates an engine’s power output to help quantify its overall performance, applying a load directly to the engine and utilizing a load cell to measure the torque absorbed by the loading mechanism. Horsepower is then calculated using the torque and RPM of the engine. To conduct this test, a precision S-Type Load Cell is attached to a torque arm which “feels” the torque from the engine loading system. The Interface Model SSMF is a great choice because it is fatigue-rated for a number of fully reversed cycles and is environmentally sealed to withstand harsh environments. Utilizing the Model CSC Signal Conditioner provides a clear signal to a data-acquisition system. Using this test solution, the load cell reacts precisely with the amount of torque being produced by the engine and provides accurate signals to the data-acquisition system. Engineers are then able to analyze the power transfer for the engine and optimize for performance. Read more about this solution here.

For additional automotive solutions and use cases, go here.

Considerations for Steel, Stainless Steel and Aluminum Load Cells

/0 Comments/in /by

In the world of force measurement and load cells, one size certainly does not fit all. There are thousands of different options for size and force ranges, and our load cell configurations vary widely based on the requirements of your project. Whether you are designing and testing products for the medical industry, or measuring force deep within a mine shaft, users need to be aware of certain force product details to ensure their getting the right tools for the job.

One of the critical considerations in the load cell selection process are the materials used in the construction of the load cell. If you did not already know, load cells can be made from several different metal materials. This list includes aluminum, steel, stainless steel, titanium, Inconel®, and even glass or carbon fiber.

Each material used depends on the end-use requirements and the need for strength, resistance, hysteresis, environmental concerns, output signal, size and weight, and budget.

For this post, the focus is on the three most used materials for load cells: aluminum, steel and stainless steel. Below is an outline comparing the different factors that make one material better than the others based on the testing requirements and use case.

Aluminum

Aluminum is a light and inexpensive metal, making it the most budget-friendly of the three. It is also the easiest to machine, as it does not require a heat treatment or secondary machining. Aluminum has a higher thermal conductivity, which can be a good or bad thing depending on your need. The hysteresis of aluminum load cells is also the lowest on this list. The most prominent benefit is that it can be used for constructing smaller load cells, so if size, weight, and total volume of the load cell is a key consideration for your project, aluminum would be the metal we’d recommend.

In adverse, when dealing with aluminum load cells it is important to understand that it is the softest material on this list, which means it is more susceptible to damage. This also means that it cannot handle as much stress, resulting in a lower output signal.

Steel

Steel is a stronger metal, so it is a bit more expensive than an aluminum load cell. It is still comparatively cost-effective. It also has the highest strength of the three materials outlined here. This means it is the least susceptible to damage and has the highest signal output. It also has higher environmental resistance than aluminum and less heat conductivity, which once again can be good or bad depending on the project.

The downsides to steel include the fact that it is more complicated to machine and requires a multi-step heat treatment operation. Compared to aluminum, the hysteresis is generally slightly higher for certain load cell designs. This can be remedied with additional engineering. It also does not provide the benefit of size, weight, and total volume flexibility that lighter aluminum provides.

In our opinion, steel provides the best value for a load cell in terms of money and performance, if size, weight and total volume is not an issue with your project or application.

Stainless Steel

Stainless steel is a stronger material than aluminum; however, it is not as strong as steel. The output signal performance for stainless steel load cells is somewhere in the middle of steel and aluminum. The main benefit of stainless steel is that it is the best material to use in a corrosive environment because of the metal’s environmental resistance properties.

The downside to stainless steel is that it is a bit more difficult to machine but does only requires a simple heat treatment process. It is also the most expensive metal of the three and has the highest hysteresis. We would recommend stainless steel when the user needs to collect data in a hazardous environment. Read more here about our Ex Rated products.

Understanding the difference between these materials is critical to getting the most accurate data from your force tests based on the environment and the nature of the product or system you are testing.

If you’re unsure about the requirements your project demands, be sure to reach out to us at 480-948-5555, or visit our website to be connected with an application engineer. We can discuss your specific challenge and help you select the load cell with the right material for your needs.

Contributor Ken Vining, Chief Engineer at Interface



Interface Solutions for Robotics and Industrial Automation

/0 Comments/in /by

As the manufacturing world continues to push towards the 4.0 Industrial Revolution, critical technology is necessary to ensure facilities are running as efficiently as possible. With advancements toward fully or semi-autonomous factories and robotics, manufacturers need to have total trust in their hardware and software to perform with precision in the assigned tasks. This requires collecting accurate and real-time data to constantly monitor every aspect of the facility’s technology and production.

In the development of robotics used in industrial automation, our Interface Multi-Axis Sensors are often used to test the multi-directional movement and force of robotics arms. Whether it’s a fully automated or semi-automated robotic system, manufacturers need to be able to ensure the complex movements and actions of the robotics arm are optimized to take on very precise jobs. These types of robotics are often used for projects that are too precise for the human hand.

Industrial automation and robotics are creating a more efficient manufacturing process, which will help to churn products out more quickly and lower costs. However, to optimize these processes, it’s critical that we trust the hardware to operate autonomously and that we have systems in-place to identify malfunctions quickly.

Interface plays a critical role in robotics and industrial automation by providing our customers with highly accurate load cells and torque transducers to measure and collect data on the force and torque that these machines are exerting. Interface force measurement solutions and products are involved in the testing of the machines before they hit the production line, and in some cases, our products are also installed directly on the machine to allow users to monitor the force in real-time.

One industry that has a high demand for our products is the consumer packaging industry. Many of the processes involved in the production line of a consumer packaging plant have utilized automation for a long time.

For instance, beverage companies that sell bottles of water or soda utilize machines that cap the product all day long. Hundreds of thousands of bottles go through the capping process on the production line daily. If there are any issues with the torque applied in the capping process, the beverage company could see heavy losses because the bottle could be damaged from over torquing the cap, or the beverage could leak during the shipping process if the caps are under torqued. To avoid these loses, the machines are optimized using a torque transducer.

Torque transducers provide data during the testing process to help the machine manufacturer get the force exactly right for the capping process. The torque transducer can also stay installed on the machine so that the beverage company can continuously monitor the torque of the machine and stop production before damages occur if there is an issue.

Interface offers nearly 50 types of reaction (static) torque transducers and rotary (dynamic) torque transducers. All of our torque transducers are precision-machined and use our proprietary torque sensors for the most accurate data possible.

Another common automation use for force and torque measurement products is in the automotive industry. Automation in this industry has been used for some time increase production of cars.

Two examples of how Interface load cells and torque transducers play a role in the automobile production line is with seat durability testing and bolt fastening.

For seat testing, we had a customer use an Interface Multi-Axis Model 6A68C 6-Axis Load Cell to identify previously unknown bending forcing that could negatively influence their testing process. This allowed the customer to redesign their testing fixture to eliminate the bending moment and more accurately perform the durability testing.

For bolt fastening, we installed an Interface Model LWCF Clamping Force Load Washers along with Interface Instrumentation to monitor the force being applied during bolt tightening. This helped the customer avoid over tightening bolts, which could damage the product in the process.

For a more in-depth overview of both applications, please check out our application notes:

Force measurement products are a critical technology in the testing and monitoring of automation equipment. To learn more about the various products and instrumentation Interface supplies to facilitate industrial automation and support advancements in robotics, contact our applications experts here.  We also have a number of application notes focused on industrial automation here.

Contributor: Ken Bishop, Sr Sales Director, Custom Solutions and Services



Applications for Consumer Products and Packaging

/0 Comments/in /by

When we think about force measurement and its relation to product development, we often consider the aerospace, automotive or industrial industry. However, many of Interface’s customers use load cells and torque transducers to test and develop machinery used for consumer products and in the packaging industry.

In order to meet this demand, customers need force measurement tools that are both accurate and provide the necessary data points to automate and regulate consumer packaging machinery. This consumer packaging case study takes a look at the wide variety of applications of force measurement tools used to create consistency and quality among the products consumer buy and use daily.

BACKGROUND

If you have ever wondered how a pill or piece of candy gets a little logo stamped on it without crushing it or how every bag of chips is nearly filled to the same capacity, chances are a load cell or torque transducer was involved. Interface works with hundreds of customers who manufacture a wide variety of machines used in the consumer packaging industry. These machines serve numerous functions including logo stamping, bag weighing, bottle capping, sealing, and precision cutting.

According to Grandview Research, the use of automation, as well as robotics throughout the packaging lines, has seen tremendous growth in recent years. The aim is to improve productivity, reduce the operating costs and prevent waste, thus improving the overall efficiency of the packaging systems. “Big Data” has also gained popularity with operation managers that collect machine data to regulate the performance of the machinery, undertake preventive maintenance and maximize the up-time.

CHALLENGE

The challenge our customers run into when building these machines is they require a high level of precision to get consistent and repeatable results. If the machines are incorrectly calibrated, it can lead to excessive waste. For instance, if a bottle of soda isn’t capped correctly, it can leak, or if the machine which embosses toilet paper and napkins is too forceful, the paper will be ripped to shreds. Currently, most packaging machines are relying on physical hard stops, clutches, monitoring motor current and laborious tasks to monitor and apply the necessary force and torque. To ensure proper performance and to reduce waste, the most accurate and reliable force measurement tools are required.

SOLUTION

Interface works with hundreds of original equipment manufacturers (OEMs) who develop machines for the consumer packaging industry. Depending on the function of the machine, we manufacture a wide variety of force measurement products to help reduce waste, ensure repeatable results and provide accurate data to help consumer packaging customers automate their processes.

All of our products come with various data communication systems, including analog or digital and Bluetooth®, wireless or Ethernet. This provides customers with flexibility in their data collection methods and the ability to connect systems through the Internet of Things (IoT) functionality. For machines using a precision twisting motion, such as capping machines, we offer nearly 50 types of reaction torque transducers and rotary torque transducers for customers. All of our torque transducers are precision-machined and use our proprietary torque sensors for the most accurate data possible.

For precision weighing or stamping, such as the candy stamping application, we manufacture more than 60 different types of load cells and Interface Mini Load Cells. These load cells have capacities as low as 1 lbf (500 gf) for extreme precision. In our customer’s application highlighting candy stamping, a test apparatus was outfitted with the Interface Model WMC Mini Load Cell and a 9330 Data Logging Indicator to measure the compression force required to imprint the candy without crushing it and collect data to finely tune the process.

For applications using robotics, Interface offers multi-axis sensors to test force and torque measurements simultaneously in three mutually perpendicular axes.

RESULTS

Accuracy in packaging is a game-changer for cost-savings, production efficiency, time-to-market, and product safety. Whether you are measuring, weighing or securing, Interface load cells, mini load cells, torque transducers, and instrumentation can assure you the quality and accuracy you need to protect your brand and customer satisfaction.

Interface is one of the leading force measurement manufacturers for the consumer packaging industries. We work directly with OEM’s and engineering consultants to implement systems and products which help to reduce waste, automate the packaging process and provide accurate, repeatable results. For more information on how Interface can help solve your test and measurement challenges, please contact us to connect with our specialized Application Engineers, click here to locate a local Representative or International Distributor.

READ COMPLETE CASE STUDY HERE

Interface Case Study For Consumer Packaging
